Tascam HS-8 Software Manual

New functions in firmware V1.20
A tape emulation mode has been added for use with an editor/
synchronizer that supports the Sony P2 protocol using the RS-422
connector.
Tape emulation mode
The tape emulation mode emulates linear time-based operation
like that of tape. Using transport control via RS-422, the unit can be
operated like a tape machine. With "00:00:00:00" as the tape starting
point, each take is located by its start TC position.
Example:
Time line
Take 1
01:00:00:00
Start TC position
NOTE
Only takes in the currently loaded folder can be played back in this
mode. Takes in other folders cannot be played back in tape emulation
mode.
REMOTE SETUP screen RS-422 page
ª
and buttons have been added for the RS-422 tape emulation
ON OFF
function. Turning it will automatically pause the transport. This
ON
function only works when the
NOTE
If the HS-8 is playing back in emulation mode, changing settings
will not be possible. The following pop-up will appear if you try to
change a setting. (Some settings are excluded from this restriction.)
To change a setting, press the
beforehand. After making the change, press the
to resume emulation mode.
D01162820A
Take 2
Take 3
02:00:00:00 02:50:00:00
is set to
Serial Mode RS-422
STOP
key once to stop the transport
PLAY PAUSE
or
Home Screen
ª
When the tape emulation mode is ON,
indicator ( 1 ) at the top right of the Home Screen.
When a take that is playing back matches the time of the emulated
tape, this indicator appears lit.
When there is no take that matches the time of the emulated tape,
this indicator blinks.
When the tape emulation function is ON, the time code display (
is limited to one of the following three types.
Meaning
Display ( )
2
The elapsed time from the start of the take is shown.
(Nothing If there is no take that matches the time of the
shown) emulated tape, the starting time of the next take is
shown.
The remaining time until the end of the take is
shown. If there is no take that matches the time of
REMAIN
the emulated tape, the remaining time (length) of
.
the next take is shown.
The emulated tape time is shown.
TAPE
Sync and time code settings (SYNC T/C
ª
screen) SETUP page
On this page, the
•
from the project time code frame type to the input time code
frame type.
You can now change the project time code frame type. It cannot,
•
however, be changed during playback or recording.
key
appears as the left
TAPE
section contents have been changed
STATUS
HS-8
)
2
1
TASCAM HS-8
