MINOURA BIKE TOWER 5 Manual

Thank you for purchasing Minoura BIKE TOWER 5 .
This is the bike storage stand which can hold 2 bikes on its cradle hook at two different heights. If you add 2
more optional cradles behind the pole, you can hold up to 4 bikes on a pole.
The main pole is fully adjustable from 1.7 meter (5' 7") to 3.1 meter (10' 2") between the floor and the ceiling of
your room. And the top rubber cup is spring loaded so you can install BIKE TOWER 5 at anywhere you need
without any tool.
IMPORTANT NOTES
• Please read this instructions manual carefully before use.
• BIKE TOWER is the storage stand for ordinary 2-wheel bicycles only. Do NOT use it
for any other purposes, for example, displaying heavy electric bikes or tandem bikes,
attaching wall panel or using the pole horizontally to hook down the bikes.
• BIKE TOWER is installed between the floor and ceiling using a strong spring and the
tension this provides. BIKE TOWER must be installed firmly on a solid floor and ceiling
using a supporting beam or load bearing area of the ceiling. Failure to do so may cause
damage to your ceiling, bikes, BIKE TOWER, and may cause personal injury.
!
Set BIKE TOWER firmly
against a supporting beam
or load bearing area of the
ceiling.
Failure to do so will cause
damage to your ceiling.
!
When setting the main telescoping
pole, make sure to extend it until the
red warning sign no longer shows.
The warning sign is located just
below the upper rubber cup.
BIKE TOWER 5 instructions manual
Ceiling Supporting Beam
Ceiling
Panel
Red Warning Sign
- Page 1 -
!
Set the BIKE TOWER up vertically
from floor to ceiling. Make sure
the BIKE TOWER is not slanted.
Slanted installation may cause the
BIKE TOWER to fall down, causing
damage and/or injury.
