1 Desktop Board Features

This chapter briefly describes the main features of Intel
Table 1 summarizes the features of the Desktop Board.
Table 1. Feature Summary
Form Factor
Processor
Main Memory
Chipset
Graphics
Audio
Expansion
Capabilities
Peripheral
Interfaces
BIOS
LAN Support
Power Management
Supported
Operating Systems
For more information about Desktop Board D945GCLF, including the Technical Product
Specification (TPS), BIOS updates, and device drivers, go to
http://support.intel.com/support/motherboards/desktop/.
Mini-ITX (171.45 millimeters [6.75 inches] x 171.45 millimeters
[6.75 inches])
® ™
Intel Atom processor 230
• One 240-pin SDRAM Dual Inline Memory Module (DIMM) socket
• 533 MHz single channel DDR2 SDRAM interface
• Supports up to 2 GB of system memory
®
Intel 945GC Express Chipset consisting of:
®
• Intel 82945GC Express Chipset Graphics and Memory Controller Hub
(GMCH)
®
• Intel 82801GB I/O Controller Hub (ICH7)
®
Intel 945GC Express Chipset with Intel
®
(Intel GMA 950)
• RealTek* ALC662 audio codec
®
• Support for Intel High Definition Audio
• Support for 4-channel audio (two independent 2-channel audio streams)
One PCI* bus add-in card connector
• Up to six USB 2.0 ports
― Four ports routed to the back panel
― Two ports routed to an onboard USB header
• One IDE interface with ATA-100/66 support (two devices)
• Two Serial ATA (3.0 Gb/s) interfaces
• One VGA connector
• One parallel port
• One serial port
• PS/2* keyboard and mouse ports
®
• Intel BIOS
• Support for SMBIOS
®
• Intel Rapid BIOS Boot
®
• Intel Express BIOS Update
• 10/100 Mb/s LAN Subsystem
• Support for Advanced Configuration and Power Interface (ACPI)
• Wake on USB, PCI, PS/2, LAN, and front panel
• Microsoft Windows Vista* Home Basic Edition
• Microsoft Windows Vista Home Basic 64-bit Edition
• Microsoft Windows* XP Professional
• Microsoft Windows XP Professional x64 Edition
• Microsoft Windows XP Home
®
Desktop Board D945GCLF.
®
Graphics Media Accelerator 950
