Duracell Coppertop MN 1500 Specification Sheet

5.5 mm
Max.
+
( )
–
( )
Dimensions shown are ANSI standards
Berkshire Corporate Park Berkshire Corporate Park Berkshire Corporate Park Berkshire Corporate Park
Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A.
Telephone: Toll-free 1-800-544-5454 Telephone: Toll-free 1-800-544-5454
Internet: www. Internet: www.duracell duracell.com .com
* *
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
MN1500_US_CT.PDF
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
Page 1 of 2
14.5
mm
13.5
1.0 mm
MIN.
50.5
mm
49.5
Alkaline-Manganese Dioxide Battery
Nominal Voltage:
Operating Voltage
Impedance:
Typical Weight:
Typical Volume:
Terminals:
Storage Temperature
Range:
Operating Temperature
Range:
ANSI:
IEC:
TYPICAL DISCHARGE CHARACTERISTICS AT 21°C (70°F)
1.6
1.5
1.4
1.3
1.2
1.1
1
0.9
0.8
0 20 40
MN1500
Size: AA (LR6)
1.5 V
1.6 - 0.75V
120 m-ohm @ 1kHz
24 gm (0.8 oz.)
8.4 cm 3 (0.5 in. 3 )
Flat
o o
-20 C to 35
C
o o
-20 C to 54 C
o o
(-4 F to 130 F)
15A
LR6
3.9 OHMS
10 OHMS
24 OHMS
43 OHMS
60 80 100
Service Hours
120
6/08
