Subject: Proper Method for Running Benchmark and Diagnostics Programs
Date: 06/04/93
Page(s): 1 of 1
This bulletin describes the proper method for running any benchmark or diagnostics
programs. This applies to any computer system.
In most cases, the computer should be started using an MS-DOS boot diskette
that's 'clean' - in other words, one with no CONFIG.SYS or AUTOEXEC.BAT files.
The appropriate executable can then be run, either from diskette or hard drive.
There will be some exceptions to the above rule. In attempting to benchmark or
troubleshoot any add-on that requires a device driver (CD-ROM, local area network,
etc.), obviously the necessary device driver(s) must be loaded. Also, some
programs will require a minimum number of FILES or BUFFERS to be defined in
the CONFIG.SYS file. Such programs will usually display this requirement if they
are run without the necessary CONFIG.SYS file.
For the most consistent results, use the absolute minimal boot configuration that's
allowed by the hardware being tested.
EPSON
PSB No: S-0158
Originator: MWT
Advertisement
Related Manuals for Epson Apex 100
Summary of Contents for Epson Apex 100
- Page 1 EPSON Product Support Bulletin Subject: Proper Method for Running Benchmark and Diagnostics Programs Date: 06/04/93 PSB No: S-0158 Originator: MWT Page(s): 1 of 1 This bulletin describes the proper method for running any benchmark or diagnostics programs. This applies to any computer system.
-
Page 2: Table Of Contents
SOTA 386si from SOTA Technology, inc. The Equity models tested were the Equity I, Equity II Equity I + and Equity le. The Apex models tested were the Apex, Apex Plus and Apex 100. All were tested with Norton Utilities and MS - DOS. - Page 3 PSB No: S-0111 Page: 2 of 3 Installation of the board in most of the units was quick and simple to do when following the installation instructions accompanying the boards. Installation of the SOTA 386si in the Equity I and the Equity II is rather difficult. Due to the amount of disassembly required, we strongly recommend that only Authorized Service Centers install the board in the Equity I and Equity II.
- Page 4 Although these boards were tested by qualified product support specialists, Epson America makes no representations that these third party products are compatible with all hardware configurations or software applications. We recommend that you certify these products with your specific hardware and software requirements and consult with the third party vendor to ensure reliable operation.
-
Page 5: Date: 9/5/89
Q. Does the APEX 100 have a serial interface port? A. Yes, an IBM PC- compatible (25 - pin connector) serial port is standard with the APEX 100 and can be used to connect a serial device such as an external modem, serial mouse or a serial printer. - Page 6 L- series printers are 24 - pin printers with superb letter quality print. The L1000 is an 80 column printer and the L750 is a 136 column printer. Q. What type of hard disk drive does Epson use with the APEX 100\20 and what is the average disk access time.
- Page 7 20MB, the WD1002A- WX2 hard disk controller with Western Digital’s SuperBios ROM should be used. Q. What type of floppy disk drives does the APEX 100 have and what kind of floppy diskettes should I use? A. The APEX 100 - series computers use half - height, 5 1/4”, 360KB floppy disk drives.
- Page 8 Make sure the system requirements on the software package matches your computer configuration and video adapter type. Software is available through Epson Accessories, Inc. at 1 - 800 - 873 - 7766, or at your local software store. Q. Can I install a Math- Coprocessor chip and what type do I need? A.
- Page 9 PSB No: S-0097 Page: 5 of 8 Q. Can I use the APEX 100 Monochrome Monitor (Model # AP - 1040) with other IBM PC - compatible computers? A. The Apex 12” Monochrome monitor (Model AP - 1040) uses a TTL video signal which is IBM PC - compatible and can be used with other computers that have a monochrome TTL video board.
- Page 10 TEX - 60 from Idea Associates and the Everex Stream - 20MB, Model 4.02 from Everex Systems, Inc. Q. What kind of joystick can I use with the APEX 100 and where do you connect it? A. There are many IBM PC- compatible joysticks available and some have different types of connectors.
- Page 11 The APEX 100 computer can be used in both the United States and internationally simply by selecting the appropriate input voltage on the voltage selection switch located on the rear of the unit. The APEX 100 will operate on either 115VAC or 230VAC at 50/60 Hz power.
- Page 12 A. Yes, the IBM 5250 emulation board (ver. 2.1) is certified with for use with the APEX 100. Q. Can the APEX 100 be used as a workstation on a Local Area Network? A. The APEX 100 has been tested as a workstation using network adapter...
-
Page 13: Equity I
Product Support Bulletin Subject: Equity and Apex Series Compatibility with the System OmniBridge Controller and BridgeFiler External Floppy Drives PSB No: S-0088B Date: 04/11/90 Originator: KAS 60 Page: 1 of 3 The purpose of this bulletin is to provide the results of compatibility testing conducted by the Computer Product Support Center with the Sysgen OmniBridge controller and Bridge - Filer external floppy disk drives. -
Page 14: Apex
(1.2M and 1.44M) or normal (360K and 720K) disk drives. APEX The Epson APEX was found compatible with the OmniBridge controller. It was able to support one or two external disk drives (daisychained) together. The external drives could be used as high density (1.2M and... -
Page 15: Apex 100
PSB No: S-008B Page: 3 of 3 APEX 100 The Epson APEX 100 was found compatible with the It was able to support one or OmniBridge controller. two external disk drives (daisychained) together. The external drives could be used as high density (1.2M and 1.44M) or normal (360K and 720K) disk drives.
