Related Manuals for TANDBERG MOVI 4.0 - ADMINISTRATOR GUIDE 09-2010
Summary of Contents for TANDBERG MOVI 4.0 - ADMINISTRATOR GUIDE 09-2010
-
Page 1: Administrator Guide
Movi version 4.0 Administrator guide Software version 4.0.1.8289 D14410.06 September 2010... -
Page 2: Table Of Contents
Signing in ................................. 16 Subscribing to the VCS ..........................16 Registering to the VCS ..........................16 When Movi is registered to the VCS ........................ 16 Presence..............................16 SIP keep alive ............................17 TANDBERG Movi Administrator guide Page 2 of 22... - Page 3 Automatic bandwidth adaptation ......................19 Automatic CPU adaptation ........................19 Conference information ..........................20 Checking for updates and getting help ..................21 References and related documents ................... 22 Disclaimers and notices ......................22 TANDBERG Movi Administrator guide Page 3 of 22...
-
Page 4: Introduction
This guide provides comprehensive information on Movi, its capabilities and functions. Movi works in conjunction with other TANDBERG infrastructure products, primarily the Video Communication Server (VCS), TANDBERG Management Suite (TMS) and the TMS Agent, which handles provisioning. It is assumed that the reader is familiar with these products. -
Page 5: Multimedia Device Requirements
All microphones work with Movi. Note that some cameras have built-in microphones. Camera Movi works with most common web cameras. Built-in Apple iSight cameras are supported by Movi. For more information, see the Knowledge Base article: What cameras have been tested with Movi? TANDBERG Movi Administrator guide Page 5 of 22... -
Page 6: Deploying And Upgrading Movi
Release notes document. Configuring the client This section describes and recommends configuration settings. TANDBERG recommends that you create an installation file that will install Movi with the Advanced settings pre-configured; see the section Pre- configuring the Movi client below. -
Page 7: Pre-Configuring The Movi Client
Corresponds to Internal VCS in Movi’s Advanced settings. A value of 1 hides the Advanced settings link in the Movi client HIDEADVANCEDLOGIN sign-in screen. TANDBERG recommends using this setting so that end users will not be able to make changes to the Advanced settings... -
Page 8: Movi For Mac Pre-Settings
For information on how to disable authentication on the VCS and TMS Agent, contact your TANDBERG support agent. The MoviSetup.exe file supplied by TANDBERG is a basic InstallShield-generated installer. MoviSetup.exe can be run with standard InstallShield arguments, such as ... -
Page 9: New Deployment
Software URL. Uninstalling Uninstalling the client will remove all client-related files and folders including registry files and logs. Note: TANDBERG recommends backing up information files, such as registry files and logs, prior to uninstalling. File locations Contact information Contacts and recent call information are saved per Movi login name on Windows, and per system login name on Mac OS X. -
Page 10: Provisioning The Client
Movi is deployed in completed, if ICE fails or environments where most if the remote side does other endpoints do not not understand ICE. The understand ICE. See the available options are: Enabling ICE section. TANDBERG Movi Administrator guide Page 10 of 22... - Page 11 384 kbps With no provisioning, the Bandwidth (adjustable to up default starting level is to 2014 kbps lower than the maximum from within the that can be set by the client) user. TANDBERG Movi Administrator guide Page 11 of 22...
- Page 12 VCS indicated by the External VCS field in the Movi Advanced settings. Public Presence Uses value set Enables the account to It is sufficient to set the TANDBERG Movi Administrator guide Page 12 of 22...
- Page 13 TURN server settings See the Enabling ICE section. that are required for TurnAuthUsername enabling ICE. These settings are only TurnServer available in TMS 12.6 or later after uploading the MoviProvisioningConfigTempl ate.xml file. TANDBERG Movi Administrator guide Page 13 of 22...
-
Page 14: How Movi Communicates
Note that in both cases, the port numbers used will be consecutive, but chosen randomly within the specified range. Media routing Movi 4.0 supports Interactive Connectivity Establishment (ICE) for better media routing. ICE is used if enabled both in Movi and the far end. TANDBERG Movi Administrator guide Page 14 of 22... -
Page 15: Media Routing Without Ice
Set TurnServer to the address of the server through which media is relayed in an “ICE call”. Typically, the address of the VCS Expressway. Note: The ICE Provisioning configurations are not available by default. See the Uploading Movi 4.0 Provisioning options to the TMS section for more information. TANDBERG Movi Administrator guide Page 15 of 22... -
Page 16: Running Movi
In Applications > Presence there are two settings that determine timeouts for the Presence server: Subscription expiration time Publication expiration time Movi will subscribe and publish when 75% of the specified time intervals have elapsed. TANDBERG Movi Administrator guide Page 16 of 22... -
Page 17: Sip Keep Alive
Auto means the Movi client will try to communicate using TLS and encrypt the calls, but if not possible, TCP communication and unencrypted calls are allowed. The default behavior is Auto. TANDBERG Movi Administrator guide Page 17 of 22... -
Page 18: Sent And Received Bandwidth
Movi knows about the network and the far end SIP URI, a ”safe” initial bandwidth is chosen. The database file is called bitratehistory.xml and resides in the Windows user profile: Windows XP: %userprofile%\Local Settings\Application Data\TANDBERG\Movi\2.0 Windows Vista and Windows 7: %userprofile%\AppData\Local\TANDBERG\Movi\2.0 Note: This feature is not available in Movi for Mac. Resolution High image resolution is not the only factor linked to high video quality. -
Page 19: Video
If Movi is responsible for less than 90% of the CPU usage: Movi displays a warning asking the user to close other applications. If Movi is responsible for 90% or more of the CPU usage: Movi lowers the resolution for outgoing video. TANDBERG Movi Administrator guide Page 19 of 22... -
Page 20: Conference Information
The transmit jitter information is based on RTCP reports from the far end. High jitter affects the call quality and is usually indicative of poor network conditions. TANDBERG Movi Administrator guide Page 20 of 22... -
Page 21: Checking For Updates And Getting Help
If the documentation does not answer your question or you have a problem with one of our products, refer to the Support sections of the web site which are kept up to date with the latest information from TANDBERG > Support). -
Page 22: References And Related Documents
The objective of this documentation is to provide the reader with assistance in using and configuring the product. The specifications for the product and the information in this Guide are subject to change at any time, without notice, by TANDBERG. Every effort has been made to supply complete and accurate information in this Guide;...
