NETGEAR R4500 Installation Manual

N900 Wireless Dual Band Gigabit Router
R4500
Package Contents
Ethernet cable
Power adapter
N900 Wireless Router
(with stand attached)
Power cord
Step 1:
Installation Guide
Unplug the power
to turn off your modem.
Internet
Step 4:
Connect the power adapter to the
router, then plug it into an outlet.
Wait for the 2.4 GHz LED (
to turn on.
If none of the LEDs turn on, make sure the
Power On/Off button is in the ON position
(pushed in).
Step 2:
Connect one end of the yellow
Ethernet cable (
and the other end to the Internet port
on your router.
DSL
or Cable
Power On/Off
Modem
)
2.4
GHz
Step 3:
Plug in, then turn on your modem.
) to your modem,
Wait approximately 2 minutes
until your modem turns on.
If your modem has a battery backup,
first remove and reinsert the battery
before connecting your
modem to power.
(not included)
Power On/Off
N900 Wireless Router
Step 5:
Connect your computer
to the router ( ).
Use another Ethernet cable to establish
a wired connection as shown in this diagram.
Optionally, connect wirelessly by using
the preset wireless security settings
located on the bottom label.
Laptop or Desktop
Computer
Step 6:
Open a browser.
If the web page does not
display, close and re-open
the browser, then enter
http://www.routerlogin.net
in the address bar, or
check the "Troubleshooting"
section on the back of
this installation guide.
