NF61S-M2 TE Setup Manual
FCC Information and Copyright
This equipment has been tes ted and found to comply with the limits of a Class
B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed
to provide reasonable protec tion against harmful interference in a residential
installation. T his equipment generates , uses , and c an radiate radio frequency
energy and, if not ins talled and used in accordance with the instructions , may
cause harmful interference to radio communications . There is no guarantee
that interference will not occur in a particular ins tallation.
The vendor makes no representations or warranties with respec t to the
contents here and s pecially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make c hanges to the c ontents here without obligation to
notify any party beforehand.
D uplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be c hanged without notice and
we will not be res ponsible for any mis takes found in this user's manual. All the
brand and produc t names are trademarks of their respec tive companies .

Advertisement

Table of Contents
loading

Summary of Contents for Biostar NF61S-M2 TE

  • Page 1 NF61S-M2 TE Setup Manual FCC Information and Copyright This equipment has been tes ted and found to comply with the limits of a Class B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed to provide reasonable protec tion against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction.............1 Before You Start..............1 Package Checklist..............1 Motherboard Features............2 Rear Panel Connectors............3 Motherboard Layout ............4 Chapter 2: Hardware Installation........5 Installing Central Processing Unit (CPU) ........ 5 FAN Headers................ 7 Installing System Memory............8 Connectors and Slots ............10 Chapter 3: Headers &...
  • Page 3: Chapter 1: Introduction

    NF61S-M2 TE CHAPTER 1: INTRODUCTION EFORE T ART Thank you for choosing our product. Be fore you start installing the mothe rboard, please make sure you follow the instructions be low: Prepare a dry and stable work ing environment with sufficie nt lighting.
  • Page 4: Motherboard Features

    Motherboard Manual OT HERBOARD EAT URES SPEC Socket AM2 AMD 64 Architectu re enables 32 and 64 bit AMD Athlon 64 / Athlon 64 FX / Ath lon 64 X2 computing / Sempron processors Supports Hyper Tran sport and Cool=n =Quiet Supports up to 1GHz Bandwidth Support HyperTran sport Chipset...
  • Page 5: Rear Panel Connectors

    Micro ATX Size Board Special RAID 0 / 1 support Features Biostar Reserves the righ t to add or remove support OS Support Windows 2000 / XP / VISTA for any OS With or withou t notice. ANEL ONNECT ORS...
  • Page 6: Motherboard Layout

    Motherboard Manual OT HERBOARD AYOUT JCFAN1 JKBMS1 JATXPWR2 JUSB1 JATXPW R1 JUSBLAN1 JAUDIO1 GeForce JCDIN1 6100-405 JAUDIOF1 PEX1_1 SATA1 SATA2 PEX16_1 BIOS JCMOS1 BAT1 PCI1 Super I/O PCI2 Codec JSPDIF_OUT1 JPRNT1 JUSB2 JUSB3 JPANEL1 FDD1 JSFAN1 Not e: represe nts the 1 pin.
  • Page 7: Chapter 2: Hardware Installation

    NF61S-M2 TE CHAPTER 2: HARDWARE INSTALLATION (CPU) NST ALLING ENT RAL ROCESSING Step 1: Remove the socket protection cap. Step 2: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle.
  • Page 8 Motherboard Manual Step 4: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 5: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the JCFAN1. This completes the installation.
  • Page 9: Fan Headers

    NF61S-M2 TE FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 10: Installing System Memory

    Motherboard Manual NST ALLING YST EM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 11 NF61S-M2 TE B. Memory Capacity DIMM Socket DDR Module Total Memory Size Location DIMMA1 256MB/512MB/1GB/2GB *1 Max memory 4GB. DIMMB1 256MB/512MB/1GB/2GB *1 C. Dual Channel Memory installation To trigger the Dual Channel f unction of the motherboard, the memory module must meet the following requirements: Install memory module of the same density in pair, shown in the following table.
  • Page 12: Connectors And Slots

    Motherboard Manual ONNECT ORS AND LOT S FDD1: Floppy Disk Conne ctor The motherboard prov ides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk ty pes. This connector supports the prov ided f loppy drive ribbon cables. IDE1: Hard Disk Conne ctor The motherboard has a 32-bit Enhanced IDE Controller that prov ides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 f unctionality.
  • Page 13 NF61S-M2 TE PEX1_1: PCI-Expre ss x1 Slot PCI-Express 1.0a compliant. Data transf er bandwidth up to 250MB/s per direction; 500MB/s in total. PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins. 2X bandwidth ov er the traditional PCI architecture.
  • Page 14: Chapter 3: Headers & Jumpers Setup

    Motherboard Manual CHAPTER 3: HEADERS & JUMPERS SETUP OW T O ET UP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 15 NF61S-M2 TE JATXPWR1: ATX Powe r Source Conne ctor This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V...
  • Page 16: Sata1 Sata2

    Motherboard Manual JUSB2/JUSB3: Heade rs for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC f ront panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused) +5V (fused)
  • Page 17 NF61S-M2 TE JCDIN1: CD-RO M Audio-in Connector This connector allows user to connect the audio source f rom the v ariaty dev ices, like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card etc. Assignment Left Channel Input Ground Ground...
  • Page 18 Motherboard Manual J1: Power Source Heade r for PS/2 Ke yboard and Mouse Pin 1-2 close +5V for PS/2 keyboard and mouse. Pin 2-3 close PS/2 keyboard and mouse are powered by +5V standby voltage. Note: In order to support this func tion “Power-on s ystem via keyboar d and mouse”, “J 1” jumper cap s houl d be pl aced on Pi n 2-3.
  • Page 19 NF61S-M2 TE JSPDIF_O UT1: Digital Audio-out Conne ctor This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JPRNT1: Printe r Port Connector This header allows you to connector printer on the PC. Assignment Assignment...
  • Page 20: Chapter 4: Raid Functions

    Motherboard Manual CHAPTER 4: RAID FUNCTIONS PERAT ION YST EM Supports Windows XP Home/Prof essional Edition, and Windows 2000 Professional. RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications.
  • Page 21 NF61S-M2 TE RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
  • Page 22: Chapter 5: Useful Help

    Motherboard Manual CHAPTER 5: USEFUL HELP RIVER NST ALLAT ION OT E After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system.
  • Page 23: Award Bios Beep Code

    NF61S-M2 TE BIOS B WARD Beep Sound Meaning One long beep followed by two short Video card not found or v ideo card beeps memory bad High-low siren sound CPU overheated System will shut down automatically One Short beep when system boot-up No error found during POST...
  • Page 24: Troubleshooting

    Motherboard Manual ROUBLESHOOT ING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, f an securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on key board does not turn on.
  • Page 25: Chapter 6: Warpspeederâ„¢ Iii

    NF61S-M2 TE WARPSPEEDER™ III CHAPTER 6: NT RODUCT ION [WarpSpeeder™ III], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 26: Installation

    Motherboard Manual NST ALLAT ION 1. Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. 2. When you see the following dialog in setup procedure, it means setup is completed.
  • Page 27: Warpspeederâ„¢ Iii

    NF61S-M2 TE 6.4 W ™ III PEEDER 1. Desktop Icon After the [WarpSpeeder™ III] has been installed, a [WarpSpeeder™ III] icon will appear on the desktop, just like the icon shown below. Now you can launch the [WarpSpeeder™ III] utility simply by double-clicking the desktop icon.
  • Page 28 Motherboard Manual 3. Overclock/Overvoltage Panel Click the Overclock/Overvoltage button in the Main Panel, the button will be highlighted and the Overclock/Overvoltage Panel will show up as the following figure. As you can see, the Overclock Panel is on the right side, and the Overvoltage Panel is on the left side.
  • Page 29 NF61S-M2 TE O ve rclock Panel contains these fe atures: a. “Auto-Overclock”: User can click this button and [WarpSpeeder™ III] will set the best and stable performance and frequency automatically. A warning dialog as below will show up to notify you that the system may become unstable, click on “OK”...
  • Page 30 Motherboard Manual O ve rvoltage Panel contains these fe ature s: a. “CPU Voltage”: This function allows user to adjust CPU voltage. Click on “+” to increase or “-“ to decrease the CPU voltage. b. “Memory Voltage”: This function allows user to adjust Memory voltage. Click on “+” to increase or “-“...
  • Page 31 NF61S-M2 TE 5. About Panel Click the “about” button in Main Panel, the button will be highlighted and the About Panel will show up as the following figure. In this panel, you can get model name and detail information in hints of all the chipset that are related to overclocking.
  • Page 32: Appendencies: Spec In Other Language

    Motherboard Manual APPENDENCIES: SPEC IN OTHER LANGUAGE ERMAN Spezifikationen Sockel AM2 Die AMD 64-Architektur un terstü tzt eine 32-Bit- AMD Ath lon 64 / Ath lon 64 FX / Ath lon 64 X2 / und 64-Bit-Daten verarbeitung Sempron Prozessoren Unterstü tzt Hyper Tran sport und Cool’n’Qu iet Unterstü...
  • Page 33 190 mm (B) X 244 mm (L) ße. Sonderfun k Unterstü tzt RAID 0 / 1 tionen Biostar beh ält sich das Rech t vor, ohne OS-Un terst Windows 2000 / XP / VISTA Ankündigung die Un terstützung für ein ützung...
  • Page 34: France

    Motherboard Manual RANCE SPEC Socket AM2 L'architecture AMD 64 permet le calcul 32 et 64 bits Processeu rs AMD Athlon 64 / Athlon 64 FX / Prend en charge Hyper Tran sport et Cool’n ’Quiet Ath lon 64 X2 / Sempron Prend en charge Hyper T ran sport ju squ'à...
  • Page 35 Fonctionnali tés Prise en charge RAID 0 / 1 spéciales Biostar se réserve le droit d'ajou ter ou de supprimer Support SE Windows 2000 / XP / VISTA le support de SE avec ou san s préavis.
  • Page 36: Italian

    Motherboard Manual T ALIAN SPECIFICA Socket AM2 L’architettura AMD 64 abilita l a computazione Processori AMD Athlon 64 / Athlo n 64 32 e 64 bit FX / Athlon 64 X2 / Sempron Supporto di Hyper Tra nsport e Cool’ n’Quiet Supporto di Hyper Transport fi no a1 GHz di larghezza di banda Chipset...
  • Page 37 190 mm (lar ghezza) x 244 mm scheda (altezza) Caratteristich Supporto RAID 0 / 1 e speciali Sistemi Biostar si riserva il diritto di aggiungere o operativi Windows 2000 / XP / VISTA rimuovere il supporto di qualsiasi sistema supportati operativo se nza pre avviso.
  • Page 38: Spanish

    Motherboard Manual PANISH Especificación La arqu itectu ra AMD 64 permite el procesado de 32 Conector AM2 y 64 bits Procesadores AMD Ath lon 64 / Athlon 64 FX / Soporta las tecnologías Hyper T ran sport y Ath lon 64 X2 / Sempron Cool’n’Qu iet Admite HyperTran sport con un an cho de banda de hasta1 GHz...
  • Page 39 190 mm. (A) X 244 Mm. (H) la placa Funciones Admite RAID 0 / 1 especiales Soporte de Biostar se reserva el derecho de añ adir o retirar el Windows 2000 / XP / VISTA sistema soporte de cualquier SO con o sin aviso previo. operativo...
  • Page 40: Portuguese

    Motherboard Manual ORT UGUESE ESPECIFICAÇÕES A arqu itectu ra AMD 64 permite u ma compu tação de Socket AM2 32 e 64 bits Processadores AMD Ath lon 64 / Ath lon 64 FX Suporta as tecn ologias Hyper Tran sport e / Ath lon 64 X2 / Sempron Cool’n’Qu iet Suporta a tecnologia HyperT ransport com...
  • Page 41 Característi Suporta as funções RAID 0 / 1 especiais Sistemas A Biostar reserva-se o direito de adicionar ou Windows 2000 / XP / VISTA operativos remover suporte para qu alquer sistema operativo suportados com ou sem aviso prévio.
  • Page 42: Polish

    Motherboard Manual OLISH SPEC Socket AM2 Architektu ra AMD 64 umożliwia przetwarzanie 32 i Procesor AMD Ath lon 64 / Athlon 64 FX / Athlon 64 X2 64 bitowe / Sempron Procesory Obsługa Hyper T ransport oraz Cool’n ’Qu iet Obsługa HyperT ran sport o szerokości pasma do1 GHz Chipset...
  • Page 43 190 mm (S) X 244 mm (W) płyty Funkcj e Obsługa RAID 0 / 1 specjaln e Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows 2000 / XP / VISTA odwoływania obsługi dowoln ego systemu operacyjne operacyjnego bez powiadomien ia.
  • Page 44: Russian

    Motherboard Manual USSIAN СПЕЦ Гнездо AM2 Архитектура AMD 64 разрешат ь обработка (центральн ый Процессоры AMD Ath lon 64 / Ath lon 64 FX / данных на 32 и 64 бит процессор) Ath lon 64 X2 / Sempron Поддержка Hyper Tran sport и Cool’n’Qu iet Поддержка...
  • Page 45 190 мм (Ш) X 244 мм (В) Специальн ые технические Поддержка RAID 0 / 1 характери стики Biostar сохран яет за собой право добавлять Поддержка OS Windows 2000 / XP / VISTA или удалять средства обесп ечения для OS с или без предварительного уведомления.
  • Page 46: Arabic

    Motherboard Manual RABIC ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫ﻡﻘﺒﺲ‬AM2 ‫ﺗﻤﻜﻦ ﺗﻘﻨﻴﺔ‬AMD 64 ‫ﺏﺖ‬ ‫و‬ ‫إﺝﺮاء اﻟﻌ ﻤ ﻠﻴﺎت ا ﻟﺤﺎﺳﻮﺏﻴﺔ ﺏﺴ ﺮﻋﺔ‬ AMD Athlon 64 / Athlon 64 FX / ‫ت‬ ‫ﻡﻌ ﺎ ﻟﺠﺎ‬ ‫اﻟﻤ ﺮآ ﺰﻳﺔ‬ ‫اﻟﻤﻌ ﺎ ﻟﺠﺔ‬ ‫وﺣﺪة‬ ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬Hyper T ransport ‫ و‬Cool’n ’Quiet Ath lon 64 X2 / Sempron HyperTran sport 1000 ‫ﺗﺮدد‬...
  • Page 47: Smart Fan

    NF61S-M2 TE ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫ﻋﺪد‬ SATA ‫ﻡﻨﻔﺬ‬ ‫ﻳﺪﻋﻢ آﻞ ﻡﻨﻔﺬ و اﺣﺪ ﻡﻦ أﺝﻬﺰة‬SATA ‫ﻋﺪد‬ ‫ﻡﻨﻔﺬ اﻟﻠﻮﺣﺔ اﻷﻡﺎﻡﻴﺔ‬ ‫ﺗﺠﻬﻴﺰات اﻟﻠﻮﺣﺔ اﻷﻡﺎﻡﻴﺔ‬ ‫ﻳﺪﻋﻢ‬ ‫ﻋﺪد‬ ‫ﻡﻨﻔﺬ اﻟﺼﻮت اﻷﻡﺎﻡﻲ‬ ‫ﻳﺪﻋﻢ وﻇﻴﻔﺔ اﻟﺼﻮت ﺏﺎﻟﻠﻮﺣﺔ اﻷﻡﺎﻡﻴﺔ‬ ‫ﻋﺪد‬ CD-IN ‫ﻡﻨﻔﺬ‬ ‫ﻳﺪﻋﻢ وﻇﻴﻔﺔ دﺥﻞ ﺹﻮت اﻟﻘ ﺮص ا ﻟﻤﺪﻡﺞ‬...
  • Page 48: Japanese

    Motherboard Manual APANESE 仕様 AMD 64アーキテクチャでは、 32 ビットと64 ビット計算が Socket AM2 可能です AMD Ath lon 64 / Athlon 64 FX / Athlon 64 X2 ハイパートランスポートとクールアンドクワイアットをサ / Sempron プロセッサ ポートします 1 GHzのバンド幅までハイパートランスポートを サポートします チップセット GeForce 6100-405 DDR2 DIMMスロット x 2 デュアル チャンネルモードDDR2 メモリモジュール 各DIMMは...
  • Page 49 NF61S-M2 TE 仕様 SATAコネクタ 各コネクタは1 つのSATAデバイスをサポートします フロントパネルコネクタ フロントパネル機能をサポートします フロントオーディオコネクタ フロントパネルオーディオ機能をサポートします CDインコネクタ CDオーディオイン機能をサポートします S/PDIFアウトコネクタ デジタルオーディオアウト機能をサポートします CPUファンヘッダ CPUファン電源装置(スマートファン機能を搭載) システムファンヘッダ システムファン電源装置 CMOSクリアヘッダ 各コネクタは2 つのフロントパネルUSBポートをサポート USBコネクタ します プリンタポートコネクタ 各コネクタは1 つのプリンタポートをサポートします 電源コネクタ(24 ピン) 電源コネクタ(4 ピン) PS/2 キーボード PS/2 マウス シリアルポート 背面パネル VGAポート LANポート USBポート オーディオジャック...
