Installing The Fpr-100 Software; Arinterdding Arinter Printer - ACR Electronics FPR-100 PROGRAMMER Product Support Manual

· A hard disk with at least 10 megabytes of available storage.
· VGA or higher-resolution screen supported by Microsoft Windows.
· 16 megabytes of RAM.
· A mouse or other pointing device.
· 1 available serial port.
Printer (optional)
·
4.0

INSTALLING THE FPR-100 SOFTWARE

The FPR-100 software is installed using the setup program included on disk 1. The setup
program will install all of the needed files to your hard disk automatically. The software
must be installed in the C:\FPR100 directory to work correctly. This directory is the
default directory in the setup program.
1. Place the disk marked 1 of 4 into the floppy drive of your computer.
2. Click the START button on the bottom of your Windows operating system.
3. Type "a:\setup.exe" without the quotation marks and press ENTER.
4. Choose the RUN option from the menu.
5. Follow the installation directions on the screen. The FPR-100 must be installed in the
"C:\Fpr100\" directory. This directory is already set when you run the setup
program.
6. If you purchased the FPR-100 with the laptop computer, please refer to section 4.1 to
set up your printer for use with the system.
4.1 Adding a Printer
1. Click the START button on the bottom of your Windows operating system.
2. Click the Settings option on the pop up menu.
3. Click the Printers option on the Settings menu.
4. From the Printers box that appears click Add Printer and follow the instructions. If
you are using a computer purchased from ACR Electronics and you are asked for the
Windows disk do the following.
A. When you get the message "Please insert the disk labeled 'Windows 95 CD-
ROM' and then click OK" click the OK button.
B. There will then be an input box with the title Copying Files... In the space
provided
C:\Windows\Options\cabs then press ENTER.
C. If this does not work or if the computer cannot identify your printer, contact the
printer manufacturer for more information.
5. The printer setup as your default printer will be used by the FPR-100 for printing
labels and reports.
under the Copy files from: text
4
type the following:
Y1-03-0149 Rev. D
