Dodge 2008 Viper Owner's Manual

Dodge 2008 viper automobile owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Viper
2 0 0 8
O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading

Related Manuals for Dodge 2008 Viper

Summary of Contents for Dodge 2008 Viper

  • Page 1 Viper 2 0 0 8 O W N E R ’ S M A N U A L...

  • Page 2: Introduction 3

    TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 4 CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .

  • Page 5: Introduction

    4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
  • Page 6 INTRODUCTION 5...

  • Page 7: Warnings And Cautions

    The vehicle identification number (VIN) is on the left front corner of the instrument panel. The VIN is visible from outside the vehicle through the windshield. This number also appears on the Automobile Information Vehicle Identification Number Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove the VIN.

  • Page 8: Vehicle Modifications / Alterations

    INTRODUCTION 7 VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.

  • Page 10: Table Of Contents

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder .
  • Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Door Locks ......23 Manual Door Lock .....24 Power Door Locks .

  • Page 12: Safety Checks You Should Make Inside

    Break-In Recommendations ....56 Safety Tips ......57 Exhaust Gas .

  • Page 13: Things To Know Before Starting Your Vehicle 9

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS You can insert the double-sided keys into the locks with either side up. The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer or a locksmith.

  • Page 14: Key-In-Ignition Reminder

    NOTE: The Power Accessory Delay feature allows you to operate the radio and the power windows for 2 minutes after turning off the ignition switch. Removing the key from the ignition switch and opening the driver’s door will cancel this feature. Your dealership can enable or disable the Power Accessory Delay feature as desired.
  • Page 15 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Keyless Entry (RKE) transmitter. After the last door is closed, or if all doors are closed, the system will arm itself in approximately 16 seconds. During the arming process, the Vehicle Security Alarm Indicator light will flash at a fast rate.

  • Page 16: To Disarm The System

    Press the Trunk button on the RKE transmitter to allow access without triggering the alarm or having to disarm the system. The trunk lid will pop open. Entering the liftgate with the System Armed — Coupe: NOTE: Using the key to open the liftgate while the system armed will trigger the alarm.

  • Page 17: Illuminated Entry System

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Press the UNLOCK button on the RKE transmitter. The front and rear park lights and the turn signal lights will flash to acknowledge the signal. NOTE: The vehicle will not start unless the Vehicle Security Alarm System is disarmed by either method.

  • Page 18: Remote Keyless Entry

    REMOTE KEYLESS ENTRY This system allows you to lock or unlock the doors, open the trunk/liftgate, or activate the panic alarm from distances up to about 23 feet (7 meters) using a hand held radio transmitter. The transmitter need not be pointed at the vehicle to activate the system.

  • Page 19: To Lock The Doors

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Repeat these steps if you want to return this feature to its previous setting. NOTE: Pressing the LOCK button on the transmitter while you are in the vehicle will activate the Security Alarm.

  • Page 20: To Unlatch The Trunk/Liftgate

    Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the transmitter. This feature can be turned on or turned off. To change the current setting, proceed as follows: 1. Press the LOCK button on a programmed transmitter for at least 4 seconds, but no longer then 10 seconds.

  • Page 21: Programming Additional Transmitters

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ON/RUN position. If not deactivated through the trans- mitter or the ignition switch, the alarm will turn off automatically after 3 minutes. Programming Additional Transmitters NOTE: You must have at least one programmed trans- mitter to perform this procedure.

  • Page 22: Battery Replacement

    Battery Replacement The recommended replacement battery is 2016. This is a generic battery, readily available at local retail stores. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. • Do not touch the battery terminals that are on the back housing or the printed circuit board.

  • Page 23: General Information

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Remove and replace the battery. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. To assemble the transmitter case, snap the two halves together.

  • Page 24: Things To Know Before Starting Your Vehicle 23

    DOOR LOCKS WARNING! Do not touch the exhaust pipe sill covers when entering or exiting your Viper. They can be hot enough to burn you. Observe the warning labels on each door closure panel. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 WARNING! •...

  • Page 25: Manual Door Lock

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Manual Door Lock The driver’s door can be locked or unlocked with the key. The door lock is located on the outside door panel beneath the mirror. Mechanical Door Lock Power Door Locks A power door lock switch is on each door trim panel.
  • Page 26 Electronic Door Lock This vehicle is equipped with a virtual lock system. Input from the outside door handle is ignored if the vehicle is virtually locked. Door Lock Messaging The words “DOOR UNLOCKED” will flash in the odom- eter if one door is unlocked or will remain on steadily if both doors are unlocked.

  • Page 27: Windows

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows The power window switches are located between the driver and passenger seats on the center tunnel bezel, just to the left of the parking brake. The switch on the left side controls the driver’s window and the switch on the right controls the passenger’s window.

  • Page 28: Auto Down Feature

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Auto Down Feature Both windows have an auto down feature. Press the window switch to the second detent, release, and the window will go down automatically. Press the switch a second time in either direction to stop the window. To open the window to a desired position, press and hold the window switch in the first detent.

  • Page 29: Liftgate - Coupe Models Only

    28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LIFTGATE — COUPE MODELS ONLY The liftgate can be unlocked or locked by the Remote Keyless Entry (RKE) transmitter or by activating either of the power door lock switches located on the door trim panels.

  • Page 30: Trunk Lock And Release - Convertible Models Only

    WARNING! • Driving with the liftgate open can allow poison- ous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle. • If you are required to drive with the liftgate open, make sure that all windows are closed, and the climate control blower switch is set at high speed.

  • Page 31: Trunk Safety Warning - Convertible Models Only

    30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Gas props support the trunk lid in the open position. However, because the gas pressure drops with temperature, it may be necessary to assist the props when opening the trunk lid in cold weather. TRUNK SAFETY WARNING —...

  • Page 32: Occupant Restraints

    OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the seat belts and the airbags for the driver and passenger. Please pay close attention to the information in this section. It explains how to use your restraint system properly to keep you and your passenger as safe as possible.
  • Page 33 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be injured seriously or killed. •...
  • Page 34 3. Slide the latch plate up the webbing as far as necessary to make the belt go around your lap. 4. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle (Convertible Shown) THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 WARNING!
  • Page 35 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up a little on the shoulder belt, as shown. Removing Slack From Belt (Convertible Shown) 6.

  • Page 36: Lap/Shoulder Belt Untwisting Procedure

    8. To release the belt, push the red button in the buckle. The belt will retract automatically to its stowed position. If necessary, slide the latch plate down the webbing to allow it to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.

  • Page 37: Enhanced Seat Belt Reminder System (Beltalert )

    36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Seat Belt Reminder System (BeltAlert ) If the driver does not buckle their seat belt and vehicle speed exceeds 5 mph (8 km/h), or if the passenger does not buckle their seat belt within 10 seconds of vehicle speed exceeding 5 mph (8 km/h), the Enhanced Warning System (Belt Alert) will alert the occupant(s) to buckle their seat belt(s).

  • Page 38: Automatic Locking Mode

    NOTE: Watch for the Seat Belt Reminder light to turn on while unbuckling the seat belt and turn off while re- buckling the seat belt. It may be necessary to retract the seat belt. 6. Turn the ignition switch to the OFF/LOCK position. A single chime will sound to signify that you have com- pleted the programming successfully.

  • Page 39: Six-Point Belt System - If Equipped

    38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Once the belt is in automatic locking mode, you will not be able to pull any more of the webbing out of the retractor. In this mode, you will only be able to retract excess webbing into the retractor to secure the child restraint.

  • Page 40: Seat Belts And Pregnant Women

    Seat Belts and Pregnant Women We recommend that pregnant women use the seat belts throughout their pregnancy. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap portion of the belt across the thighs and as snug across the hips as possible.

  • Page 41: Driver And Passenger Supplemental Restraint System (Srs) - Airbag

    40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Driver and Passenger Supplemental Restraint System (SRS) - Airbag This vehicle is equipped with airbags for the driver and passenger as a supplement to the seat belt restraint systems. The driver airbag is mounted in the steering wheel.
  • Page 42 The airbags work with the instrument panel knee bolsters and the seat belts to provide improved protection for the driver and passenger. While the seat belts are designed to protect the driver and passenger in many types of collisions, the airbags will deploy in moderate to severe frontal collisions.
  • Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Never allow a child to place the shoulder belt behind them or under the arm. 6. Never allow a child to lean forward toward the instrument panel as a passenger airbag deployment could cause severe injury or death to a child in this position.
  • Page 44 • Steering Wheel and Column • Instrument Panel • Seat Track Position Sensors • Interconnecting Wiring • Seat Belt Reminder Light • Knee Impact Bolsters • Front Acceleration Sensors • Passenger Seat Occupant Classification System (OCS) − Occupant Classification Module (OCM) −...
  • Page 45 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The ORC turns on the Airbag warning light and Passenger Airbag Disable (PAD) indica- tor light for 6 to 8 seconds as a self-check when the ignition is first turned on. After the self-check, the Airbag warning light will turn off and the PAD indicator light will function normally (Refer to “Passenger Airbag Disable (PAD) Indicator Light”...
  • Page 46 • The Knee Impact Bolsters help protect the knees of the driver and the passenger, and position everyone for the best interaction with the airbags. • The Occupant Classification Module (OCM) is lo- cated underneath the passenger seat. The OCM uses input from the Flex Mat to classify the occupant in the passenger seat into a size category.
  • Page 47 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE who is seated properly in the passenger seat. The driver and passenger should always use the PAD indicator light as an indication that the passenger is positioned properly in their seat. If the PAD indicator light comes on when an adult or teenager is in the passenger seat, have the passenger reposition their self in the seat until the light goes out.
  • Page 48 may not classify the occupant properly. Furthermore, objects lodged under the seat can prevent the occu- pant’s weight from being measured properly and may result in the occupant being classified improperly. The passenger seat assembly contains critical compo- nents that affect passenger airbag deployment. Correctly functioning passenger seat components are critical for the OCS to classify the passenger properly and calculate the proper airbag deployment.
  • Page 49 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Unapproved modifications or service procedures to the passenger seat assembly, its related components, or seat cover may inadvertently change the airbag deployment in case of a frontal crash. This could result in death or serious injury to the passenger if the vehicle is involved in an accident.
  • Page 50 for airbag inflation. These airborne particles may irri- tate the skin, eyes, nose, or throat. If you have skin or eye irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air. If the irritation continues, see your doctor.

  • Page 51: Child Restraint

    50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. Airbag Warning Light You will want to have the airbags ready for your protection in a collision. While the airbag system is designed to be maintenance free, if any of the following occurs, have an autho- rized dealer service the system immediately: •...
  • Page 52 There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat Owner’s Manual to ensure you have the correct seat for your child. Use the restraint that is correct for your child: Infant and Child Restraints •...
  • Page 53 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year. These child seats are also held in the vehicle by the lap/shoulder belt. The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly.
  • Page 54 Here are some tips on getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. We also recommend that you make sure that you can install the child restraint in the vehicle where you will use it before you buy it.
  • Page 55 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Remove the child tether access cover by prying either side with a screwdriver or similar tool, as shown. Child Tether Access Cover NOTE: While the child tether is in use, keep the access cover in a safe place so that it can be replaced after use of the child tether.
  • Page 56 7. Return the seatback to an upright position. 8. Install the child restraint according to the manufactur- er’s directions. 9. Remove slack from the tether strap according to the child restraint manufacturer’s directions. WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.

  • Page 57: 56 Things To Know Before Starting Your Vehicle

    56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Tighten the lap portion of the belt and allow the excess webbing to retract back to the retractor. If it still does not make the child restraint secure, then secure the child restraint with the Child Restraint Tether Anchor.

  • Page 58: Safety Tips

    • Avoid excessive idling. • Check the engine oil level at every fuel fill. NOTE: A new engine will consume some oil during the first few thousand miles of operation. This should be considered as a normal part of the break-in and not interpreted as a sign of difficulty.
  • Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow the safety tips below.

  • Page 60: The Vehicle

    Periodic Safety Checks You Should Make Outside The Vehicle Tires Examine tires for excessive tread wear or uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and side wall for cuts and cracks. Check the wheel nuts for tightness. Check the tires for proper pressure.
  • Page 62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Convertible Top Operation — Convertible Models Only ......63 To Lower The Top .
  • Page 63 62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Running Lights ....82 Lights-On Reminder ....82 Battery Saver Feature —...

  • Page 64: Convertible Top Operation - Convertible Models Only

    CONVERTIBLE TOP OPERATION — CONVERTIBLE MODELS ONLY WARNING! The convertible top does not provide the structural protection that a reinforced metal roof does, and the fabric top cannot be expected to prevent the ejection of the occupants of a vehicle in a collision. Therefore, it is important that all occupants wear their seat belts at all times when riding in a convertible.

  • Page 65: To Raise The Top

    64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Depress the button located at the top of the latch and then pull the latch handle downward and rearward. Unlatching Convertible Top 4. Disengage the latch hook from the windshield receiver rod and then pull the latch all the way back to the detent stow position.
  • Page 66 4. Press downward on the convertible top and then press the lever behind the driver seat to release the downstack latch. Convertible Top Latch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 65 5. Manually raise the convertible top until it meets the windshield header.
  • Page 67 66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7. From inside the vehicle, grasp the handles and pull the convertible top toward the windshield header. Then, push the latch handle forward so that the latch hook engages the windshield receiver rod. Aligning Convertible Top 8.

  • Page 68: Convertible Top Boot Cover Installation - If Equipped

    NOTE: Until the convertible top system has had ad- equate time to break-in, it may take a greater effort to engage the latch hook and close the latch. However, several weeks of normal convertible top usage will reduce these efforts. 9.
  • Page 69 68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Slide the boot cover pocket over the front corner of the convertible top on the driver side of the vehicle. Then, stretch and slide the boot cover pocket over the front corner of the convertible top on the passenger side of the vehicle.
  • Page 70 6. On the passenger side of the vehicle, clip the tab under the trunk lid stop and on the outer edge of the quarter panel flange. Attaching Passenger Side Tab UNDERSTANDING THE FEATURES OF YOUR VEHICLE 69 7. Push downward on the boot cover pocket to engage the inboard tab.
  • Page 71 70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 8. On the driver side of the vehicle, clip the tab under the trunk lid stop and on the outer edge of the quarter panel flange. Attaching Driver Side Tab 9. Push downward on the boot cover pocket to engage the inboard tab.
  • Page 72 11. Stretch and smooth out the boot cover from the rear of vehicle. Stretching and Smoothing Cover 12. Close the trunk. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 71 13. Ensure that the forward edge of the boot cover is tucked in fully. Forward Edge...

  • Page 73: Convertible Top Boot Cover Removal And Storage

    72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Convertible Top Boot Cover Removal and Storage 1. Open the trunk. 2. On the driver side of the vehicle, pull upward on the boot cover to disengage the inboard tab. Disengaging Driver Side Tab 3.
  • Page 74 4. On the passenger side of the vehicle, pull upward on the boot cover to disengage the inboard tab. Disengaging Passenger Side Tab UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73 5. Unclip the tab under the trunk lid stop and on the outer edge of the quarter panel flange.
  • Page 75 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7. Fold the outer edges of the boot cover inward. Folding Outer Edges 8. Fold the boot cover again. Folding Boot Cover 9. Place the boot cover into the bag and store it in the trunk or a secure dry area.

  • Page 76: Mirrors

    MIRRORS Inside Day/Night Mirror Adjust the mirror to center on the view through the rear window. A pivot system allows for horizontal and verti- cal mirror adjustment. Adjusting Rearview Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75 Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).

  • Page 77: Power Remote Control Mirrors

    76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object.

  • Page 78: Seats

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77 NOTE: When not in use, return the power mirror switch to the neutral (off) position to prevent accidental mirror movement. SEATS Manual Seat Adjustments Forward & Rearward Adjustment The adjusting bar is at the front of the seat, near the floor. Pull the bar upward to move the seat forward or rear- ward.
  • Page 79 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.

  • Page 80: To Open And Close The Hood

    TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. First, reach into the lower right grille opening and pull the primary hood latch forward. Hood Release Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 Next, raise the front of the hood slightly and push the safety catch handle to the right.
  • Page 81 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Assist props will raise the hood to a normal usage position. If greater access is required, the hood may be pushed up at the front, raising the hood beyond the initial opening height. CAUTION! Do not leave the hood open in areas where strong gusts of wind are likely.

  • Page 82: Lights

    LIGHTS Exterior & Interior Lighting Control The Multi-Function Lever on the left side of the steering column controls the operation of the headlights, parking lights, turn signal lights, front fog lights, instrument panel lights, and interior lights. Multi-Function Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 Headlights &...

  • Page 83: Daytime Running Lights

    82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This feature can be disabled at the dealership, if so desired. Daytime Running Lights The fog lights will come on as Daytime Running Lights, whenever the ignition switch is on, the headlights are off, and the parking brake is off.

  • Page 84: Highbeam/Lowbeam Select Switch

    Turn Signal Control You can also signal a lane change by moving the lever partially upward or downward without moving beyond the detent. The turn signals will continue to operate until you release the lever. If either light has a very fast flash rate, check for a defective outside light bulb.

  • Page 85: Flash To Pass

    84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash to Pass You can signal another vehicle with your headlights by lightly pulling the Multi-Function Lever toward you. This will cause the headlights to turn on at high beam and remain on until the lever is released. Interior Lights The interior lights will turn on whenever a door is opened or the liftgate is opened (Coupe models) and the...
  • Page 86 Courtesy/Reading Light Switches Courtesy lights are also found in the driver’s foot well, the passenger’s foot well, and in the liftgate on Coupe models. You can turn this light on and off from the dimmer control in the Multi-Function Lever. This light is also controlled automatically by the illuminated entry system.
  • Page 87 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Instrument Panel Dimming With the parking lights or headlights on, rotate the dimmer control upward to increase the brightness of the instru- ment panel lights or rotate it down- ward to decrease the brightness of the instrument panel lights.

  • Page 88: Windshield Wipers And Washers

    WINDSHIELD WIPERS AND WASHERS The Windshield Wiper/Washer Control Lever is on the right side of the steering column. Windshield Wiper/Washer UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 From the “OFF” position, push the Windshield Wiper/ Washer Control Lever upward to the first detent past the intermittent “DEL”...

  • Page 89: Mist Feature

    88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the Windshield Wiper/Washer Control Lever upward to the first detent “DEL” position, and then rotate the end of the lever to select the desired delay interval. There are seven delay settings, which allow you to regulate the wipe interval from a minimum of one cycle every second to a maximum of approximately 15 seconds between cycles.

  • Page 90: Adding Washer Fluid

    Adding Washer Fluid The windshield washer fluid reservoir is located in the front of the engine compartment on the passenger side of the vehicle. Be sure to check the fluid level in the reservoir at regular intervals. Fill the reservoir with windshield washer solvent (not radiator antifreeze) and operate the system for a few seconds to flush out the residual water.

  • Page 91: Adjustable Pedals

    90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Tilting the steering column while the vehicle is moving is dangerous. Without a stable steering col- umn, you could lose control of the vehicle and have an accident. Adjust the column only while the ve- hicle is stopped.
  • Page 92 To adjust the pedals: 1. Adjust the seat and steering column to a comfortable position. 2. Either press the adjustable pedal switch forward to move the pedals forward (toward the front of the ve- hicle), or pull the switch rearward to move the pedals rearward (toward the rear of the vehicle).

  • Page 93: Adjustable Foot Rest

    92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjustable Foot Rest This feature allows the driver to adjust the foot rest forward or backward and to rotate it upward or down- ward to allow for greater driving comfort. Adjustable Foot Rest To adjust the pedal: 1.

  • Page 94: Understanding Your Instrument Panel

    UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....95 Instrument Cluster Description ....96 Speedometer .
  • Page 95 94 UNDERSTANDING YOUR INSTRUMENT PANEL Notes On Playing MP3 Files ... . . 114 Operation Instructions - (CD Mode For MP3 Audio Play) ..... 116 Satellite Radio —...

  • Page 96: Instrument Panel Features

    INSTRUMENT PANEL FEATURES 1 — Air Outlet 2 — Sound System Speaker 3 — Main Message Center 4 — Fuel Gauge 5 — Auxiliary Message Center 6 — Tachometer UNDERSTANDING YOUR INSTRUMENT PANEL 95 7 — Speedometer/Odometer 8 — Oil Pressure Gauge 9 —...

  • Page 97: Instrument Cluster Description

    96 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTION Speedometer Shows the vehicle’s speed in miles- per-hour (mph) and kilometers-per- hour (km/h). Odometer/Trip Odometer The odometer shows the total distance the vehicle has been driven. NOTE: U.S. federal regulations require upon transfer of vehicle ownership, the seller certify the mileage the vehicle has been driven.

  • Page 98: Message Center

    • The word “DECK” will flash in the display if the trunk/liftgate is open. • The words “LOW TIRE” will flash slowly in the display and a chime will sound if the tire pressure is low. • The words “FLAT TIRE” will flash rapidly in the display and a chime will sound if critically low tire pressure is detected.
  • Page 99 98 UNDERSTANDING YOUR INSTRUMENT PANEL standard non-anti-lock brakes. If this occurs, safely bring the vehicle to a complete stop as soon as possible and cycle the ignition key to attempt to reset the ABS. If the light remains on, see your authorized dealer immediately to have the system serviced.
  • Page 100 CAUTION! Prolonged driving with the light on could cause further damage to the emission control system. It could also affect fuel economy and driveability. The vehicle must be serviced before any state emissions tests can be performed. Turn Signal Indicators The left or right arrow will flash in unison with the corresponding front and rear turn signals when the turn signal switch is operated.
  • Page 101 100 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The light will turn on when the ignition switch is in the ON/RUN position and the parking brake is applied. This light shows only that the parking brake is applied. It does not show the degree of brake application. WARNING! Driving a vehicle with the brake light on is danger- ous.
  • Page 102 Low Tire Pressure Telltale / TPMS Malfunction Indicator Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those...
  • Page 103 102 UNDERSTANDING YOUR INSTRUMENT PANEL upon subsequent vehicle start-ups as long as the mal- function exists. When the malfunction indicator is illumi- nated, the system may not be able to detect or signal low tire pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly.

  • Page 104: Gauges & Indicator Lights

    WARNING! Do not exceed 55 mph (88 km/h) if the LOW Tire indicator is activated. Vehicle handling and braking may be reduced. You could have an accident and be severely or fatally injured. Seat Belt Reminder Light If the driver does not buckle their seat belt and vehicle speed exceeds 5 mph (8 km/h), or if the passenger does not buckle their seat belt within 10 seconds of vehicle speed exceeding 5 mph (8 km/h), the...
  • Page 105 104 UNDERSTANDING YOUR INSTRUMENT PANEL 6000 RPM. This serves as a visual aid to shift before reaching the red line. This warning will turn off when the tachometer pointer falls below 5900 RPM. (See page 136 for more information.) Coolant Temperature Gauge This gauge shows the engine coolant tempera- ture.
  • Page 106 between 20 and 80 psi (pounds per square inch). If the pointer remains in the red range, safely bring the vehicle to a complete stop and turn off the engine. DO NOT operate the vehicle until the cause is corrected. This gauge does not indicate the amount of oil in the engine.

  • Page 107: Setting The Digital Clock

    106 UNDERSTANDING YOUR INSTRUMENT PANEL Charge System Light The red Charge System Light is located in the Voltage Gauge. It will turn on when there is a charging system malfunction or a possible accessory drive belt failure. CAUTION! The accessory belt also drives the water pump. Op- erating the vehicle with a failed belt can cause engine overheating and possible severe engine damage.

  • Page 108: Two Types Of Signals

    you understand and save you concern about these “ap- parent” malfunctions, you must understand a point or two about the transmission and reception of radio sig- nals. Two Types of Signals There are two basic types of radio signals: AM or Amplitude Modulation, in which the transmitted sound causes the amplitude, or height, of the radio waves to vary;...

  • Page 109: Sales Code Rah - Am & Fm Stereo Radio With Cd Player And Cd/Dvd Changer Controls

    108 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RAH — AM & FM STEREO RADIO WITH CD PLAYER AND CD/DVD CHANGER CONTROLS NOTE: The radio sales code is located on the lower left side of your radio faceplate. RAH radio Radio Operation Power/Volume Control Press the ON/VOL control to turn the radio on.
  • Page 110 Program Type Radio Display Adult Hits Adult Hit Classical Classical Classic Rock Classic Rock College College Country Country Information Inform Jazz Jazz Foreign Language Language News News Nostalgia Nostalgia Oldies Oldies Personality Personality Public Public Rhythm and Blues R & B Religious Music Religious Music Religious Talk...
  • Page 111 110 UNDERSTANDING YOUR INSTRUMENT PANEL no station is found with the selected PTY program type, the radio will return to the last preset station. If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station.
  • Page 112 Tone Control The Bass and/or Treble controls sound for the desired tone. Press the AUDIO button, select Bass or TREBLE, then press SEEK + or SEEK to increase or decrease amplification of the band. To Set The Radio Push-Button Memory When you are receiving a station that you wish to commit to push-button memory, press the SET button.

  • Page 113: Cd Player Operation

    112 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Changes or modifications not expressively ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment. CD Player Operation NOTE: • The ignition switch must be in the ON or ACC position and the volume control ON before the CD player will operate.
  • Page 114 Seek Press the top of the SEEK button for the next selection on the CD. Press the bottom of the button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first 10 seconds of the current selection.

  • Page 115: Cd/Dvd Changer Operation

    114 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD Changer Operation Press the MODE button to select between the CD player and the optional remote CD/DVD changer. Time Press the TIME button to change the display from elapsed CD or DVD playing time to time of day. Notes On Playing MP3 Files The radio can play MP3 files, however, acceptable MP3 file recording media and formats are limited.
  • Page 116 CD audio tracks and computer files (including MP3 files). Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of multisession for CD audio or MP3 playback may result in longer disc loading times. Supported MP3 file formats The radio will recognize only files with the *.mp3 exten- sion as MP3 files.

  • Page 117: Operation Instructions - (Cd Mode For Mp3 Audio Play)

    116 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.

  • Page 118: Satellite Radio - If Equipped

    RW/FF (CD Mode For MP3 Play) Press the FF side of the button to move forward through the MP3 selection. Press the RW side of the button to move back through the MP3 selection. AM/FM Button (CD Mode For MP3 Play) Switches back to Radio mode.

  • Page 119: System Activation

    118 UNDERSTANDING YOUR INSTRUMENT PANEL System Activation Sirius Satellite Radio service is pre-activated, and you may begin listening immediately to the one year of SIRIUS audio service that is included with the factory- installed satellite radio system in your vehicle. Sirius will contact you to supply a welcome kit and to confirm subscription information, including the set up of your on-line listening account at no additional charge.

  • Page 120: Selecting Satellite Mode In Rbb, Rah, Rev And Rbk Radios

    The radio will exit the ESN/SID mode when any other button is pushed, the ignition is turned OFF, or 5 minutes has passed since any button was pushed. ESN/SID Access With RBP, RBU, RAZ, RB1 and RBQ Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the CD Eject and TIME buttons simultaneously for 3 seconds.

  • Page 121: Selecting A Channel

    120 UNDERSTANDING YOUR INSTRUMENT PANEL Selecting a Channel Press and release the SEEK or TUNE buttons to search for the next channel. Press the top of the button to search up and the bottom of the button to search down. Holding the TUNE button causes the radio to bypass channels until the button is released.

  • Page 122: Pty Button Seek

    one and stop the search. Pressing a pre-set memory button during a music type scan, will call up the memory channel and stop the search. PTY Button SEEK When the desired program is obtained, press the SEEK button within five seconds. The channel will change to the next channel that matches the program type selected.

  • Page 123: Radio Antenna

    122 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO ANTENNA The radio antenna is located in the windshield. CD/DVD DISC MAINTENANCE To keep the CD/DVD discs in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface.

  • Page 124: Air Conditioning And Heating System

    Air Conditioning and Heating System Air Conditioning And Heater Controls UNDERSTANDING YOUR INSTRUMENT PANEL 123 Blower Control Use this control to regulate the amount of air forced through the sys- tem in any mode you select. Turn the control clockwise to increase fan speed.
  • Page 125 124 UNDERSTANDING YOUR INSTRUMENT PANEL Mode Control Use this control to select the direction of air flow. NOTE: The dot between the mode control icons is a mix position between the two modes. The mode settings are as follows: • Recirculation Control Air is recirculated inside the vehicle.
  • Page 126 • Defrost/Floor Air is directed through the windshield defrost and the floor outlets. This setting works best in cold or snowy conditions that require extra heat at the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield. •...

  • Page 127: Operating Tips

    126 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips NOTE: Refer to the chart at the end of this section for suggested control settings for various weather condi- tions. Summer Operation The engine cooling system in air-conditioned vehicles must be protected with a high-quality antifreeze coolant to provide proper corrosion protection and to protect against engine overheating.
  • Page 128 Window Fogging Interior fogging on the windshield can be quickly re- moved by turning the mode selector to Defrost. The Defrost/Floor mode can be used to maintain a clear windshield and provide sufficient heating. If side win- dow fogging becomes a problem increase blower speed. Vehicle windows tend to fog on the inside in mild but rainy or humid weather.

  • Page 129: Rear Window Features

    128 UNDERSTANDING YOUR INSTRUMENT PANEL REAR WINDOW FEATURES Electric Rear Window Defroster The electric Rear Window Defroster Control is located on the climate control. Press this button to turn on the rear window defroster. A light above the button will illuminate when the rear window defroster is ON.
  • Page 130 STARTING AND OPERATING CONTENTS Starting Procedures ..... 132 Normal Starting ..... . 133 If Engine Fails To Start .
  • Page 131 130 STARTING AND OPERATING Tire Safety Information ....149 Tire Markings ......149 Tire Identification Number (TIN) .
  • Page 132 Fuel System Cautions ....170 Carbon Monoxide Warnings ....171 Adding Fuel .

  • Page 133: Starting Procedures

    132 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct any other occupant to buckle their seat belt. WARNING! • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.

  • Page 134: Normal Starting

    CAUTION! Long periods of engine idling, especially at high engine speeds, can cause excessive exhaust tempera- tures, which can damage your vehicle. Do not leave your vehicle unattended with the engine running. Normal Starting NOTE: • You must disarm the security system in order to start the engine.
  • Page 135 134 STARTING AND OPERATING 5. Turn the key to the ON/RUN position. Ignition Key Positions 6. Press the red ENGINE START button located on the instrument panel. Release the button when the engine starts. Engine Start Button...

  • Page 136: If Engine Fails To Start

    If Engine Fails to Start CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. STARTING AND OPERATING 135 WARNING! • Never pour fuel or other flammable liquid into the throttle body air inlet opening in an attempt to start the vehicle.

  • Page 137: After Starting

    136 STARTING AND OPERATING If the engine is flooded, it may start to run, but not have enough power to continue running when the start button is released. If this occurs, continue cranking up to 15 seconds with the accelerator pedal pushed all the way to the floor.
  • Page 138 Be sure the transmission is in FIRST gear when moving forward from a standing position. CAUTION! Failure to start out in FIRST gear when moving forward from a starting position may result in dam- age to the clutch. You will find it easier to use only the lower gears for most city driving.

  • Page 139: Recommended Shift Speeds

    138 STARTING AND OPERATING driving. The noise may also be more noticeable when the transmission is warm. This noise is normal and is not an indication of a problem with your clutch or transmission. Recommended Shift Speeds To use your manual transmission for fuel economy it should be upshifted as listed below.

  • Page 140: Driving On Slippery Surfaces

    To maintain a safe speed and prolong brake life, down- shift to maintain a safe speed when descending a steep grade. WARNING! Skipping more than one gear while downshifting, could cause you to lose control of your vehicle. You could have an accident. CAUTION! If you skip more than one gear while downshifting or downshift at too high an engine speed, you could...

  • Page 141: Traction

    140 STARTING AND OPERATING Traction When driving on wet or slushy roads, it is possible for a wedge of water to build up between the tire and road surface. This is hydroplaning and may cause partial or complete loss of vehicle control and stopping ability. To reduce this possibility, the following precautions should be observed: 1.

  • Page 142: Flowing/Rising Water

    Flowing/Rising Water WARNING! Do not drive on or cross a road or a path where water is flowing and/or rising (as in storm run-off). Flow- ing water can wear away the road or path’s surface and cause your vehicle to sink into deeper water. Furthermore, flowing and/or rising water can carry your vehicle away swiftly.

  • Page 143: Parking Brake

    142 STARTING AND OPERATING WARNING! • Driving through standing water limits your vehi- cle’s traction capabilities. Do not exceed 5 mph (8 km/h) when driving through standing water. • Driving through standing water limits your vehi- cle’s braking capabilities, which increases stop- ping distances.
  • Page 144 drops into the handle (releasing the lock), guide the handle downward to its stop and then release the button and the handle. Parking Brake The Brake System Warning Light in the instrument cluster will turn on when the ignition is in the ON/RUN position and the parking brake is applied.

  • Page 145: Brake System

    144 STARTING AND OPERATING BRAKE SYSTEM Your vehicle is equipped with dual hydraulic brake systems. If either of the two hydraulic systems loses normal capability, the remaining system will still function. However, there will be some loss of overall braking effectiveness. You may notice increased pedal travel during application, greater pedal force required to slow or stop, and potential activation of the Brake System Warning Light.

  • Page 146: Anti-Lock Brake System

    Safe Operating Tips WARNING! To use your brakes and accelerator more safely, follow these tips: • Do not “ride” the brakes by resting your foot on the pedal. This could overheat the brakes and result in unpredictable braking action, longer stopping distances, or brake damage. •...
  • Page 147 146 STARTING AND OPERATING The Anti-Lock Brake System pump motor runs during the self-test at 12 mph (20 km/h) and during an ABS stop. The pump motor makes a low humming noise during operation, which is normal. CAUTION! The Anti-Lock Brake System is subject to possible detrimental effects of electronic interference caused by improperly installed after-market radios or telephones.
  • Page 148 All vehicle wheels and tires must be the same size and type as the original equipment and the tires must be properly inflated to produce accurate signals for the computer. WARNING! Significant over or under inflation of tires, or mixing sizes of front or rear tires or wheels on the vehicle can lead to loss of braking effectiveness.

  • Page 149: Power Steering

    148 STARTING AND OPERATING POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.

  • Page 150: Tire Safety Information

    TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. STARTING AND OPERATING 149 • European Metric tire sizing is based on European design standards.
  • Page 151 150 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm)
  • Page 152 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions (i.e., tire pressure, vehicle loading, road conditions, and posted speed limits)

  • Page 153: Tire Identification Number (Tin)

    152 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including date code, located on the white sidewall side of the tire.

  • Page 154: Tire Loading And Tire Pressure

    Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location STARTING AND OPERATING 153 Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about: 1) the number of people that can be carried in the vehicle...
  • Page 155 154 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
  • Page 156 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1400 lbs. and there will be five 150 lb. passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 –...
  • Page 157 156 STARTING AND OPERATING...

  • Page 158: Tires - General Information

    WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.

  • Page 159: Tire Inflation Pressures

    158 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
  • Page 160 check tire pressure. Do not make a visual judgement when determining proper inflation. Radial tires may look properly inflated even when they are under inflated. CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem.

  • Page 161: Radial-Ply Tires

    160 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.

  • Page 162: Tire Spinning

    Tire Spinning When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels above 35 mph (55 km/h). Refer to the paragraph on “Freeing A Stuck Vehicle” in Section 6 of this manual. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure.

  • Page 163: Life Of Tire

    162 STARTING AND OPERATING Many states have laws requiring tire replacement at this point. Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.

  • Page 164: Alignment And Balance

    WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.

  • Page 165: Tire Chains

    164 STARTING AND OPERATING Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. TIRE CHAINS Due to limited clearance, tire chains are not recom- mended.

  • Page 166: Tire Rotation

    STARTING AND OPERATING 165 aggressive tread designs such as those on all season type tires. Rotation will increase tread life, help to maintain mud, snow, and wet traction levels, and contribute to a smooth, quiet ride. Follow the “Maintenance Schedules” in Section 8 of this manual for the recommended tire rotation frequency for your type of driving.

  • Page 167: Tire Pressure Monitor System (Tpms)

    166 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) Low Tire Indicator If tire pressure falls below 20 psi (138 kpa), the Low Tire Pressure Telltale in the Message Center will illuminate, a chime will sound, and the words LOW TIRE will flash slowly in the Liquid Crystal Display (LCD) panel in the bottom of the speedometer.
  • Page 168 WARNING! Do not exceed 55 mph (88 km/h) if the LOW Tire indicator is activated. Vehicle handling and braking may be reduced. You could have an accident and be severely or fatally injured. TPMS Malfunction Warning Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.

  • Page 169: Fuel Requirements

    If you experience these symptoms, try another brand of “premium” gasoline before considering service for the vehicle. Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) which...

  • Page 170: Gasoline/Oxygenate Blends

    Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions. Fuels blended with these oxygenates may be used in your vehicle.

  • Page 171: Materials Added To Fuel

    170 STARTING AND OPERATING Materials Added to Fuel All gasoline sold in the United States is required to contain effective detergent additives. Use of additional detergents or other additives are not needed under normal conditions and they would result in additional cost.

  • Page 172: Carbon Monoxide Warnings

    Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas, which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.
  • Page 173 172 STARTING AND OPERATING NOTE: • After removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler cap door reinforce- ment. • When the fuel nozzle “clicks” or shuts off, the fuel tank is full. •...

  • Page 174: Vehicle Loading

    WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel to the vehicle when the engine is running. • A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.

  • Page 175: Trailer Towing

    174 STARTING AND OPERATING TRAILER TOWING Trailer towing with this vehicle is not recommended. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat towing with all four wheels on the ground) Recreational towing for this vehicle is not recommended. NOTE: If the vehicle requires towing, make sure all four wheels are off the ground.

  • Page 176: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....176 If Your Engine Overheats ....176 TIREFIT Kit .

  • Page 177: Hazard Warning Flasher

    176 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER Hazard Flasher Switch The flasher switch is on the top of the steering column, just behind the steering wheel. Depress the flasher button and all front and rear directional signals will flash. Depress the flasher button again to turn off the flashers.

  • Page 178: Tirefit Kit

    • In city traffic — While moving, shift into the highest gear possible to reduce engine RPM. NOTE: There are steps that you can take to slow down an impending overheat condition. If your air conditioner is on, turn it off. The air conditioning system adds heat to the cooling system and turning off the A/C removes this heat.

  • Page 179: Tirefit Storage

    178 WHAT TO DO IN EMERGENCIES TIREFIT Storage The TIREFIT kit is located in the trunk. TIREFIT Location TIREFIT Usage Precautions NOTE: • Replace the TIREFIT Sealant Bottle prior to the expi- ration date (printed on the bottle label) to assure optimum operation of the system.
  • Page 180 • You can use the TIREFIT air pump to inflate bicycle tires. The kit also comes with two needles for inflating sport balls, rafts, or like inflatable items. However, use only the Black Air Pump Hose (6) and make sure the Mode Select Knob (4) is in the Air Mode when inflating such items to avoid injecting sealant into them.

  • Page 181: Tirefit Kit Components & Operation

    180 WHAT TO DO IN EMERGENCIES WARNING! • Take care not to allow the contents of TIREFIT to come in contact with hair, eyes, or clothing. TIRE- FIT is harmful if inhaled, swallowed, or absorbed through the skin: It causes skin, eye, and respira- tory irritation.

  • Page 182: Sealing A Tire With Tirefit

    6. Air Pump Hose (Black) 7. Sealant Hose (Clear with Yellow Cap) Using the Mode Select Knob & Hoses Selecting Air Mode Turn the Mode Select knob (4) to this position for air pump operation only. Use the Black Air Pump Hose (6) when selecting this mode.
  • Page 183 182 WHAT TO DO IN EMERGENCIES (B) Setting Up to Use TIREFIT: Turn the Mode Select knob (4) to the Sealant/ Air Mode position. 1. Uncoil the Clear Sealant Hose (7) and then remove the Yellow Cap from the fitting at the end of the hose. 2.
  • Page 184 • Turn the Mode Select knob to the Sealant/Air Mode. • Connect the Power Plug (5) to a different power outlet in your vehicle or another vehicle, if available. Make sure the engine is running before turning on the TIREFIT kit. •...
  • Page 185 184 WHAT TO DO IN EMERGENCIES WARNING! TIREFIT is not a permanent flat tire repair. Have the tire inspected and repaired or replaced after using TIREFIT. Do not exceed 55 mph (90 km/h) until having the tire repaired or replaced. Failure to follow this warning can result in injuries that are serious or fatal to you, your passengers, and others around you.
  • Page 186 5. Place the TIREFIT kit in its proper storage area in the vehicle. 6. Have the tire inspected and repaired or replaced at the earliest opportunity at an authorized dealer or tire ser- vice center. 7. Replace the Sealant Bottle (1) at your nearest autho- rized Mopar parts dealership as soon as possible.

  • Page 187: Jump-Starting Procedures

    186 WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES WARNING! • Take care to avoid the radiator cooling fans whenever the hood is raised. They can start anytime the ignition switch is on. You can be hurt by the fans. • Take care to avoid the accessory drive whenever the hood is raised.
  • Page 188 5. Remove the plastic cover from the remote jump-start positive post (+) in the engine compartment. Refer to the following illustration for remote jump-starting connec- tions. Remote Jump-Start Connections WHAT TO DO IN EMERGENCIES 187 6. If you are jump-starting your vehicle, connect one end of a jumper cable to the positive (+) terminal on the booster battery.
  • Page 189 188 WHAT TO DO IN EMERGENCIES WARNING! • You should not try to start your vehicle by pushing or towing. • Do not connect the cable to the negative post of the discharge battery. The resulting electrical spark could cause the battery to explode. •...

  • Page 190: Freeing A Stuck Vehicle

    WARNING! Any procedure other than above could result in: 1. Personal injury caused by electrolyte squirting out the battery vent; 2. Personal injury or property damage due to battery explosion; 3. Damage to charging system of booster vehicle or of immobilized vehicle. FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion.
  • Page 191 190 WHAT TO DO IN EMERGENCIES CAUTION! Towing with equipment other than flat bed types may damage your vehicle.

  • Page 192: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS 8.4L Engine Compartment ....194 Onboard Diagnostic System (OBD II) ..195 Emissions Inspection And Maintenance Programs .
  • Page 193 192 MAINTAINING YOUR VEHICLE Battery Save Feature ....210 Air Conditioner Maintenance ... . . 212 Power Steering —...
  • Page 194 Replacement Bulbs ..... . 240 Bulb Replacement ..... . 242 Auxiliary High Beam Headlight, Front Park/Turn Signal Light, Front Side Marker Light .

  • Page 195: 8.4L Engine Compartment

    194 MAINTAINING YOUR VEHICLE 8.4L ENGINE COMPARTMENT...

  • Page 196: Onboard Diagnostic System (Obd Ii)

    ONBOARD DIAGNOSTIC SYSTEM (OBD II) To meet new government regulations and promote cleaner air, your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions and engine control systems. When these systems are operating prop- erly, your vehicle will provide excellent performance and fuel economy, as well as engine emissions well within current government regulations.

  • Page 197: Emissions Inspection And Maintenance Programs

    196 MAINTAINING YOUR VEHICLE EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system. Failure to pass could prevent vehicle registration. For states, which have an I/M (Inspection and Maintenance) requirement, this check verifies the following: the MIL (Malfunction Indicator Light) is functioning and is not on when the engine is running,...

  • Page 198: Replacement Parts

    5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn off the ignition key or start the engine. This means that your vehicle’s OBD system is not ready and you should not proceed to the I/M station.

  • Page 199: Dealer Service

    198 MAINTAINING YOUR VEHICLE DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service Manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
  • Page 200 The best time to check the oil level is approximately 5 minutes after a fully warmed engine is turned off or before starting the engine after it has sat overnight. Checking the oil while the vehicle is on level ground also will improve the accuracy of the oil level readings.
  • Page 201 200 MAINTAINING YOUR VEHICLE • More than 50% of your driving is at sustained high speeds during hot weather, above 90°F (32°C) • Trailer towing • Taxi, Police, or delivery service (commercial service) • Off-road or desert driving • If equipped for and operating with E-85 (ethanol) fuel NOTE: If ANY of these apply to you, then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first, and follow schedule “B”...

  • Page 202: Engine Oil Filter

    The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil filler cap location, refer to the “Engine Com- partment” illustration in this section. Materials Added to Engine Oil The manufacture strongly recommends against the addi- tion of any additives (other than leak detection dyes) to MAINTAINING YOUR VEHICLE 201 the engine oil.

  • Page 203: Drive Belts - Check Condition And Tension

    202 MAINTAINING YOUR VEHICLE quality filters should be used to assure most efficient service. Mopar Engine Oil Filters are a high quality oil filter and are recommended. Drive Belts — Check Condition and Tension Belt tension is controlled by means of an automatic tensioner.

  • Page 204: Spark Plugs

    Spark Plugs Spark plugs must fire properly to assure engine perfor- mance and emission control. New plugs should be in- stalled at the specified mileage. The entire set should be replaced if there is any malfunction due to a faulty spark plug.

  • Page 205: Fuel Filter

    204 MAINTAINING YOUR VEHICLE Fuel Filter The fuel filter is a part of the fuel module and it does not require maintenance. Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device.

  • Page 206: Ignition Wiring System And Ignition Timing

    WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming in contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.

  • Page 207: Crankcase Emission Control System

    206 MAINTAINING YOUR VEHICLE NOTE: • Because of the plastic body shell on your vehicle, ignition cables should be replaced with the specially designed RFI cables available at your dealer. • The ignition timing cannot be set on this engine. Crankcase Emission Control System Proper operation of this system depends on freedom from plugging due to deposits.
  • Page 208 MAINTAINING YOUR VEHICLE 207 Accessing The Battery Battery Location...
  • Page 209 208 MAINTAINING YOUR VEHICLE WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin, or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
  • Page 210 To Service the Battery: 1. Remove the floor portion of the rear compartment carpet to access the battery compartment. 2. Remove the battery cover mounting screws and re- move the battery cover. 3. Disconnect the negative battery cable from the battery. NOTE: The negative battery terminal is marked with a (-) symbol.

  • Page 211: Battery Save Feature

    210 MAINTAINING YOUR VEHICLE Battery Save Feature The Battery Save feature conserves battery power when storing the vehicle. It allows for up to 3 months of storage time without losing radio and engine controller memory. Using this feature is an alternative to disconnecting the battery.
  • Page 212 4. Remove the key from the ignition switch and exit the vehicle. The Battery Save Feature will be enabled 45 seconds after all doors are closed. NOTE: • Turning the ignition switch to the ON/RUN position at any time will cancel activation of the Battery Save Feature.

  • Page 213: Air Conditioner Maintenance

    212 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an Authorized Dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test.

  • Page 214: Power Steering - Fluid Check

    Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluorocar- bon (HFC) that is endorsed by the Environmental Pro- tection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by dealers or other service facilities using recovery and recycling equipment.

  • Page 215: Front & Rear Suspension Ball Joints

    214 MAINTAINING YOUR VEHICLE WARNING! Overfilling the power steering fluid reservoir can result in spilling power steering fluid on hot engine parts and the power steering fluid catching fire. Front & Rear Suspension Ball Joints This vehicle has suspension ball joints that require peri- odic inspection and lubrication.

  • Page 216: Body Lubrication

    Lubrication The tie rod ends are lubricated for life. No periodic lubrication is required. Body Lubrication Locks and all body pivot points, including seat tracks, doors hinges, trunk/liftgate hinges, and hood hinges, should be lubricated periodically to assure quiet, easy operation and to protect against rust and wear.
  • Page 217 216 MAINTAINING YOUR VEHICLE Multi-Purpose Lubricant NLGI Grade 2 or equivalent should be applied sparingly to all pivot and sliding contact areas. Other Body Mechanisms The following body mechanisms should be inspected and, if necessary, all pivot and sliding contact areas of these components should be lubricated with a smooth white body lubricant such as Mopar Spray White Lube or equivalent:...

  • Page 218: Windshield Wiper Blades

    • Rubber bushings • Starter bearing • Throttle control cable • Water pump bearings Windshield Wiper Blades The rubber edges of the wiper blades and the windshield should be cleaned periodically with a sponge or soft cloth and a mild nonabrasive cleaner. This will remove accu- mulations of salt or road film.

  • Page 219: Exhaust System

    218 MAINTAINING YOUR VEHICLE Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system. If you notice a change in the sound of the exhaust system; or if exhaust fumes can be detected inside the vehicle; or when the underside or side of the vehicle is damaged;...

  • Page 220: Cooling System

    Cooling System WARNING! • When working near the radiator cooling fans, disconnect each fan motor lead or turn the ignition switch to the OFF position. The fans are tempera- ture controlled and can start any time the ignition switch is in the ON position. •...
  • Page 221 220 MAINTAINING YOUR VEHICLE drain from the coolant recovery bottle. DO NOT RE- MOVE THE COOLANT PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT. Cooling System — Drain, Flush, and Refill The system should be drained, flushed, and refilled at the intervals shown on the “Maintenance Schedules”...
  • Page 222 Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to 5 Years or 100,000 miles (160 000 km) before replacement. To prevent reducing this extended maintenance period, it is important that you use the same coolant throughout the life of your vehicle.
  • Page 223 222 MAINTAINING YOUR VEHICLE The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution.
  • Page 224 service attendant of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month. When additional coolant is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill.

  • Page 225: Hoses And Vacuum/Vapor Harnesses

    224 MAINTAINING YOUR VEHICLE • Do not change the thermostat for summer or winter operation. If replacement is ever necessary, install ONLY the correct type thermostat. Other designs may result in unsatisfactory coolant performance, poor gas mileage, and increased emissions. Hoses and Vacuum/Vapor Harnesses Inspect surfaces of hoses and nylon tubing for evidence of heat and mechanical damage.

  • Page 226: Brake System

    Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Recommended service intervals can be found in the “Maintenance Schedules” in this manual. WARNING! Riding the brakes can lead to brake failure and possibly an accident.
  • Page 227 226 MAINTAINING YOUR VEHICLE • Inspect the brake hoses whenever the brake system is serviced and at every engine oil change. Inspect hy- draulic brake hoses for surface cracking, scuffing, or worn spots. If there is any evidence of cracking, scuffing, or worn spots, the hose should be replaced immediately! Eventual deterioration of the hose can take place resulting in a possibility of a burst failure.
  • Page 228 Use only the manufacturer’s recommended brake fluid. Refer to “Fluids, Lubricants, and Genuine Parts” for the correct fluid type. Use of a brake fluid that may have a lower initial boiling point or unidentified as to specifica- tion, may result in sudden brake failure during hard prolonged braking.

  • Page 229: Transmission

    228 MAINTAINING YOUR VEHICLE Transmission Transmission Fluid Level Check Check the fluid in the transmission when performing other underhood services. Check the fluid level by removing the fill plug located on the left side of the transmission. The fluid level should be at the bottom of the fill hole.
  • Page 230 Use only the manufacturer’s recommended clutch fluid. Refer to “Fluids, Lubricants, and Genuine Parts” for the correct fluid type. WARNING! Overfilling the clutch fluid reservoir can result in spilling clutch fluid on hot engine parts and the clutch fluid catching fire. Use only clutch fluid that has been in a tightly closed container to avoid contamination from foreign matter.

  • Page 231: Rear Axle

    230 MAINTAINING YOUR VEHICLE Rear Axle Axle Lubricant Level Check Check the exterior of the axle for evidence of gear oil leakage every 12 months or 6,000 miles (10 000 km). This check should be made with the vehicle level and sup- ported by the suspension, with the vehicle on the ground or raised on an axle and wheel type hoist.
  • Page 232 In the event that you do take this vehicle to a commercial car wash, move the Heater/Air Conditioning blower control to the lowest setting. This will prevent the possi- bility of water entering the system. CAUTION! The tires on this vehicle are wider than the guide tracks on most washes and the low ground clearance of this vehicle may not be compatible with some car wash equipment.
  • Page 233 232 MAINTAINING YOUR VEHICLE Convertible Top Care — Convertible Models Only Use a mild detergent to clean the top. Avoid heavy scrubbing and rinse with plenty of clean water. Allow to dry thoroughly before storage. Underbody Maintenance The corrosive materials used for ice and snow removal or dust control may accumulate on the underbody of your vehicle.
  • Page 234 NOTE: Never scrape the windows with squeegees, razor blades, or other sharp instruments. • Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners. If using soap, wipe clean with a clean damp rag or chamois cloth.

  • Page 235: Fuses (Power Distribution Centers)

    234 MAINTAINING YOUR VEHICLE FUSES (POWER DISTRIBUTION CENTERS) Fuses (Power Distribution Center) A power distribution center is located in the engine compartment on the driver’s side of the vehicle. This center contains fuses and relays. Power Distribution Center Cavity Car- Mini Description tridge...
  • Page 236 Cavity Car- Mini Description tridge Fuse Fuse 30 Amp — Ignition Switch Run/ Pink Accessory Feed 40 Amp — Headlights Green 30 Amp — Ignition Switch Run Feed Pink — 20 Amp Auto Shutdown Relay Yellow (ASD) — 20 Amp Cigar Lighter Yellow —...
  • Page 237 236 MAINTAINING YOUR VEHICLE Cavity Car- Mini Description tridge Fuse Fuse 62, 63 — 15 Amp Gauges Blue 64, 65 — 10 Amp Airbag 66, 67 — 20 Amp Wiper Switch Yellow 68, 69 — 20 Amp Left HID Headlight Yellow 70, 71 —...

  • Page 238: Fuses (Mini-Power Distribution Center)

    Fuses (Mini-Power Distribution Center) A mini-power distribution center is located in the engine compartment on the passenger’s side of the vehicle. This center contains radiator fan control relays and has two externally-mounted 40 Amp fuses for the radiator fans. Mini-Power Distribution Center MAINTAINING YOUR VEHICLE 237 CAUTION! •...

  • Page 239: Vehicle Storage

    238 MAINTAINING YOUR VEHICLE VEHICLE STORAGE We recommend that you follow these guidelines for storing your vehicle for extended periods. • Fill the fuel tank. This will prevent water condensation inside the tank. If you plan to store your vehicle more than 2 months, add an anti-oxidant fuel stabilizer to the fuel tank.
  • Page 240 Then, either disconnect the battery at the negative terminal or use the “Battery Save Feature” to conserve battery power. Refer to “Battery Save Feature” under “Maintenance Procedures” in this section for details. NOTE: Disconnecting the battery causes the engine control system to lose memory of some “learned” func- tions.

  • Page 241: Replacement Bulbs

    240 MAINTAINING YOUR VEHICLE NOTE: To help prevent the battery from discharging during shorter periods of inactivity, perform the follow- ing: 1. Make sure that the trunk/liftgate, hood, doors, win- dows, and convertible top are completely closed. 2. Make sure that remote transmitter is operating and that the battery is good.

  • Page 242: Bulb Number

    LIGHT BULBS — Exterior (Convertible Models) Low/High Beam High Intensity Discharge (HID) Headlight ..Serviced at dealer only Auxiliary High Beam Headlight ..(HB3A) 9005XS Front Park/Turn Signal Light ... . . 3157AK Fog Light .

  • Page 243: Bulb Replacement

    242 MAINTAINING YOUR VEHICLE BULB REPLACEMENT Auxiliary High Beam Headlight, Front Park/Turn Signal Light, Front Side Marker Light 1. Remove the push pin from the upper outer corner of the splash shield and remove the splash shield. 2. Turn the appropriate bulb and socket assembly counter-clockwise, and then pull it out of the headlight assembly.

  • Page 244: High Intensity Discharge Headlights (Hid)

    3. Pull the bulb out of the socket assembly. 4. Push the replacement bulb into the socket assembly. 5. Reinstall the bulb and socket assembly into the head- light assembly, and then turn it clockwise. 6. Install the splash shield and push pin. High Intensity Discharge Headlights (HID) The headlights are a type of high voltage discharge tube.

  • Page 245: Front Fog Light

    244 MAINTAINING YOUR VEHICLE Front Fog Light 1. Remove the push pin from the upper outer corner of the splash shield and remove the splash shield. 2. Turn the bulb and socket assembly counter-clockwise, and then pull it out of the front fog light assembly. 3.

  • Page 246: Taillight, Tail/Stop Light, Rear Marker Light

    Taillight, Tail/Stop Light, Rear Marker Light 1. Open the trunk 2. Remove the two fasteners and then remove the access panel. MAINTAINING YOUR VEHICLE 245 3. Turn the appropriate bulb and socket assembly counter-clockwise, and then pull it out of the upper light assembly.

  • Page 247: Backup Light, Rear Turn Signal Light

    246 MAINTAINING YOUR VEHICLE 5. Push the replacement bulb into the socket assembly. 6. Reinstall the bulb and socket assembly into the upper light assembly, and then turn it clockwise. 7. Install the access panel and the two fasteners. 8. Close the trunk. Backup Light, Rear Turn Signal Light 1.
  • Page 248 MAINTAINING YOUR VEHICLE 247 3. Remove the three upper light assembly retaining nuts. 4. Remove the three bulb and socket assemblies from the upper light assembly by turning them counter-clockwise and then pulling them out of the upper light assembly.
  • Page 249 248 MAINTAINING YOUR VEHICLE 5. Remove the upper light assembly. 6. Turn the appropriate bulb and socket assembly counter-clockwise, and then pull it out of the lower light assembly. 1 — Backup Light...

  • Page 250: Rear Turn Signal Light

    MAINTAINING YOUR VEHICLE 249 7. Pull the bulb out of the socket assembly. 8. Push the replacement bulb into the socket assembly. 9. Reinstall the bulb and socket assembly into the lower light assembly, and then turn it clockwise. 10. Reinstall the three bulb and socket assemblies into the upper light assembly, and turn them clockwise.

  • Page 251: License Light

    250 MAINTAINING YOUR VEHICLE License Light 1. Open the trunk. 2. Turn the bulb and socket assembly counter-clockwise, and then pull it out of the housing. 3. Pull the bulb out of the socket assembly. 4. Push the replacement bulb into the socket assembly. 5.

  • Page 252: Headlight Aiming

    HEADLIGHT AIMING The headlights on your new vehicle were aimed at the factory under a no load setting. A great increase in weight will change the aiming of the headlights. Therefore, it may be necessary to readjust the headlights if you typically carry an excessive amount of weight in the rear compartment or generally suspect misalignment.

  • Page 253: Fluids, Lubricants, And Genuine Parts

    252 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluids, Lubricants, and Genuine Parts Mopar Antifreeze/Coolant 5 Year/102,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) or equivalent. For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or SM/CF, and...

  • Page 254: Chassis

    Chassis Component Transmission Rear Axle Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part Mopar ATF+4 Automatic Transmission Fluid. Mopar Synthetic Gear and Axle Lubricant SAE 75W-140 or equivalent, with Limited Slip Additive Friction Modifier Mopar Brake & Clutch Fluid DOT 4 Motor Vehicle or equivalent. Mopar Power Steering Fluid + 4, Mopar ATF+4 Automatic Transmission Fluid.

  • Page 255: Body

    254 MAINTAINING YOUR VEHICLE Body Component Hinges: Door, Trunk & Hood Springs and Links Latches: Door, Hood & Trunk Door Hinge Check Spring Seat Regulator & Track Window System Components Lock Cylinders Parking Brake Mechanism Fluid, Lubricant, or Genuine Part Mopar Spray White Lube or equivalent.
  • Page 256 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..256 Maintenance Schedules ....256 Schedule “B” ......259 Schedule “A”...

  • Page 257: Emission Control System Maintenance

    256 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
  • Page 258 • Off-road or desert operation. • If equipped for and operating with E-85 (ethanol) fuel. NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5000 km) or 3 months, whichever comes first, and follow the maintenance rec- ommendations in Schedule “B”...
  • Page 259 258 MAINTENANCE SCHEDULES At Each Stop for Fuel • Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accu- racy of the oil level reading.

  • Page 260: Schedule "B" 259

    SCHEDULE “B” Follow schedule “B” if you usually operate your vehicle under one or more of the following conditions. • Day or night temperatures are below 32° F (0° C). • Stop and go driving. • Extensive engine idling. • Driving in dusty conditions. •...
  • Page 261 260 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the air cleaner filter if necessary. Inspect the transmission fluid. Inspect the brake linings. Change the rear axle fluid. Change the brake fluid.
  • Page 262 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the air cleaner filter if necessary. Inspect and replace the PCV valve if neces- sary. Change the transmission fluid. Inspect the transmission fluid.
  • Page 263 262 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the engine air cleaner fil- ter if necessary. Inspect and replace the Auto Tension Drive Belt if necessary. Change the transmission fluid.
  • Page 264 Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Rotate the tires. Inspect and replace the air cleaner filter if necessary. Inspect and replace the PCV valve if necessary. Flush and replace engine coolant at 60 months, if not done at 102,000 miles.
  • Page 265 264 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the air cleaner filter if necessary. Inspect and replace the PCV valve if neces- sary. Inspect and replace the Auto Tension Drive Belt if necessary.
  • Page 266 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the engine air cleaner fil- ter if necessary. Replace the spark plugs. Replace the ignition cables. Flush and replace the engine coolant, if not replaced at 60 months.
  • Page 267 266 SCHEDULE “B” Miles (Kilometers) Inspect the brake linings. Change the rear axle fluid. Change the brake and clutch fluid. Change the brake fluid. Lubricate the front and rear suspension ball joints. 93,000 96,000 99,000 102,000 (155 000) (160 000) (165 000) (170 000) (175 000) (180 000) 105,000 108,000...
  • Page 268 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Rotate the tires. Inspect and replace the engine air cleaner filter if neces- sary. Inspect and replace the PCV valve if necessary. Flush and replace the engine coolant, if not replaced at 102,000 months.
  • Page 269 268 SCHEDULE “B” Miles (Kilometers) Change the brake and clutch fluid. Lubricate the front and rear suspension ball joints. ‡ This maintenance is not required if previously replaced. Although not required, the manufacturer recom- mends reprogramming TPMS after rotating tires so sys- tem can relearn tire pressure sensor location.

  • Page 270: Schedule "A" 269

    SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter if necessary. Inspect the transmission fluid. Inspect the brake linings. Change the rear axle fluid. Change the brake fluid. Lubricate the front and rear suspension ball joints.
  • Page 271 270 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter if necessary. Inspect and replace the PCV valve if necessary. Flush and replace the engine coolant at 60 months, if not done at 102,000 miles.
  • Page 272 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter if necessary. Inspect and replace the PCV valve if necessary. Inspect and replace the Auto Tension Drive Belt if necessary.
  • Page 273 272 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate the tires. Inspect and replace the engine air cleaner filter if necessary. Inspect and replace the PCV valve if necessary. Replace the spark plugs. Replace the ignition cables. Flush and replace the engine coolant, if not re- placed at 60 months.
  • Page 274 Miles (Kilometers) [Months] Change the transmission fluid. Inspect the brake linings. Change the rear axle fluid. Change the brake and clutch fluid. Lubricate the front and rear suspension ball joints. ‡ This maintenance is not required if previously replaced. Although not required, the manufacturer recom- mends reprogramming TPMS after rotating tires so sys- tem can relearn tire pressure sensor location.
  • Page 276 IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......277 Prepare For The Appointment .
  • Page 277 276 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....282 Department Of Transportation Uniform Tire Quality Grades ......283 Treadwear .

  • Page 278: If You Need Consumer Assistance 277

    SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty;...
  • Page 279 278 IF YOU NEED CONSUMER ASSISTANCE special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your authorized dealer’s service manager first. Most matters can be re- solved with this process.
  • Page 280 Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
  • Page 281 280 IF YOU NEED CONSUMER ASSISTANCE WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
  • Page 282 REPORTING SAFETY DEFECTS In the 50 United States and Washington D.C. If you believe that your vehicle has a defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the manufacturer.

  • Page 283: Publication Order Forms

    282 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.

  • Page 284: Traction Grades

    Call Toll Free at: • 1–800–890–4038 (U.S.) • 1–800–387–1143 (Canada) Visit us on the World Wide Web at: • www.techauthority.daimlerchrysler.com • www.daimlerchrysler.ca/manuals DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National Highway Traffic Safety Adminis- tration.
  • Page 285 284 IF YOU NEED CONSUMER ASSISTANCE on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction perfor- mance. WARNING! The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics.
  • Page 286 INDEX...
  • Page 287 286 INDEX About Your Brakes ..... . . 144 ABS (Anti-Lock Brake System) ... . 97,145 Accessory Delay, Power .
  • Page 288 Emergency Starting ..... 186 Jump Starting ......186 Keyless Transmitter Replacement (RKE) .
  • Page 289 288 INDEX Carpeting ......233 Catalytic Converter ..... . 204 CD (Compact Disc) Changer .
  • Page 290 Selection of Coolant (Antifreeze) ..220,251,252 Crankcase Emission Control System Customer Assistance ..... 277 Daytime Running Lights ....82 Dealer Service .
  • Page 291 290 INDEX Compartment ......194 Coolant (Antifreeze) ....219,252 Cooling .
  • Page 292 Manual Transmission ....228,253 Power Steering ..... 213,253 Fluids .
  • Page 293 292 INDEX Hazard Driving Through Flowing, Rising, or Shallow Standing Water ....140 Hazard Warning Flasher ....99,176 Headlights .
  • Page 294 Key-In Reminder ......13 Keyless Entry System ..... . 17 Keys .
  • Page 295 294 INDEX Low Tire ......101 Malfunction Indicator (Check Engine) ..98 Map Reading .
  • Page 296 Methanol ......169 Mirrors ....... . 75 Electric Remote .
  • Page 297 296 INDEX Parking On Hill ......142 Passing Light ......84 PCV Valve .
  • Page 298 Remote Keyless Entry (RKE) ....17 Remote Trunk Release ..... 29 Replacement Parts .
  • Page 299 298 INDEX Service Contract ......279 Service Engine Soon Light (Malfunction Indicator) ....98 Service Manuals .
  • Page 300 Tire Safety Information ....149 TIREFIT ......177 Tires .
  • Page 301 300 INDEX Transmitter, Remote Keyless Entry (RKE) ..17,21 Transporting Pets ......56 Tread Wear Indicators .
  • Page 302 Windshield Wiper Blades ....217 Windshield Wipers ..... . . 87 Wiper Blade Replacement .
  • Page 303 81-226-0804 Second Edition Printed in U.S.A.

Table of Contents
