Vizio VSB206 Quick Start Manual

Home theater 32” sound bar
Hide thumbs Also See for VSB206:

Advertisement

Table of Contents

VIZIO

HOME THEATER

32" SOUND BAR
MODEL VSB206
QUICK START GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Vizio VSB206

Summary of Contents for Vizio VSB206

  • Page 1: Home Theater

    VIZIO HOME THEATER 32” SOUND BAR MODEL VSB206 QUICK START GUIDE...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your Sound Bar is designed and manufactured to operate within defined design limits, and of electric shock to persons. misuse may result in electric shock or fire. To prevent your Sound Bar from being damaged, • The exclamation point within an equilateral triangle is intended to alert the the following rules should be observed for its installation, use, and maintenance.

  • Page 3: Package Contents

    PACKAGE CONTENTS 32” Home Theater Sound Bar Power Adapter Stereo RCA to 3.5mm Audio Cable This Quick Start Guide Remote Control with Battery...

  • Page 4: Controls And Connections

    CONTROLS & CONNECTIONS Power Volume Up Press to turn on or Press to increase off. system volume. Input Vol - Vol + Input Volume Down Press to change input Press to decrease source (Input 1, Input 2). system volume. Sub Out Input 1 Input 2 BACK...

  • Page 5: First Time Setup

    FIRST-TIME SETUP Sub Out Input 1 Input 2 BACK OF SOUND BAR Connect the included Stereo RCA to 3.5mm Cable to ONE TV audio output as shown. CHOOSE ONE OPTIONAL: For extra bass, AUDIO OUT AUDIO OUT connect an RCA cable (not included) to an external subwoofer.
  • Page 6 Sub Out Input 1 Input 2 Sub Out Input 1 Input 2...
  • Page 7 Gently pull the plastic tab from the back of the remote control. (The plastic tab can be thrown away.) Turn your TV on, then press the Power button MUTE on the remote to turn the Sound Bar on. Power Press the Input button to switch between the MUTE Input 1 and Input 2 audio sources.

  • Page 8: Using The Remote

    USING THE REMOTE Power Volume Up Press to turn on or off. Press to increase volume. SUB - SUB + Press to decrease Press to increase subwoofer volume. subwoofer volume. MUTE Mute Volume Down Press to mute/unmute. Press to decrease volume. There is no sound when muted.

  • Page 9: Wall Mounting The Sound Bar

    WALL MOUNTING THE SOUND BAR Remove the screw from the Sound Bar stands and rotate as shown. 22 11/16” (58.26 cm) Be sure your screws are attached to wood studs or drywall anchors (for drywall) or concrete anchors (for brick/concrete walls). Reattach stands using the If you are unfamiliar with power tools or the layout of electrical wiring in the walls of your home, consult a professional installer.
  • Page 10 HELP & TROUBLESHOOTING LET US HELP! YOUR PRODUCT INCLUDES FREE LIFETIME TECH SUPPORT The VIZIO support team is highly trained and is based in the United States. We can help with: • Product Setup • Technical Problems • Warranty Questions • And More...
  • Page 11 • Press the POWER button on the remote control or on the top of your Sound Bar. • Ensure the power cord is securely connected. There is no power. • Ensure the light on the power adapter is glowing green. • Plug a different device into the electrical outlet to verify that the outlet is working correctly. • Increase the volume. Press Volume Up on the remote control or on the top of your Sound Bar. • Press MUTE on the remote to ensure the Sound Bar is not muted. • Press INPUT on the remote or on the top of your Sound Bar to select a different input source.

  • Page 12: Vizio Recommends

    VIZIO RECOMMENDS Complete your home theater experience! The VIZIO Blu-ray Player with Wireless Internet Apps delivers full 1080p HD video, 7.1 surround sound and has built-in 802.11n dual-band wireless for easy access to movies, TV shows, music and more from the Internet.
  • Page 13 AVAILABLE AT VIZIO.COM Keep entertainment freedom at your fingertips – it’s your movies, TV shows, and music in a thin, ultralight design. Stay ahead of the game with essential apps like email, calendar, and news. Part of the VIZIO Internet Apps® Plus ecosystem, the VIZIO Tablet redefines entertainment with more choice, more fun, more freedom for all. • Elegant, Easy-to-Use VIZIO Internet Apps Plus User Interface • 802.11n WiFi for High-Speed Wireless Internet...

  • Page 14: One-Year Limited Warranty

    Type of Service Defective Products must be sent to a VIZIO service center to obtain warranty service. VIZIO is not responsible for transportation costs to the service center, but VIZIO will cover return shipping to the customer. PRE-AUTHORIZATION IS REQUIRED BEFORE SENDING ANY PRODUCT TO A VIZIO SERVICE CENTER FOR WARRANTY SERVICE.

  • Page 15: Legal & Compliance

    LEGAL & COMPLIANCE FCC Class B Radio Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 16 © 2011 VIZIO INC. ALL RIGHTS RESERVED. 110215ST-NC...
