SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3 CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5 INTRODUCTION 5...
Page 6: Vehicle Identification Number
The vehicle identification number (VIN) is on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN LOCATION Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove the VIN.
Page 7: Vehicle Modifications / Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 9 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....11 Ignition Key Removal ....11 Key-In-Ignition Reminder .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Protection Door Lock ....25 Windows ......27 Power Windows .
Page 11: Things To Know Before Starting Your Vehicle 9
A WORD ABOUT YOUR KEYS You can insert the double-sided keys into the locks with either side up. Vehicle Key The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer.
Page 12: Key-In-Ignition Reminder
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles equipped with the Electronic Vehicle Information Center (EVIC), the power window switches, radio, power sunroof (if equipped), and power outlets will remain active for up to 60 minutes after the ignition switch is turned off. Opening either front door will cancel this feature.
Page 13: Sentry Key
SENTRY KEY The Sentry Key Immobilizer System prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked. The system uses ignition keys, which have an embedded electronic chip (transponder), to prevent unauthorized vehicle operation.
Page 14: Replacement Keys
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE All of the keys provided with your new vehicle have been programmed to the vehicle electronics. Replacement Keys NOTE: Only keys that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a Sentry Key is programmed to a vehicle, it cannot be programmed to any other vehicle.
Page 15: General Information
The new Sentry Key is programmed. The Keyless Entry Transmitter will also be programmed during this pro- cedure. Repeat this procedure to program up to 8 keys. If you do not have a programmed sentry key, contact your dealer for details. NOTE: If a programmed key is lost, see your dealer to have all remaining keys erased from the systems memory.
Page 16: To Disarm The System
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE system is not arming. In addition, if you open a door during the arming period, the system will cancel the arming process. If you wish to rearm the system after closing the door, you must repeat one of the previously described arming sequences.
Page 17: Illuminated Entry System
Tamper Alert If something has triggered the system in your absence, the horn will sound three times when you disarm the system. Check the vehicle for tampering. ILLUMINATED ENTRY SYSTEM The courtesy lights will turn on when you use the keyless entry transmitter or open the doors or liftgate.
Page 18: To Unlock The Doors
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To unlock the doors: Press and release the UNLOCK button on the transmitter once to unlock the driver’s door, or twice to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal.
Page 19: To Lock The Doors
• For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Flash Lights with Remote Key Lock,” under Personal Settings (Cus- tomer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual for details. •...
Page 20: Using The Panic Alarm
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the transmitter. This feature can be turned on or off. To change the current setting, proceed as follows: •...
Page 21: Programming Additional Transmitters
NOTE: • The interior lights will turn off if you turn the ignition switch to the ACC or ON position while the panic alarm is activated. However, the exterior lights and horn will remain on. • You may need to be less than 23 feet (7 meters) from the vehicle when using the transmitter to turn off the panic alarm due to the radio frequency noises emitted by the system.
Page 22: General Information
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. To assemble the transmitter case, snap the two halves together. If so equipped, install and tighten the screw until snug. Make sure there is an even “gap” between the two halves. 5.
Page 23: Power Door Locks
If the door lock plunger is down when you shut the door, the door will lock. Therefore, make sure the keys are not inside the vehicle before closing the door. WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle.
Page 24 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE chime will sound if the key is in the LOCK or ACC position and a door is open, as a reminder to remove the key. Automatic Door Locks The doors will lock automatically on vehicles with power door locks if all of the following conditions are met: 1.
Page 25: Things To Know Before Starting Your Vehicle 25
Automatic Unlock Doors on Exit The doors will unlock automatically on vehicles with power door locks if: 1. The Automatic Unlock Doors On Exit feature is en- abled. 2. The transmission was in gear and the vehicle speed returned to 0 mph (0 km/h). 3.
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Engage the Child Protection Door Lock 1. Open the rear door. 2. Insert the tip of the vehicle’s ignition key or alike into the child lock control and pull it upward. Child Lock Control 3.
Page 27: Windows
2. Insert the tip of the vehicle’s ignition key or alike into the child lock control and pull it downward. Child Lock Control 3. Repeat Steps 1 and 2 on the opposite rear door. NOTE: After disengaging the child protection door lock system, always test the door from the inside to make certain it is in the desired position.
Page 28 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the win- dows while operating the power window switches. Such entrapment may result in serious injury or death.
Page 29 To close the window part way, lift the window switch to the first detent and release it when you want the window to stop. For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power window switches will remain active for 10 minutes after the ignition switch is turned off.
Page 30: Wind Buffeting
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Switch The window lockout switch on the driver’s door allows you to disable the window controls on the passenger doors. When the switch is pressed, the window controls on the passenger doors will not illuminate and the passenger windows will be disabled.
Page 31: Liftgate
buffeting occurs with the sunroof open, then adjust the sunroof opening to minimize the buffeting. LIFTGATE The liftgate can be unlocked or locked by the remote keyless entry transmitter or by activating the power door lock switches located on the front doors. Once unlocked, the liftgate can be opened or closed.
Page 32 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If a power malfunction occurs, you can use the emergency liftgate latch release to open the liftgate. The emergency liftgate latch release is located behind a snap-in cover on the liftgate trim panel. Emergency Liftgate Latch Release Location WARNING! •...
Page 33: Occupant Restraints
OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, front airbags for both the driver and front passenger and, if so equipped, side curtain airbags for the driver and passen- gers seated next to a window.
Page 34 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 35 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Connecting Latch Plate To Buckle THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
Page 37 WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after a collision if they have been damaged (bent retractor, torn webbing, etc.).
Page 38: Lap/Shoulder Belt Untwisting Procedure
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Adjusting Upper Shoulder Belt As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you will prefer a higher position. When you release the anchorage, try to move it up and down to make sure that it is locked in position.
Page 39: Enhanced Seat Belt Reminder System (Beltalert)
NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be worn snugly and positioned properly. The pretensioners are triggered by the Airbag Control Module (refer to information on Airbags in this section). Like the front airbags, the pretensioners are single use items.
Page 40: Automatic Locking Mode - If Equipped
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Watch for the Seat Belt Reminder Light to turn on while unbuckling the seat belt and turn off while re-buckling the seat belt. It may be necessary to retract the seat belt. 4.
Page 41: Seat Belt Extender
Pregnant women should wear the lap part of the belt across the thighs and as snug across the hips as possible. Keep the belt low so that it does not come across the abdomen. That way the strong bones of the hips will take the force if there is a collision.
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity.
Page 43 WARNING! • Do not put anything on or around the front airbag covers or attempt to manually open them. You may damage the airbags and you could be injured be- cause the airbags are no longer functional. These protective covers for the airbag cushions are de- signed to open only when the airbags are inflating.
Page 44 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some simple steps you can take to minimize the risk of harm from a deploying airbag. 1. Children 12 years old and under should ride buckled up in the rear seat. 2.
Page 45 WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions, the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 46 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How The Airbag System Works • The Airbag Control Module (ACM) determines if a frontal collision is severe enough to require the airbags to inflate. The front airbag inflators are designed to provide different rates of airbag inflation from direc- tion provided by the ACM.
Page 47 their full size. The bags fully inflate in about 50 - 70 milliseconds. This is about half of the time that it takes to blink your eyes. The bags then quickly deflate while helping to restrain the driver and front passenger. The driver’s front airbag gas is vented through vent holes in the sides of the airbag.
Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE you might get sliding along a carpet or gymnasium floor. They are not caused by contact with chemicals. They are not permanent and normally heal quickly. However, if you haven’t healed significantly within a few days, or if you have any blistering, see your doctor immediately.
Page 49: Event Data Recorder (Edr)
Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper passenger side of the instrument panel.
Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the electronic data may be used by DaimlerChrysler and others to learn more about the possible causes of crashes and associated injuries in order to assess and improve vehicle performance. In addition to crash investigations initiated by DaimlerChrysler, such investigations may be requested by customers, insurance carriers, government officials, and professional crash researchers, such as those...
Page 51: Child Restraint
• Brake status (service and parking brakes) • Accelerator status (including vehicle speed) • Engine control status (including engine speed) • Cruise control status (if applicable) • Traction/stability control status (if applicable) Child Restraint Everyone in your vehicle needs to be buckled up all the time —...
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing: infant carriers and “convertible” child seats. • The infant carrier is only used rearward-facing in the vehicle.
Page 53 Children Too Large For Booster Seats Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend over the front of the seat when their back is against the seat back, should use the lap/shoulder belt in a rear seat. •...
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The restraint must be appropriate for your child’s weight and height. Check the label on the restraint for weight and height limits. • Carefully follow the instructions that come with the restraint.
Page 55 rear-seating positions, or if your child restraints are not LATCH-compatible, install the restraints using the vehi- cle’s seat belts. LATCH Anchorages Installing the LATCH-Compatible Child Restraint System We urge that you carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here.
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE cover directly behind the seat where you are placing the child restraint and attach the tether strap to the anchor- age, being careful to route the tether strap to provide the most direct path between the anchor and the child restraint.
Page 57 keep the belt tight, however, any seat belt system will loosen with time, so check the belt occasionally, and pull it tight if necessary. Seat belts with an automatic locking retractor have a distinctive label on the seat belt webbing. The seat belt must be in the automatic locking mode in order to enable a child restraint to be tightly installed.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To attach a child restraint tether strap: 1. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. Tether Strap Mounting 2. Attach the tether strap hook of the child restraint to the tether anchor and remove slack in the tether strap according to the child restraint manufacturer’s instruc- tions.
Page 59: Engine Break-In Recommendations
ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine in your new vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable. While cruising, brief full-throttle acceleration, within the limits of local traffic laws, contributes to a good break-in.
Page 60: Lock Your Vehicle
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lock Your Vehicle Always remove the keys from the ignition and lock all doors when leaving the vehicle unattended, even in your own driveway or garage. Try to park your vehicle in a well-lit area and never invite theft by leaving articles of value exposed.
Page 61: Safety Checks You Should Make Inside The Vehicle
Safety Checks You Should Make Inside The Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks. Also, if gasoline fumes are detected or if fuel, power steering fluid, or brake fluid leaks are suspected, the cause should be located and corrected immediately.
Page 63 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......67 Inside Day/Night Mirror ....67 Automatic Dimming Inside Mirror —...
Page 64 64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lumbar Support — If Equipped ... .92 Head Restraints ..... . .92 Heated Seats —...
Page 65 To Vary The Speed Setting ....108 To Accelerate For Passing ....108 Overhead Console .
Page 66 66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Roof Luggage Rack — If Equipped ..129 Load Leveling System — If Equipped ..131...
Page 67: Mirrors
MIRRORS Inside Day/Night Mirror Adjust the mirror to center on the view through the rear window. A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjusting Rearview Mirror Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).
Page 68: Equipped
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic and a slight overlap of the view obtained from the inside mirror.
Page 69: Power Remote-Control Mirrors
Power Remote-Control Mirrors The power mirror switch is located on the driver’s door trim panel next to the power door lock switch. A rotary knob selects the left mirror, right mirror, or off position. After selecting a mirror, move the knob in the same direction you want the mirror to move.
Page 70: Hands-Free Communication (Uconnect™) - If
70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE HANDS–FREE COMMUNICATION (UConnect™) — IF EQUIPPED UConnect™ is a voice-activated, hands-free, in- vehicle communications system. UConnect™ allows you to dial a phone number with your cellular phone using simple voice commands (e.g., Call” “Mike” ”Work or Dial” “248-555-1212 ).
Page 71: Operations
UConnect™ Switches The UConnect™ system can be used with any Hands- Free Profile certified Bluetooth™ cellular phone. See www.chrysler.com/uconnect for supported phones. If your cellular phone supports a different profile (e.g., Headset Profile), you may not be able to use any UCon- nect™...
Page 72 To complete the pairing process, you will need to refer- ence your cellular phone owner’s manual. One of the following vehicle specific websites may also provide detailed instructions for pairing with the brand of phone that you have: NOTE: • www.chrysler.com/uconnect • www.dodge.com/uconnect...
Page 73 • www.jeep.com/uconnect The following are general phone to UConnect™ System pairing instructions: • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing and follow the audible prompts. • When prompted, after the voice on beep, say Pair a Phone and follow the audible prompts.
Page 74 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The UConnect™ system will confirm the phone num- ber and then dial. The number will appear in the display of certain radios. Call/Dial by Saying a Name • Press the “Phone” button to begin. •...
Page 75 The UConnect™ system will allow you to enter up to 32 names in the phonebook with each name having up to four associated phone numbers and designations. Each language has a separate 32-name phonebook accessible only in that language. Edit Entries in the UConnect™ Phonebook NOTE: Editing phonebook entries is recommended when vehicle is not in motion.
Page 76 76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE from which you choose. To select one of the entries from the list, press the Voice Recognition button while the UConnect™ system is playing the desired entry and say Delete. • After you enter the name, the UConnect™ system will ask you which designation you wish to delete, home, work, mobile, or pager.
Page 77: Phone Call Features
Phone Call Features The following features can be accessed through the UConnect™ system if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the UConnect™ system. Check with your cellular service provider for the features that you have.
Page 78 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE indicating that the active and hold status of the two calls have switched. Only one call can be placed on hold at one time. Conference Call When two calls are in progress (one active and one on hold), press and hold the ’Phone’...
Page 79: Uconnect™ System Features
• After ignition key is switched to off, a call can continue on the UConnect™ system for certain duration, after which the call is automatically transferred from the UConnect™ system to the mobile phone. • An active call is automatically transferred to the mobile phone after ignition key is switched to off.
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Canada and 060 for Mexico). The number dialed may not be applicable with the available cellular service and area. The UConnect™ system does slightly lower your chances of successfully making a phone call as to that for the cell phone directly.
Page 81 When calling a number with your UConnect™ system that normally requires you to enter in a touch-tone sequence on your cellular phone keypad, you can push the ’Voice Recognition’ button and say the sequence you wish to enter followed by the word Send. For example, if required to enter your pin number followed with a pound 3 7 4 6 #, you can press the ’Voice Recognition’...
Page 82: Advanced Phone Connectivity
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect™ system (while dialing via the cell phone keypad, the user must exercise caution and take precautionary safety measures).
Page 83 Connect or Disconnect Link Between the UConnect™ System and Cellular Phone Your cellular phone can be paired with many different electronic devices, but can only be actively connected with one electronic device at a time. If you would like to connect or disconnect the Blue- tooth™...
Page 84: Things You Should Know About Your Uconnect™ System
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Delete UConnect™ Paired Cellular Phones • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing. • At the next prompt, say Delete and follow the prompts.
Page 85 • UConnect™ phonebook nametag recognition rate is optimized for the voice of the person who stored the name in the phonebook. • You can say O (letter O ) for 0 (zero). 800 must be spoken eight-zero-zero. • Even though international dialing for most number combinations is supported, some shortcut dialing number combinations may not be supported.
Page 86 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87...
Page 88 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 89: Seats
North American English Primary Alternate(s) Zero Add location Add new All of them Confirmation prompts Confirmations prompts Delete a name Delete Language Select language List names List all List paired phones List phones Pager Beeper Phone pairing Pairing Phonebook Phone book Return to main menu Return.
Page 90: Power Seats - If Equipped
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured.
Page 91: Power Reclining Seats - If Equipped
CAUTION! Do not place any article under a power seat as it may cause damage to the seat controls. Power Reclining Seats — If Equipped The recliner control is located on the outboard side of the seat. Power Seat Recline Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 WARNING! Do not ride with the seatback reclined so that the...
Page 92: Lumbar Support - If Equipped
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lumbar Support — If Equipped This feature allows you to increase or decrease the amount of lumbar support. Turn the control lever for- ward to increase and rearward to decrease the desired amount of lumbar support. Lumbar Support Control Lever Head Restraints Head restraints can reduce the risk of whiplash injury in...
Page 93 The controls for each heater are located near the bottom center of the instrument panel. After turning on the ignition, you can choose from High, Off, or Low heat settings. Amber LEDs in the top portion of each switch indicate the level of heat in use. Two LEDs will illuminate for high, one for low, and none for off.
Page 94: Folding Rear Seat
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Rear Seat Folding Rear Seats The rear seatbacks can be folded forward to provide an additional storage area. Pull on the loops shown in the illustration to fold down either or both seatbacks. These loops can be tucked away when not in use.
Page 95: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. First, pull the hood release lever located under the left side of the instrument panel. Hood Release Lever Next, move to the outside of the vehicle and push the safety catch to the left.
Page 96: Lights
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision. You could have a collision. Be sure all hood latches are fully latched before driving. LIGHTS Headlight Switch The headlight switch is located on the left side of...
Page 97: Headlights On With Wipers (Available With Auto Headlights Only)
headlights will stay ON for up to 90 seconds after you turn the ignition switch OFF. To turn the Automatic System OFF, move the headlight switch out of the AUTO (A) position. Headlight Switch NOTE: The engine must be running before the head- lights will come ON in the Automatic mode.
Page 98: Daytime Running Lights (Canada Only)
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you turn the headlights, park lights, or ignition switch on again, the system will cancel the delay. If you turn the headlights off before the ignition, they will turn off in the normal manner. NOTE: The lights must be turned off within 45 seconds of turning the ignition off to activate this feature The Headlight delay time is programmable on vehicles...
Page 99: Multi-Function Lever
Multi-Function Lever The multi-function lever controls the operation of the turn signals, headlight beam selection, and passing lights. The lever is located on the left side of the steering column. Multi-Function Lever Turn Signals Move the Multi-Function Lever up or down and the corresponding turn signal indicator in the instrument cluster flashes to show proper operation of the front and rear turn signal lights.
Page 100: Overhead Console Map/Reading Lights
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overhead Console Map/Reading Lights These lights are mounted between the sun visors on the overhead console. Each light is turned ON by pressing the lens. Press the lens a second time to turn OFF the light.
Page 101: Windshield Wipers And Washers
Interior light Defeat (OFF) Rotate the dimmer control to the extreme bottom “OFF” position. The interior lights will remain off when the doors are open. Parade Mode (Daytime Brightness Feature) Rotate the dimmer control upward to the first detent. This feature brightens all text displays such as the odometer, Electronic Vehicle Information Center (EVIC) —...
Page 102: Intermittent Wiper System
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Turn the windshield wipers off when driving through an automatic car wash. Damage to the windshield wipers may result if the wiper switch is left in any position other than OFF. Intermittent Wiper System Use the intermittent wiper when weather conditions make a single wiping cycle with a variable pause be- tween cycles desirable.
Page 103: Headlights On With Wipers (Available With Auto Headlights Only)
two wipe cycles after releasing the lever and then resume the intermittent interval previously selected. If you activate the washer while the windshield wiper is turned OFF, the wipers will operate for two wipe cycles and then turn OFF. Headlights On with Wipers (Available with Auto Headlights Only) When this feature is active, the headlights will turn on approximately 10 seconds after the wipers are turned on...
Page 104: Tilt/Telescoping Steering Column
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The fluid reservoir will hold nearly 1 gallon (4 liters) of washer fluid when the message “Low Washer Fluid” appears in the Electronic Vehicle Information Center (EVIC) — if equipped. WARNING! Commercially available windshield washer solvents are flammable.
Page 105: Adjustable Pedals - If Equipped
To unlock the steering column, pull the control handle outward. To tilt the steering column, move the steering wheel upward or downward as desired. To lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired. To lock the steering column in position, push the control handle inward until fully engaged.
Page 106: Electronic Speed Control
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Press the switch forward to move the pedals forward (toward the front of the vehicle). Press the switch rearward to move the pedals rearward (toward the driver). • The pedals can be adjusted with the ignition OFF. •...
Page 107: To Activate
To Activate: Push the speed control lever inward (toward the steering column) and release (“ON/OFF”). The indicator light in the lever (and in the instrument cluster on some models) will illu- minate to show that the speed control system is ON. To turn the system OFF, push the lever inward (toward the steering column) again and release.
Page 108: To Vary The Speed Setting
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE speed. To do so, push the lever up and release (RES/ ACCEL), and then remove your foot from the accelerator pedal. To Vary the Speed Setting: When the speed control is set, you can increase speed by pushing the lever up and holding (“RES/ACCEL”).
Page 109: Overhead Console
OVERHEAD CONSOLE The overhead console contains courtesy/reading lights, an optional universal garage door opener (HomeLink ), storage for sunglasses, and an optional power sunroof switch. Overhead Console UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Courtesy/Reading Lights At the forward end of the console are two courtesy/ reading lights.
Page 110: Garage Door Opener (Homelink ) - If
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER (HomeLink ) — IF EQUIPPED The HomeLink Universal Transceiver replaces up to three remote controls (hand held transmitters) that oper- ate devices such as garage door openers, motorized gates, or home lighting. It triggers these devices at the push of a button.
Page 111: Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Programming HomeLink NOTE: When programming a garage door opener, it is advised to park outside the garage. It is also recom- mended that you install a new battery in the hand-held transmitter of the device being programmed. This will allow for quicker training and accurate transmission of the radio-frequency signal.
Page 112 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. Press and hold the two outer HomeLink buttons. Release the buttons only when the EVIC displays “Chan- nels Cleared” (after 20 seconds); however, do not hold the buttons for longer than 30 seconds. Do not repeat this step if programming a second or third hand-held trans- mitter to the remaining HomeLink buttons.
Page 113: Canadian Programming/Gate Programming
NOTE: If your garage door opener fails to respond to the programmed HomeLink Universal Transceiver, and your garage door opener is manufactured after 1995, it may have a multiple security code system (rolling code system). Please proceed to Steps 6–8 to complete the programming of a rolling code equipped device (most common garage door openers require this step.
Page 114: Using Homelink
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If programming a garage door opener or gate operator, it is advised to unplug the device during the cycling process to prevent possible overheating. 3. Continue to press and hold the HomeLink button while you press and release your hand-held transmitter every two seconds until the frequency signal is accepted successfully by HomeLink.
Page 115: Security
For questions or comments, contact HomeLink at: www.homelink.com or 1-800-355-3515. Security If you sell your vehicle, be sure to erase the frequencies by following the “Erasing HomeLink Buttons” instruc- tions in this section. This device complies with part 15 of FCC rules and with RSS-210 of Industry Canada.
Page 116: Opening Sunroof - Express
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.
Page 117: Pinch Protect Override
Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the switch forward and hold for two seconds after the reversal occurs. This allows the sunroof to move towards the closed position. NOTE: Pinch protection is disabled while the switch is pressed.
Page 118: Sunroof Fully Closed
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For vehicles equipped with the EVIC, the power sunroof switch will remain active for up to 60 minutes after the ignition switch is turned off. Opening either front door will cancel this feature. The time is programmable. For details, refer to “Delay Power Off to Accessories Until Exit,”...
Page 119 NOTE: If desired, the power outlet next to the ash receiver tray (if equipped) can be converted by your authorized dealer to provide power with the ignition switch in the LOCK position. Front Power Outlet UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 The center console outlet is powered directly from the battery (power available at all times).
Page 120: Electrical Outlet Use With Engine Off
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The auxiliary outlet is also powered directly from the battery (power available at all times). Items plugged into this outlet may discharge the battery and/or prevent engine starting. Auxiliary Power Outlet Electrical Outlet Use With Engine Off CAUTION! •...
Page 121: Cup Holders
CUP HOLDERS Front Seat Cup Holders The cup holders are located in the forward edge of the center console. Front Seat Cup Holders UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Rear Seat Cup Holders The rear seat cup holders are located in the center armrest between the rear seats.
Page 122: Storage
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Console Features The center console contains a large storage bin. The storage bin contains a four-slot coin holder (designed to hold various size coins) and a rubber mat at the bottom of the bin for noise control.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 The 60/40 split-folding rear seat provides cargo-carrying versatility. The seatbacks fold down easily by pulling nylon tabs between the seatbacks and the bolsters. When the seats are folded down, they provide a continuous, nearly flat extension of the removable tri-fold load floor.
Page 124 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Load Floor Partially Folded Load Floor Fully Folded...
Page 125 Rollaway Tonneau Cover — If Equipped The removable rollaway tonneau cover mounts in the cargo area behind the top of the rear seats. The tonneau cover, when extended, covers the cargo area to keep items out of sight. Notches in the trim panels near the liftgate opening secure the extended tonneau cover in place.
Page 126 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To install the tonneau cover, position it in the vehicle so that the flat side of the housing faces upward. Then, insert either the left or the right spring-loaded post (located on the ends of the tonneau cover housing) into the left or the right front attachment point shown.
Page 127 Waterproof Liner The optional waterproof liner can be placed over the lower load floor. Waterproof Liner UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Cargo Organizer The optional cargo organizer can also be placed into the lower load floor. Lift the handle and pull to open the cargo organizer.
Page 128 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Tie-Down Hooks The tie-downs located on cargo area floor and on the rear trim panels should be used to safely secure loads when vehicle is moving. WARNING! • Cargo tie-down hooks are not safe anchors for a child seat tether strap.
Page 129 • Place as much cargo as possible in front of the rear axle. Too much weight or improperly placed weight over or behind the rear axle can cause the rear of the vehicle to sway. • Do not pile luggage or cargo higher than the top of the seatback.
Page 130 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To adjust, remove, or install the crossbars, proceed as follows: Roof Luggage Rack 1. Flip the lever on the end of the crossbar upward. 2. Turn the lever counter clockwise to loosen the lower clamp.
Page 131 CAUTION! • To avoid damage to the roof rack and vehicle, do not exceed the maximum roof rack load capacity of 150 lbs (68 kg). Always distribute heavy loads as evenly as possible and secure the load appropriately. • Long loads, which extend over the windshield, such as wood panels or surfboards, or loads with large frontal area should be secured to both the front and rear of the vehicle.
Page 133: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel And Controls ... . 137 Base Instrument Cluster ....138 Premium Instrument Cluster —...
Page 134 134 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - CD Mode ..164 Operation Instructions - Auxiliary Mode ..166 Operating Instructions - Hands Free Phone — If Equipped ......167 Operating Instructions - Satellite Radio —...
Page 135 Video Entertainment System (Sales Code XRV) — If Equipped ......183 Satellite Radio — If Equipped ... . . 184 System Activation .
Page 136 136 UNDERSTANDING YOUR INSTRUMENT PANEL Adding Washer Fluid ....202 Electric Rear Window Defroster ... 202...
Page 137: Instrument Panel And Controls
INSTRUMENT PANEL AND CONTROLS 1 — Air Outlet 2 — Instrument Cluster 3 — Rear Wiper/Washer Switch 4 — Hazard Switch 5 — Electronic Stability Program Off But- ton* / Traction Control System Off Button* UNDERSTANDING YOUR INSTRUMENT PANEL 137 6 —...
Page 138: Base Instrument Cluster
138 UNDERSTANDING YOUR INSTRUMENT PANEL BASE INSTRUMENT CLUSTER...
Page 139: Premium Instrument Cluster - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 139 PREMIUM INSTRUMENT CLUSTER — IF EQUIPPED...
Page 140: Instrument Cluster Descriptions
140 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the ON position. 2. Trip Odometer Button Base Cluster The word TRIP will appear when this button is pressed. Push in and hold the button for two seconds when the trip odometer displays to reset it to 0 miles (kilometers).
Page 141 7. Electronic Throttle Control (ETC) Light This light will turn on briefly as a bulb check when the ignition switch is turned ON. This light will also turn on while the engine is running if there is a problem with the Elec- tronic Throttle Control system.
Page 142 142 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, see Section 7 of this manual.
Page 143 and driving to the prevailing road conditions, and do not switch off the ESP or TCS — if equipped. (See page 230 for more information.) (See page 233 for more information.) 13. Electronic Stability Program (ESP) / Brake Assist System (BAS) Malfunction Indicator Light — If Equipped The yellow ESP/BAS malfunction indicator light will turn on when the key in the...
Page 144 144 UNDERSTANDING YOUR INSTRUMENT PANEL 18. Front Fog Light Indicator — If Equipped This light will turn on when the front fog lights are ON. (See page 98 for more information.) 19. Electronic Vehicle Information Center Display — If Equipped This display shows the Electronic Vehicle Information Center (EVIC) messages when the appropriate conditions exist.
Page 145 NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level condi- tions. The vehicle should have service performed, and the brake fluid level checked. Immediate repair is necessary if brake failure is indicated. WARNING! Driving a vehicle with the brake light on is danger- ous.
Page 146 146 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pres- sure label, you should determine the proper tire inflation pressure for those tires.) As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS)
Page 147 23. Anti-Lock Brake Light — If Equipped This light monitors the Anti-Lock Brake System. The light will turn on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the brake system is not functioning and service is required.
Page 148: Electronic Vehicle Information Center (Evic) - If Equipped
148 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) – IF EQUIPPED Electronic Vehicle Information Center The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display. It is located in the instrument cluster below the speedometer. Vehicles equipped with steering wheel mounted buttons (de- scribed in this section) are also equipped with the EVIC.
Page 149: Electronic Vehicle Information Center (Evic) Displays
Press the FUNCTION SELECT button to accept a selection. The FUNCTION SELECT button also advances the radio to the next preset station, changes the side of the tape being FUNC- played (if so equipped), or changes the current TION CD track being played (if so equipped) when SELECT Button the EVIC is in the Compass/Temp/Audio...
Page 150: Trip Functions
150 UNDERSTANDING YOUR INSTRUMENT PANEL • Left/Right Front Door Ajar (one or more, with a single chime if speed is above 1 mph [1.6 km]) • Left/Right Rear Door Ajar (one or more, with a single chime if speed is above 1 mph [1.6 km]) •...
Page 151 Vehicles with the 5.7L Multi-Displacement System (MDS) may be equipped with the FUEL SAVER MODE in the Trip Functions of the EVIC. The FUEL SAVER MODE message will display above the average fuel economy in the EVIC display. This message will appear whenever MDS allows the engine to operate on four cylinders, which will vary depending on driving habits and vehicle usage.
Page 152 152 UNDERSTANDING YOUR INSTRUMENT PANEL and average fuel economy, according to the current fuel tank level. DTE cannot be reset through the FUNCTION SELECT button. NOTE: Significant changes in driving style or vehicle loading will greatly affect the actual drivable distance of the vehicle, regardless of the DTE displayed value.
Page 153: Compass Display
Compass Display The compass readings indicate the direction the vehicle is facing. Press and release the compass button to display one of eight com- pass readings and the outside temperature. COM- PASS Button Automatic Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually.
Page 154: Telephone - If Equipped
154 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Turn the ignition switch ON. 2. Press and hold the compass button for approximately 2 seconds. 3. Press the SCROLL button until “Compass Variance” message and the last variance zone number displays in the EVIC. 4.
Page 155 • Call status: Incoming call, connecting, connected, air time in minutes and seconds, call ended, call failed, roaming, and no phone connection. • UConnect Active. • Caller ID phone number display. When the appropriate conditions exist, and if supported by the cell phone, the EVIC will display the following telephone symbols: The EVIC displays this symbol to indicate the signal strength of the UConnect™...
Page 156: Navigation - If Equipped
156 UNDERSTANDING YOUR INSTRUMENT PANEL The EVIC displays this symbol to indicate the battery strength of the UConnect™ phone. Battery Strength The EVIC displays this symbol to indicate that a phone connection has been made. Call in Progress The EVIC displays this symbol to indicate that the UConnect™...
Page 157 Press and release the MENU button until Personal Set- tings displays in the EVIC. Use the SCROLL button to display one of the following choices: “Language” When in this display you may select one of five lan- guages for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 158 158 UNDERSTANDING YOUR INSTRUMENT PANEL on lock/unlock feature. To make your selection, press and release the FUNCTION SELECT button until “ON” or “OFF” appears. “Flash Lights with Remote Key Lock” When ON is selected, the front and rear turn signals will flash when the doors are locked or unlocked with the remote keyless entry transmitter.
Page 159: Radio General Information
door will cancel this feature. To make your selection, press and release the FUNCTION SELECT button until “Off,” “45 sec.,” “5 min.,” “10 min.,” “30 min.,” or “60 min.” appears. “Confirmation of Voice Commands” — If Equipped When ON is selected, all voice commands from the UConnect™...
Page 160: Electrical Disturbances
160 UNDERSTANDING YOUR INSTRUMENT PANEL Electrical Disturbances Radio waves may pick up electrical disturbances during transmission. They mainly affect the wave amplitude, and thus remain a part of the AM reception. They interfere very little with the frequency variations that carry the FM signal.
Page 161: Sales Code Ref - Am/Fm/Cd (Single Disc) Radio With Optional Satellite Radio And Hands Free Phone Capability
SALES CODE REF — AM/FM/CD (SINGLE DISC) RADIO WITH OPTIONAL SATELLITE RADIO AND HANDS FREE PHONE CAPABILITY NOTE: The radio sales code is located on the lower right side of your radio faceplate. REF Radio UNDERSTANDING YOUR INSTRUMENT PANEL 161 Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 162 162 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Button (Radio Mode) Press and release the SEEK button to search for the next listenable station in either AM/FM or Satellite (if equipped) mode. Press the right side of the button to seek up and the left side to seek down. The radio will remain tuned to the new station until you make another selec- tion.
Page 163 4. Adjust the minutes using the right side Tune/Audio control. 5. To exit, press any button/knob or wait 5 seconds. RW/FF (Radio Mode) Pressing the rewind/fast forward button causes the tuner to search for the next frequency in the direction of the arrows.
Page 164: Operation Instructions - Cd Mode
164 UNDERSTANDING YOUR INSTRUMENT PANEL selected within 5 seconds after pressing the SET button, the station will continue to play but will not be stored into push-button memory. You may add a second station to each push-button by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window.
Page 165 SEEK Button (CD Mode) Press the right side of the SEEK button for the next track on the CD. Press the left side of the button to return to the beginning of the current track, or return to the beginning of the previous track if the CD is within the first 10 seconds of the current selection.
Page 166: Operation Instructions - Auxiliary Mode
166 UNDERSTANDING YOUR INSTRUMENT PANEL Press the RND button a second time to stop Random Play. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3 player, cassette player, or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 167: Operating Instructions - Hands Free Phone - If Equipped
Mode Button (Auxiliary Mode) Press the mode button repeatedly to select between the CD player and Satellite Radio (if equipped). Operating Instructions - Hands Free Phone — If Equipped Refer to the “HANDS FREE PHONE (UConnect™)” section of the Owner’s Manual. Operating Instructions - Satellite Radio —...
Page 168: Operating Instructions - Radio Mode
168 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio.
Page 169 3. After the hours are adjusted, press the right side Tune/Audio control to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side Tune/Audio control. 5. To exit, press any button/knob or wait 5 seconds. INFO Button (Radio Mode) Press the INFO button for an RBDS station (one with call letters displayed).
Page 170 170 UNDERSTANDING YOUR INSTRUMENT PANEL Press the rotary TUNE control again to exit setting tone, balance, and fade. RND/PTY Button (Radio Mode) Pressing this button once will turn on the PTY mode for 5 seconds. If no action is taken during the 5-second time out, the PTY icon will turn off.
Page 171: Operating Instructions - Tape Player
station with the same selected PTY name. The PTY function only operates when in the FM mode. If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station. NOTE: If you have selected a PTY with the tune knob, simply pressing the tune button in will go directly to a “PTY seek”.
Page 172: Tape Eject
172 UNDERSTANDING YOUR INSTRUMENT PANEL Tape Eject Press this button and the cassette will disen- gage and eject from the radio. Scan Button Press this button to play 10 seconds of each selection. Press the scan button a second time to cancel the feature. Changing Tape Direction If you wish to change the direction of tape travel (side being played), press Preset 6.
Page 173: Load/Eject Button (Cd Mode For Cd Audio Play)
Inserting Compact Disc(s) CAUTION! This CD player will accept 4 3/4 inch (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. You may eject a disc with the radio OFF. If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc.
Page 174 174 UNDERSTANDING YOUR INSTRUMENT PANEL Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc. Press and hold the LOAD/EJT button for 5 seconds and all CDs will be ejected from the radio. If you have ejected a disc and have not removed it within 15 seconds, it will be reloaded.
Page 175: Notes On Playing Mp3 Files
Press and hold the FF button to fast forward through the tracks. Release the FF button to stop the fast forward feature. If the RW button is pressed, the current track will reverse to the beginning of the track and begin playing. Press the RND button a second time to stop Random Play.
Page 176 176 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats The radio will recognize only files with the *.mp3 exten- sion as MP3 files. Non-MP3 files named with the *.mp3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
Page 177: Operation Instructions
To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a single-session disc, enable the Disc at Once option before writing to the disc. Operation Instructions - (CD Mode for MP3 and WMA Audio Play) SEEK Button (CD Mode for MP3 and WMA Play) Pressing the right side of the SEEK button plays the next...
Page 178 178 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button (CD Mode for MP3 Play) Press and INFO button while playing MP3 or WMA disc. The radio scrolls through the following TAG information: Song Title, Artist, File Name, and Folder Name (if avail- able).
Page 179: Sales Code Rec - Am/Fm/Cd (6-Disc) Radio With Navigation System
Operating Instructions - Video Entertainment System (VES) (If Equipped) Refer to separate “Video Entertainment System (VES) Guide.” SALES CODE REC — AM/FM/CD (6–DISC) RADIO WITH NAVIGATION SYSTEM REC Radio Satellite Navigation Radio with CD Player with MP3 Capability (REC) - combines a Global-Positioning System-based navigation system with an integrated color UNDERSTANDING YOUR INSTRUMENT PANEL 179 screen to provide maps, turn identification, selection...
Page 180 180 UNDERSTANDING YOUR INSTRUMENT PANEL 1. At the Main Menu screen, highlight “Clock Setup” and press ENTER OR press and hold for 3 seconds the TIME button on the unit’s faceplate. The Clock Setup screen appears. 2. To show the GPS clock, select “Displayed Clock: GPS Clock”...
Page 181 1. At the Clock Setup screen highlight “Displayed Clock: User Defined Clock”. 2. To increase the clock by hours, make sure “HR +” is highlighted and press ENTER. Press ENTER again to increase the clock by another hour. You will see on the “User Defined Time”...
Page 182: Audio Clock Display
182 UNDERSTANDING YOUR INSTRUMENT PANEL Audio Clock Display Select this option to change the size of the clock on the audio screens. 1. When you are at an audio screen, quickly press the TIME button on the navigation faceplate. 2. In this example the large clock appears on the screen. 3.
Page 183: Video Entertainment System (Sales Code Xrv) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 183 VIDEO ENTERTAINMENT SYSTEM (SALES CODE XRV) — IF EQUIPPED The optional VES™ (Video Entertainment System) con- sists of a DVD player and LCD (liquid crystal display) screen, a battery-powered remote control, and two head- sets. The system is located in the center console storage bin under the armrest lid.
Page 184: Satellite Radio - If Equipped
184 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Control Location SATELLITE RADIO — IF EQUIPPED Satellite radio uses direct satellite to receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius™ Satel- lite Radio. This service offers over 100 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.
Page 185: Selecting Satellite Mode In Ref, Raq, And Rak Radios
simultaneously for 3 seconds. The first four digits of the twelve-digit ESN/SID number will display. Press the SEEK UP button to display the next four digits. Continue to press the SEEK UP button until all twelve ESN/SID digits display. The SEEK DOWN will page down until the first four digits display.
Page 186: Selecting A Channel
186 UNDERSTANDING YOUR INSTRUMENT PANEL Selecting a Channel Press and release the SEEK or TUNE knob to search for the next channel. Press the top of the button to search up and the bottom of the button to search down. Holding the TUNE button causes the radio to bypass channels until the button is released.
Page 187: Pty Button Seek
PTY Button SEEK When the desired program is obtained, press the SEEK button within five seconds. The channel will change to the next channel that matches the program type selected. Satellite Antenna To ensure optimum reception, do not place items on the roof around the rooftop antenna location.
Page 188: Radio Operation
188 UNDERSTANDING YOUR INSTRUMENT PANEL Center (EVIC). The EVIC features a driver-interactive display. This is located in the instrument cluster below the speedometer. The VOLUME button controls the sound level of the sound system. Press the top of the VOLUME button to increase the sound level. Press the bottom of the VOLUME button to VOL- decrease the sound level.
Page 189: Tape Player Operation
Tape Player Operation Press the top of the SCROLL button once to listen to the next track on the cassette. Press the bottom of the SCROLL button once either to listen to the beginning of the current track or to listen to the beginning of the previous track if it is within 5 seconds after the current track begins to play.
Page 190: Cd/Dvd Disc Maintenance
190 UNDERSTANDING YOUR INSTRUMENT PANEL 5. A loose tape should be corrected before use. To rewind a loose tape, insert the eraser end of a pencil into the tape drive gear and twist the pencil in the required directions. Maintain your cassette tape player. The head and capstan shaft in the cassette player can pick up dirt or tape deposits each time a cassette is played.
Page 191: Radio Operation And Cellular Phones
RADIO OPERATION AND CELLULAR PHONES Under certain conditions, the cellular phone being On in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the cellular phone antenna. This condition is not harmful to the radio.
Page 192 192 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control The rotary knob in the center controls air temperature. Rotate the control to the left for cooler air temperature and to the right for warmer air tempera- ture. Rotating the control to the ex- treme left provides the coldest setting.
Page 193: Automatic Temperature Control - If Equipped
• Panel Air flows through the outlets located in the instrument panel. Air flows through the regis- ters in the back of the center console to the rear seat passengers. These registers can be closed to block airflow. • Recirculation Control The mode control knob also controls the recirculation feature.
Page 194 194 UNDERSTANDING YOUR INSTRUMENT PANEL the controls on the climate control, from a dual sun- sensor located in the top of the instrument panel, from an infrared sensor located in the face of the climate control, and from various sensors located throughout the vehicle. The controls on the climate control provide the system with operator input.
Page 195 The system will automatically control recir- culation. However, pressing the Recircula- tion Control button will temporarily put the system in recirculation mode (ten minutes). This can be used when outside conditions such as smoke, odors, dust, or high humidity are present. Activating recirculation will cause the LED in the control button to illuminate.
Page 196 196 UNDERSTANDING YOUR INSTRUMENT PANEL...
Page 197 The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control knob (on the right) to one of the following positions. • Defrost Air is directed to the windshield through the outlets at the base of the windshield. Air is also directed to the front door windows through the side window demister grilles.
Page 198: Operating Tips
198 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: To control the air conditioning manually, the mode selector must be moved out of the AUTO position. • Recirculation Control This button can be used to block out smoke, odors, dust, high humidity, or if rapid cooling is desired.
Page 199 system lubrication to minimize the possibility of com- pressor damage when the system is started again. Window Fogging Interior fogging on the windshield can be quickly re- moved by turning the mode selector to Defrost. The Defrost/Floor mode can be used to maintain a clear windshield and provide sufficient heating.
Page 200 200 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...
Page 201: Rear Window Features
REAR WINDOW FEATURES Rear Wiper Operation The rear wiper is operated by the rear wiper/ washer switch. The switch is located near the top center of the instrument panel. An indicator in the switch illuminates when the rear wiper is on. Rear Wiper/Washer Switch To use the rear wiper, push the left side of the rear wiper/washer switch in and release.
Page 202 202 UNDERSTANDING YOUR INSTRUMENT PANEL Adding Washer Fluid The windshield washer and rear window washer share the same fluid reservoir. The reservoir is located in the front of the engine compartment on the passenger side of the vehicle. Be sure to check the fluid level at regular intervals.
Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 203 CAUTION! To avoid damaging the electrical conductors of the rear window defroster, do not use scrapers, sharp instruments, or abrasive window cleaners on the interior surface of the window. Labels can be peeled off after soaking with warm water.
Page 205: Starting And Operating 205
STARTING AND OPERATING CONTENTS Starting Procedures ....208 Automatic Transmission ....209 Normal Starting .
Page 206 206 STARTING AND OPERATING Power Steering ......229 Multi Displacement System (MDS) - 5.7L Engine Only ......230 Traction Control System (TCS) —...
Page 207 Premium System — If Equipped ..258 General Information ....261 Fuel Requirements ..... 261 2.7L Engine .
Page 208: Starting Procedures
208 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
Page 209: Automatic Transmission
Automatic Transmission The gear selector must be in the NEUTRAL or PARK position before you can start the engine. Apply the brakes before shifting into any driving gear. Normal Starting Normal Starting of either a cold or a warm engine is obtained without pumping or depressing the accelerator pedal.
Page 210: After Starting
210 STARTING AND OPERATING WARNING! • Never pour fuel or other flammable liquid into the throttle body air inlet opening in an attempt to start the vehicle. This could result in flash fire causing serious personal injury. • Do not attempt to push or tow your vehicle to get it started.
Page 211: Engine Block Heater - If Equipped
ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms engine coolant and permits quicker starts in cold weather. Connect the cord to a standard 110-115 volt AC electrical outlet with a grounded, three-wire extension cord. The engine block heater cord is routed under the hood on the driver side of the vehicle.
Page 212: Automatic Transmission - General Information
212 STARTING AND OPERATING WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in re- verse.
Page 213: Brake/Transmission Shift Interlock System
The selector lever is automatically locked while in the P (Park) position. To move the selector lever out of the P (Park) position, the brake pedal must be firmly depressed before the shift lock will release. Shift the selector lever to the desired position only when the engine is idling normally and the brake pedal is applied.
Page 214: Speed Automatic Transmission
214 STARTING AND OPERATING Brake Interlock Override For electrical system malfunctions, there is an override for the interlock system. In order to override this system the key must be in the ignition with the switch in the ACC or ON positions. Remove the rubber storage tray from the bin located to the right of the selector lever.
Page 215 Gear Ranges P (Park) P (Park) supplements the parking brake by locking the transmission. The engine can be started in this range. Never use P (Park) while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range.
Page 216 216 STARTING AND OPERATING R (Reverse) For moving the vehicle rearward. Always stop before moving the lever to R (Reverse), except when rocking the vehicle. N (Neutral) Engine may be started in this range. CAUTION! Coasting the vehicle, or driving for any other reason with selector lever in NEUTRAL can result in trans- mission damage.
Page 217 3 (Third) This range eliminates shifts into Overdrive. The trans- mission will operate normally in First, Second and Third while in this range. The “3” position should also be used when descending steep grades to prevent brake system distress. NOTE: Using the “3” range while operating the vehicle under heavy operating conditions will improve perfor- mance and extend transmission life by reducing exces- sive shifting and heat build up.
Page 218 218 STARTING AND OPERATING clutch is not engaged, it may seem as if the transmis- sion is not shifting into “Overdrive” when cold. This is considered a normal condition. Pulling the selector lever into the “3” position will show that the transmis- sion is able to shift into and out of “Overdrive.”...
Page 219: Speed Automatic Transmission
5 Speed Automatic Transmission Shifting from D (Drive) to P (Park) or R (Reverse) (or from P or R to D) should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake when moving the selector lever between these gears.
Page 220 220 STARTING AND OPERATING The following indicators should be used to ensure that you have engaged the selector lever into the P (Park) position: • When shifting into P (Park) move the lever all the way forward until it stops, and is fully seated. •...
Page 221 D (Drive) This range should be used for most city and highway driving. It provides the smoothest upshifts and down- shifts and best fuel economy. The transmission automatically upshifts through fifth gear. The D (Drive) position provides optimum driving characteristics under all normal operating conditions. When frequent transmission shifting occurs when using the Overdrive range, such as when operating the vehicle under heavy loading conditions (in hilly terrain, travel-...
Page 222 222 STARTING AND OPERATING Delayed Shifts in Cold Temperatures During cold temperature operation, you may notice delayed upshifts depending on engine and transmission temperature as well as vehicle speed. This feature im- proves warm up time of the engine and transmission to achieve maximum efficiency.
Page 223: Autostick - If Equipped
times. Follow the reset procedure described under “Tem- porary Transmission Limp Home Mode” in this section. In Permanent Limp Home Mode, P (Park), R (Reverse), and N (Neutral) will continue to operate. Second gear will operate in the D (Drive) shifter position. The mal- function indicator light may illuminate.
Page 224: Driving On Slippery Surfaces
224 STARTING AND OPERATING CAUTION! All wheels must have the same size and type tires. Unequal tire sizes must not be used. Unequal tire size may cause failure of the front differential and/or the transfer case. DRIVING ON SLIPPERY SURFACES Acceleration Rapid acceleration on snow covered, wet, or other slip- pery surfaces may cause the rear wheels to pull errati-...
Page 225: Parking Brake
PARKING BRAKE The parking brake should always be applied when the driver is not in the vehicle. WARNING! Never use Park position on an automatic transmis- sion as a substitute for the parking brake. Always apply parking brake fully when parked to guard against vehicle movement and possible injury or damage.
Page 226: Brake System
226 STARTING AND OPERATING NOTE: This light only shows that the parking brake is applied. It does not show the degree of brake application. WARNING! • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
Page 227 The electronic brake force distribution (EBD) prevents the rear wheels from over-braking and provides greater control of available braking forces applied to the rear axle. When the vehicle is driven over 7 mph (11 km/h), you may also hear a slight clicking sound as well as some related motor noises.
Page 228 228 STARTING AND OPERATING WARNING! • The Anti-Lock Brake System contains sophisticated electronic equipment that may be susceptible to inter- ference caused by improperly installed or high output radio transmitting equipment. This interference can cause possible loss of anti-lock braking capability. In- stallation of such equipment should be performed by qualified professionals.
Page 229: Power Steering
Brake Force Distribution (EBD) systems are not function- ing. Immediate repair to the ABS system is required. POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost.
Page 230: Multi Displacement System (Mds) - 5.7L Engine Only
230 STARTING AND OPERATING MULTI DISPLACEMENT SYSTEM (MDS) - 5.7L Engine Only This feature offers improved fuel economy by shutting off four of the engine’s eight cylinders during light load and cruise conditions. The system is automatic with no driver inputs or additional driving skills required. NOTE: The MDS system may take some time to return to full functionality after a battery disconnect.
Page 231 acceleration, ease up on the accelerator and apply as little throttle as possible. Be sure to adapt your speed and driving to the prevailing road conditions. The TCS OFF button is located in the center of the instrument panel. To turn OFF the TCS, momentarily press the button and the TCS Indicator Light will illumi- nate.
Page 232: Brake Assist System (Bas) - If Equipped
232 STARTING AND OPERATING BRAKE ASSIST SYSTEM (BAS) — IF EQUIPPED WARNING! The BAS (Brake Assist System) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevail- ing road conditions. The BAS cannot prevent acci- dents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 233: Electronic Stability Program (Esp) - If Equipped
ELECTRONIC STABILITY PROGRAM (ESP) — IF EQUIPPED WARNING! The ESP (Electronic Stability Program) cannot pre- vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. The ESP cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 234 234 STARTING AND OPERATING The ESP OFF button is located in the center of the instrument panel. To turn OFF the ESP, momentarily press the ESP OFF button and the ESP/TCS Indicator Light will illuminate. To turn the system ON again, momentarily press the ESP OFF button and the indicator light will turn OFF.
Page 235: Synchronizing Esp
CAUTION! If the vehicle is towed with the front axle raised, the engine must be shut off (key in the ignition switch to the OFF/LOCK or ACC position). Otherwise, the ESP will immediately be engaged and will apply the rear wheel brakes.
Page 236: Tire Safety Information
236 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. • European Metric tire sizing is based on European design standards.
Page 237 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm) 65 = Aspect Ratio in Percent (%)
Page 238 238 STARTING AND OPERATING Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions.
Page 239: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code located on the white sidewall side of the tire. DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 240: Tire Loading And Tire Pressure
240 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the:...
Page 241 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading Information”...
Page 242 242 STARTING AND OPERATING manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. NOTE: The following table shows examples on how to calculate total load, cargo/luggage, and towing capaci- ties of your vehicle with varying seating configurations and number and size of occupants.
Page 243 STARTING AND OPERATING 243...
Page 244: Tires - General Information
244 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 245: Tire Inflation Pressures
2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
Page 246 246 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 247: Radial-Ply Tires
WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail. You could have a serious accident. Don’t drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).
Page 248: Limited Use Spare - If Equipped
248 STARTING AND OPERATING Do not install a wheel cover or attempt to mount a conventional tire on the compact spare wheel, since the wheel is designed specifically for the compact spare. Do not install more than one compact spare tire/wheel on the vehicle at any given time.
Page 249: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure someone. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) for more than 30 seconds continuously when you are stuck, and don’t let anyone near a spinning wheel, no matter what the speed.
Page 250: Life Of Tire
250 STARTING AND OPERATING Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.
Page 251: Alignment And Balance
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combina- tions of unapproved tires and wheels may change suspension dimensions and performance charac- teristics, resulting in changes to steering, han- dling, and braking of your vehicle.
Page 252: Self-Sealing Tires - If Equipped
252 STARTING AND OPERATING SELF–SEALING TIRES — IF EQUIPPED A non-hardening viscous sealant applied to the inner liner of each tire fills punctures up to 0.19 in. (5 mm) to minimize the loss of air pressure. This contributes to the safety of the vehicle by significantly reducing the prob- ability of a roadside stop due to a flat tire.
Page 253: Snow Tires
NOTE: In order to avoid damage to tires, chains, and your vehicle do not drive for a prolonged period of time on dry pavement. Observe the tire chain manufacturer’s instructions on method of installation, operating speed, and conditions for usage. Always use the lower suggested operating speed if both the chain manufacturer and vehicle manufacture suggest a maximum speed.
Page 254: Tire Pressure Monitor System (Tpms) - If Equipped
254 STARTING AND OPERATING is permissible if desired. Also, correct for anything caus- ing rapid or unusual wear prior to performing the tire rotation. The suggested rotation method is the “forward-cross” shown in the following diagram. TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF EQUIPPED •...
Page 255 • The TPM System will warn the driver of a low tire pressure if the tire pressure falls below the low- pressure warning limit for any reason, including low temperature effects. • The TPM System will continue to warn the driver of low tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above the recommended cold placard pressure.
Page 256: Base System - If Equipped
256 STARTING AND OPERATING CAUTION! • The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style.
Page 257 monitor tire pressure levels. Sensors, mounted to each wheel as part of the valve stem, transmit tire pressure readings to the Receiver Module. NOTE: It is particularly important for you to check the tire pressure in all of the tires on your vehicle regularly and to maintain the proper pressure.
Page 258: Premium System - If Equipped
258 STARTING AND OPERATING Telltale Light will remain ON and a chime will still sound each ignition key cycle. Once you repair or replace the original road tire, and reinstall it on the vehicle in place of the compact spare, the TPMS will update automatically and the Tire Pressure Monitoring Telltale Light will turn OFF, as long no tire pressure is below the low-pressure warning limit in any of the four active road tires.
Page 259 recommended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flashing, and the Tire Pressure Monitoring Telltale Light will turn off. The vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information.
Page 260 260 STARTING AND OPERATING NOTE: You can change the pressure units to display in PSI, kPA, or BAR. Refer to “Language,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Sec- tion 4 of this manual for details. If the ignition key is cycled, this sequence will repeat, providing the system fault still exists.
Page 261: General Information
General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration.
Page 262: Reformulated Gasoline
If you experience these symptoms, try another brand of “regular” gasoline be- fore considering service for the vehicle. Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) which...
Page 263: Starting And Operating 263
Problems that result from using methanol/gasoline or E85 Ethanol blends are not the responsibility of the manufacturer. While MTBE is an oxygenate made from Methanol, it does not have the negative effects of Metha- nol. MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase the octane num- ber.
Page 264: Carbon Monoxide Warnings
264 STARTING AND OPERATING malfunctioning and may require immediate service. Contact your dealer for service assistance. • The use of fuel additives, which are now being sold as octane enhancers, are not recommended. Most of these products contain high concentrations of methanol. Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives are not the responsibility of the manufacturer.
Page 265: Adding Fuel
ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. Push in on the left side (near the edge) of the fuel filler door to access the fuel filler cap. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.
Page 266 266 STARTING AND OPERATING CAUTION! • Damage to the fuel system or emission control system could result from using an improper fuel tank filler tube cap (gas cap). • A poorly fitting gas cap could let impurities into the fuel system. •...
Page 267: Loose Fuel Filler Cap Message
Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “Check Gascap” message will display in the Electronic Vehicle Information Center (EVIC) — if equipped. If this occurs, tighten the fuel filler cap properly and press the odometer reset button to turn off the message.
Page 268: Gross Vehicle Weight Rating (Gvwr)
268 STARTING AND OPERATING • Month Day and Hour of Manufacture (MDH) The bar code allows a computer scanner to read the Vehicle Identification Number (VIN). Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, and cargo.
Page 269 driving. If weighing the loaded vehicle shows that you have exceeded either GAWR, but the total load is within the specified GVWR, you must redistribute the weight. Improper weight distribution can have an adverse effect on the way your vehicle steers and handles and the way the brakes operate.
Page 270: Trailer Towing
270 STARTING AND OPERATING TRAILER TOWING In this section, you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer, carefully review this information to tow your load as efficiently and safely as possible.
Page 271 Tongue Weight (TW) Tongue weight (TW) is the downward force exerted on the hitch ball by the trailer. In most cases it should not be less than 10% or more than 15% of the trailer load. You must consider this as part of the load on your vehicle. Frontal Area Frontal area is the maximum height and maximum width of the front of a trailer.
Page 272 272 STARTING AND OPERATING WARNING! • An improperly adjusted Weight Distributing Hitch system may reduce handling, stability, braking performance, and could result in an acci- dent. • Weight Distributing Systems may not be compat- ible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer for additional infor- mation.
Page 273: Trailer Hitch Classification
Improper Adjustment of Weight Distributing System Trailer Hitch Classification Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package. See your authorized dealer for package content. The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the...
Page 274 274 STARTING AND OPERATING Engine/Transmission 2.7L Automatic 3.5L & 5.7L Automatic Frontal Area Max. GTW (Gross Trailer 22 SQ. FT. (2.04 square Up to 2 persons & Lug- meters) gage 1,000 lbs (454 kg) 22 SQ. FT. (2.04 square Up to 3 persons & Lug- meters) gage 1,000 lbs (454 kg) 22 SQ.
Page 275: Trailer And Tongue Weight
Engine/Transmission 40 SQ. FT. (3.72 square 5.7L Automatic with trailer tow package 40 SQ. FT. (3.72 square 40 SQ. FT. (3.72 square 40 SQ. FT. (3.72 square Refer to local laws for maximum trailer towing speeds. NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the “Tire and Loading Information”...
Page 276: Towing Requirements
276 STARTING AND OPERATING Never exceed the maximum tongue weight stamped on your bumper or trailer hitch. Consider the following items when computing the weight on the rear axle of the vehicle: • The tongue weight of the trailer. • The weight of any other type of cargo or equipment put in or on your vehicle.
Page 277 Perform the maintenance listed in Section 8 of this manual. When towing a trailer, never exceed the GAWR, or GCWR, ratings. WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel.
Page 278 278 STARTING AND OPERATING Towing Requirements — Tires − Do not attempt to tow a trailer while using a compact spare tire. − Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle. Refer to the “Tires–General Information”...
Page 279 WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.
Page 280: Towing Tips
280 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping, and backing the trailer in an area located away from heavy traffic. Towing Tips — Automatic Transmission The “D” range can be selected when towing. However, if frequent shifting occurs while in this range, the “3”...
Page 281 Towing Tips — Electronic Speed Control (If Equipped) − Don’t use in hilly terrain or with heavy loads. − When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed. −...
Page 282: Recreational Towing (Behind Motorhome, Etc.)
282 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat towing with all four wheels on the ground) Recreational towing for this vehicle is not recommended. NOTE: If the vehicle requires towing, make sure all four wheels are off the ground.
Page 283 WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....284 If Your Engine Overheats ....284 Jacking And Tire Changing .
Page 284: Hazard Warning Flasher
284 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The hazard flasher switch is located in the center of the instrument panel below the center air outlets. Hazard Flasher Switch To engage the Hazard Warning Flashers, depress the switch on the instrument panel. When the Hazard Warn- ing Switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emer- gency.
Page 285: What To Do In Emergencies 285
control to maximum heat, the Mode control to floor, and the fan control to HI. This allows the heater core to act as a supplement to the radiator and aids in removing heat from the engine cooling system. CAUTION! Driving with a hot cooling system could damage your vehicle.
Page 286: Jacking And Tire Changing
286 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 287: Jack Location/Spare Tire Stowage
WHAT TO DO IN EMERGENCIES 287 5. Passengers should not remain in the vehicle when the vehicle is being jacked. 6. Block both the front and rear of the wheel diagonally opposite the jacking position. For example, if changing the right front tire, block the left rear wheel. Jack Location/Spare Tire Stowage The jack and spare tire are both stowed under a hinged access cover in the load floor in the cargo area.
Page 288 288 WHAT TO DO IN EMERGENCIES 3. Lift the access cover using the pull strap. 4. Remove the fastener securing the spare tire. Lifting The Access Cover Spare Tire Fastener...
Page 289: Jacking And Changing A Tire
5. Remove the spare tire. 6. Remove the fastener securing the jack. Jack Fastener WHAT TO DO IN EMERGENCIES 289 WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle.
Page 290 290 WHAT TO DO IN EMERGENCIES Center Cap Removal WARNING! To avoid possible personal injury, handle the wheel covers with care to avoid contact with the metal edges and retention teeth. 4. Before raising the vehicle, use the lug wrench to loosen, but not remove, the lug nuts on the wheel with the flat tire.
Page 291 WHAT TO DO IN EMERGENCIES 291 Jack Engagement Locations...
Page 292: Compact Spare Tire
292 WHAT TO DO IN EMERGENCIES 6. Raise the vehicle just enough to remove the flat tire and install the spare tire. WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it.
Page 293: Wheel Cover Installation (If Required)
WHAT TO DO IN EMERGENCIES 293 Wheel Cover Installation (If Required) 1. Tighten the two lug nuts on the mounting studs on each side of the stud which is in alignment with the valve stem. 2. Align the valve notch in the wheel cover with the valve stem on the wheel.
Page 294: Jump-Starting Procedures
294 WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES WARNING! • Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is on. You can be hurt by the fan. • Do not attempt to push or tow your vehicle to get it started.
Page 295 WHAT TO DO IN EMERGENCIES 295 3. Set the parking brake, place the automatic transmis- sion in PARK, and turn the ignition switch to the OFF (or LOCK) position on both vehicles. 4. Turn off the heater, radio, and all unnecessary electri- cal loads.
Page 296 296 WHAT TO DO IN EMERGENCIES WARNING! • You should not try to start your vehicle by push- ing or towing. • Do not connect the cable to the negative post of the discharge battery. The resulting electrical spark could cause the battery to explode. •...
Page 297: Freeing A Stuck Vehicle
FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels. Then shift back and forth between Reverse and Drive.
Page 298: Towing A Disabled Vehicle
298 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE WITHOUT THE IGNITION KEY Special care must be taken when the vehicle is towed with the ignition in the LOCK position. The only ap- proved method of towing without the ignition key is with a flat bed truck.
Page 299: Towing This Vehicle Behind Another Vehicle With A Tow Dolly
If you must use the accessories (wipers, defrosters, etc.) while being towed, the key must be in the ON position, not the ACCESSORY position. Make certain the transmis- sion remains in NEUTRAL. WHAT TO DO IN EMERGENCIES 299 TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE WITH A TOW DOLLY The manufacture does not recommend that you tow this vehicle on a tow dolly.
Page 301: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS 2.7L Engine Compartment ....303 3.5L Engine Compartment ....304 5.7L Engine Compartment .
Page 302 302 MAINTAINING YOUR VEHICLE Body Lubrication ..... 320 Wiper Blades ......320 Windshield Washers/Rear Window Washer .
Page 303: 2.7L Engine Compartment
MAINTAINING YOUR VEHICLE 303 2.7L ENGINE COMPARTMENT...
Page 304: 3.5L Engine Compartment
304 MAINTAINING YOUR VEHICLE 3.5L ENGINE COMPARTMENT...
Page 305: L Engine Compartment
MAINTAINING YOUR VEHICLE 305 5.7L ENGINE COMPARTMENT...
Page 306: Onboard Diagnostic System - Obd Ii
306 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 307: Emissions Inspection And Maintenance
A loose, improperly installed, or damaged fuel filler cap may also turn on the Malfunction Indicator Light (MIL). EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system. Failure to pass could prevent vehicle registration.
Page 308: Replacement Parts
308 MAINTAINING YOUR VEHICLE b. The MIL will not flash at all and will remain fully illuminated until you turn off the ignition key or start the engine. This means that your vehicle’s OBD system is ready and you can proceed to the I/M station.
Page 309: Maintenance Procedures
WARNING! You can be badly injured working on or around a motor vehicle. Only do service work for which you have the knowledge and the proper equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 310 310 MAINTAINING YOUR VEHICLE Engine Oil Dipstick CAUTION! Overfilling or underfilling will cause oil aeration or loss of oil pressure. This could damage your engine. Checking Oil Level — 5.7L Engine To assure proper engine lubrication, the engine oil must be maintained at the correct level.
Page 311 CAUTION! Overfilling or underfilling will cause oil aeration or loss of oil pressure. This could damage your engine. Change Engine Oil Road conditions and your kind of driving affect the interval at which your oil should be changed. Check the following list to see if any apply to you.
Page 312 312 MAINTAINING YOUR VEHICLE American Petroleum Institute (API) Engine Oil Identification Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API). The manufacture only recommends API Certified engine oils. Engine Oil Viscosity (SAE Grade) — 2.7L and 5.7L Engines SAE 5W-20 engine oil is recommended for all operating temperatures.
Page 313 10W-30 OIL VISCOSITY CHART The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil filler cap location, refer to the “Engine Com- partment” illustration in this section. In areas where these grades are not generally available, higher SAE grades may be used.
Page 314: Engine Oil Filter
314 MAINTAINING YOUR VEHICLE Engine Oil Filter The engine oil filter should be replaced at every engine oil change. Engine Oil Filter Selection This manufacturer’s engines have a full-flow type oil filter. Use a filter of this type for replacement. The quality of replacement filters varies considerably.
Page 315: Fuel Filter
WARNING! The air induction system (air cleaner, hoses, etc) can provide a measure of protection in the case of engine backfire. Do not remove the air induction system (air cleaner, hoses, etc) unless such removal is necessary for repair or maintenance. Make sure that no one is near the engine compartment before starting the vehicle with the air induction system (air cleaner, hoses, etc) removed.
Page 316: Maintenance-Free Battery
316 MAINTAINING YOUR VEHICLE NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you. WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your ex- haust system.
Page 317 Battery Location MAINTAINING YOUR VEHICLE 317 WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin, or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 318: Air Conditioner Maintenance
318 MAINTAINING YOUR VEHICLE CAUTION! • It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked posi- tive (+) and negative (-) and identified on the battery case.
Page 319: A/C Air Filter - If Equipped
Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluorocar- bon (HFC) that is endorsed by the Environmental Pro- tection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by dealers or other service facilities using recovery and recycling equipment.
Page 320: Front & Rear Suspension Ball Joints
320 MAINTAINING YOUR VEHICLE surfaces. Refer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type. Front & Rear Suspension Ball Joints The suspension ball joints should be inspected for exter- nal leakage or damage when other maintenance is per- formed.
Page 321: Windshield Washers/Rear Window Washer
Windshield Washers/Rear Window Washer The windshield washer and the rear window washer share the same fluid reservoir. The fluid reservoir is located in the front of the engine compartment on the passenger side of the vehicle. Be sure to check the fluid level in the reservoir at regular intervals.
Page 322: Cooling System
322 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the OFF position. The fan is temperature controlled and can start at any time the ignition switch is in the ON position.
Page 323 Cooling System — Drain, Flush, and Refill The system should be drained, flushed, and refilled at the intervals shown on the Maintenance Schedule. If the solution is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner.
Page 324 324 MAINTAINING YOUR VEHICLE extended maintenance period, it is important that you use the same coolant throughout the life of your vehicle. Please review these recommendations for using Hybrid Organic Additive Technology (HOAT) coolant. When adding coolant: • The manufacturer recommends Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology).
Page 325 WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine. Heat causes pressure to build up in the cooling system.
Page 326 326 MAINTAINING YOUR VEHICLE When additional coolant is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill. Points To Remember NOTE: When the vehicle is stopped after a few miles (kilometers) of operation, you may observe vapor coming from the front of the engine compartment.
Page 327: Hoses And Vacuum/Vapor Harnesses
Hoses and Vacuum/Vapor Harnesses Inspect surfaces of hoses and nylon tubing for evidence of heat and mechanical damage. Hard or soft spots, brittle rubber, cracking, tears, cuts, abrasions, and exces- sive swelling indicate deterioration of the rubber. Pay particular attention to those hoses nearest to high heat sources such as the exhaust manifold.
Page 328 328 MAINTAINING YOUR VEHICLE WARNING! Riding the brakes can lead to brake failure and possibly an accident. Driving with your foot resting or riding on the brake pedal can result in abnormally high brake temperatures, excessive lining wear, and possible brake damage. You wouldn’t have your full braking capacity in an emergency.
Page 329 WARNING! Worn brake hoses can burst and cause brake failure. You could have an accident. If you see any signs of cracking, scuffing, or worn spots, have the brake hoses replaced immediately. Master Cylinder - Brake Fluid Level Check Check the fluid level in the master cylinder immediately if the brake system warning light indicates system fail- ure.
Page 330: Automatic Transmission
330 MAINTAINING YOUR VEHICLE CAUTION! Do not allow petroleum base fluid to contaminate the brake fluid, all brake seal components could be damaged causing partial or complete brake failure. Automatic Transmission Fluid Level Check Regular automatic transmission fluid level checks are not required.
Page 331: All Wheel Drive (Awd) - If Equipped
Severe Usage (fluid and filter) — Refer to Maintenance Schedule “B” Severe Usage is defined as: • Police, taxi, limousine, commercial type operation, or trailer towing where the vehicle is driven regularly for more than 45 minutes of continuous operation. If the transmission is disassembled for any reason, the fluid and filter should be changed.
Page 332: Front And Rear Wheel Bearings
332 MAINTAINING YOUR VEHICLE Fluid Changes The fluid should be changed as follows: Normal Usage Front Differential No Service Required Transfer Case Refer to Maintenance Schedule “A” Severe Usage Front Differential No Service Required Transfer Case Refer to Maintenance Schedule “B” Severe Usage is defined as: 1.
Page 333 What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle. The most common causes are: • Road salt, dirt, and moisture accumulation. • Stone and gravel impact. • Insects, tree sap, and tar. •...
Page 334 334 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • If your vehicle is damaged due to an accident or similar cause, which destroys the paint and protective coating, have your vehicle repaired as soon as pos- sible.
Page 335 and Mopar Total Clean or equivalent. Care should be taken to avoid soaking your leather upholstery with any liquid. Please do not use polishes, oils, cleaning fluids, solvents, detergents, or ammonia-based cleaners to clean your leather upholstery. Application of a leather condi- tioner is not required to maintain the original condition.
Page 336: Cleaning The Center Console Cup Holders
336 MAINTAINING YOUR VEHICLE 1. Clean with a wet soft rag or micro-fiber towel. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners. If soap is used, wipe clean with a clean damp rag. 2.
Page 337: Fuses (Power Distribution Centers)
FUSES (POWER DISTRIBUTION CENTERS) Fuses (Front Power Distribution Center) A power distribution center is located in the engine compartment. This center contains fuses and relays. Front Power Distribution Center MAINTAINING YOUR VEHICLE 337 Cavity Car- Mini Description tridge Fuse Fuse —...
Page 338 338 MAINTAINING YOUR VEHICLE Cavity Car- Mini Description tridge Fuse Fuse — 25 Amp Auto Shutdown/ Clear Powertrain Control Module (PCM) — — — — — — — 25 Amp Powertrain Control Clear Module (PCM) — 20 Amp Injectors, Ignition Coils Yellow —...
Page 339: Fuses (Rear Power Distribution Center)
CAUTION! • When installing the Power Distribution Center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the Power Distribu- tion Center, and possibly result in a electrical system failure.
Page 340 340 MAINTAINING YOUR VEHICLE Rear Power Distribution Center Cavity Car- Mini Description tridge Fuse Fuse 60 Amp — Ignition Off Draw (IOD) Yellow 40 Amp — Battery Green — — — 40 Amp — Battery Green 30 Amp — Heated Seats - if Pink equipped —...
Page 341 Cavity Car- Mini Description tridge Fuse Fuse 13 * — — — — 10 Amp AC Heater Control/ Cluster/Sentry Key Re- mote Keyless Entry — 20 Amp Trailer Tow Brake Mod- Yellow ule - if equipped — 20 Amp Rear Power Outlet Yellow —...
Page 342 342 MAINTAINING YOUR VEHICLE Cavity Car- Mini Description tridge Fuse Fuse — — — — — — — 5 Amp Amplifier - if equipped/ Orange Antenna/Ignition Delay/Overhead Console/Passenger Door Lock & Express Power Window Switch - if equipped/Power Mir- rors - if equipped/Rear Defrost —...
Page 343 * Cavities 11, 12, and 13 contain self-resetting fuses (circuit breakers) that are only serviceable by an autho- rized dealer. The Cluster is fused by the 25 amp circuit breaker in Cavity 11. The Passenger Seat Switch is fused by the 25 amp circuit breaker in Cavity 12. The Door Modules (except base), the Driver Door Lock Switch (base), the Driver Express Power Window Switch (if equipped), and the Passenger Door Lock Switch (base)
Page 344: Vehicle Storage
344 MAINTAINING YOUR VEHICLE VEHICLE STORAGE If you are leaving your vehicle dormant for more than 21 days, you may want to take steps to protect your battery. You may: • Disconnect the negative cable from the battery. • Anytime you store your vehicle, or keep it out of service (i.e.
Page 345: Bulb Replacement
LIGHT BULBS — Exterior Low Beam Headlight ..... 9006 High Beam Headlight..... 9005 Front Park/Turn Light .
Page 346 346 MAINTAINING YOUR VEHICLE 3 — Park/Turn Light Bulb CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. Tail/Stop, Turn Signal Light, and Backup Light 1.
Page 347 3. Push the electrical connector locking tab to the side. 4. Disconnect the electrical connector. 5. Remove 1 wing nut from the back of the tail light assembly. 6. Remove 2 push pin fasteners under the liftgate with a flat blade tool. MAINTAINING YOUR VEHICLE 347 7.
Page 348 348 MAINTAINING YOUR VEHICLE 2 — Turn Signal Light Bulb 3 — Backup Light Bulb 9. Pull the bulb out of the socket assembly. 10. Push the replacement bulb into the socket assembly. 11. Reinstall the bulb and socket assembly into the tail light assembly, and then turn it clockwise.
Page 349: License Light
License Light 1. Remove the screws securing the light to the rear fascia. 2. Remove the bulb and socket assembly. 3. Pull the bulb out of the socket assembly. 1 — License Light Bulb 2 — Socket MAINTAINING YOUR VEHICLE 349 4.
Page 350: Fluids And Capacities
350 MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Fuel (approximate) 2.7 Liter Engine 3.5 Liter Engine without All Wheel Drive 3.5 Liter Engine with All Wheel Drive 5.7 Liter Engine Engine Oil-With Filter 2.7 Liter Engine (SAE 5W-20, API Certified) 3.5 Liter Engine (SAE 10W-30, API Certified) 5.7 Liter Engine (SAE 5W-20, API Certified) Cooling System * 2.7 Liter Engine (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula)
Page 351: Fluids, Lubricants, And Genuine Parts
FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (2.7 Liter) Engine Oil (3.5 Liter) Engine Oil (5.7 Liter) Oil Filter (2.7 Liter) Oil Filter (3.5 Liter) Oil Filter (5.7 Liter) Spark Plugs Fuel Selection (2.7 Liter) Fuel Selection (3.5 Liter) Fuel Selection (5.7 Liter) Fluids, Lubricants, and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-...
Page 352: Chassis
352 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Brake Master Cylinder Front Axle Power Steering Reservoir Rear Axle Transfer Case Fluids, Lubricants, and Genuine Parts Mopar ATF+4 Automatic Transmission Fluid. Mopar DOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable.
Page 353 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..354 Maintenance Schedules ....354 Schedule “B” ......357 Schedule “A”...
Page 354: Maintenance Schedules
354 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 355 • Extensive engine idling. • Driving in dusty conditions. • Short trips of less than 10 miles (16 km). • More than 50% of your driving is at sustained high speeds during hot weather, above 90°F (32°C). • Trailer towing. •...
Page 356 356 MAINTENANCE SCHEDULES the vehicle is on level ground will improve the accu- racy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark. • Check the windshield washer solvent and add if required.
Page 357: Schedule "B" 357
SCHEDULE “B” Follow Schedule “B” if you usually operate your vehicle under one or more of the following conditions. Change the automatic transmission fluid and filter every 60,000 miles (100 000 km) if the vehicle is usually operated under one or more of the conditions marked with an •...
Page 358 358 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors.
Page 359 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Replace the spark plugs. 5.7L Engine. Inspect the front and rear brake linings and rotors.
Page 360 360 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors.
Page 361 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Replace the spark plugs. 5.7L Engine. Inspect the front and rear brake linings and rotors.
Page 362 362 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Replace the spark plugs. 5.7L Engine. Inspect the front and rear brake linings and rotors.
Page 363 Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the engine timing belt.
Page 364 364 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the spark plugs.
Page 365 Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and Inspect the accessory drive belt and ten- sioner.
Page 366 366 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Change the rear axle fluid.
Page 367: Schedule "A" 367
SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Replace the spark plugs. 5.7L Engine. Inspect the front and rear brake linings and rotors.
Page 368 368 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if required.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the spark plugs. 5.7L Engine. Check and Inspect the accessory drive belt and tensioner.
Page 369 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Check and Inspect the accessory drive belt and ten- sioner.
Page 370 370 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the spark plugs. 5.7L Engine. Check and Inspect the accessory drive belt and ten- sioner.
Page 371 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if required.* Replace the air cleaner filter. Inspect the front and rear brake linings and rotors. Replace the air conditioning filter. Rotate the tires. Change the Transfer Case Fluid - All Wheel Drive (AWD) only.
Page 373 IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......374 Prepare For The Appointment .
Page 374: Suggestions For Obtaining Service For Your Vehicle
We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 375: If You Need Consumer Assistance 375
• If for some reason you are still not satisfied, talk to the general manager or owner of the dealership. They want to know if you need assistance. • If your dealership is unable to resolve the concern, you may contact the Manufacturer’s Customer Center. Any communication to the Manufacturer’s Customer Center should include the following information: •...
Page 376: Warranty Information (U.s. Vehicles Only)
376 IF YOU NEED CONSUMER ASSISTANCE Service Contract You may have purchased a service contract for your vehicle to help protect you from the high cost of unex- pected repairs after your manufacturer’s new vehicle limited warranty expires. The manufacturer stands be- hind only the manufacturer’s Service Contracts.
Page 377: Reporting Safety Defects
REPORTING SAFETY DEFECTS In the 50 United States and Washington D.C.: If you believe that your vehicle has a defect, which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administra- tion (NHTSA) in addition to notifying the manufacturer.
Page 378: Department Of Transportation Uniform Tire Quality Grades
378 IF YOU NEED CONSUMER ASSISTANCE Corporation vehicles. A complete working knowledge of the vehicle, system, and/or components is written in straightforward language with illustrations, dia- grams, and charts. • Diagnostic Procedure Manuals. Filled with diagrams, charts and detailed illustrations, these practical manuals make it easy for students and technicians to find and fix problems on computer- controlled vehicle systems and features.
Page 379: Treadwear
Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled con- ditions on a specified government test course. For ex- ample, a tire graded 150 would wear one and a half (1 1/2) times as well on the government course as a tire graded 100.
Page 380 380 IF YOU NEED CONSUMER ASSISTANCE WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, under inflation, or excessive load- ing, either separately or in combination, can cause heat buildup and possible tire failure.
Page 381: Index
INDEX...
Page 382 382 INDEX ABS (Anti-Lock Brake System) ... . . 226 Adding Engine Coolant (Antifreeze) ..323 Adding Fuel ......265 Adding Rear Washer Fluid .
Page 383 Fluid Change ......330 Fluid Level Check ..... 330 Fluid Type .
Page 384 384 INDEX Cargo Management System ....122 Cargo Organizer ..... . 127 Rollaway Tonneau Cover .
Page 385 Cruise Light ......140 Cup Holder ......121,336 Customer Assistance .
Page 386 386 INDEX Flooded, Starting ..... 209 Fuel Requirements ....261,350 Oil .
Page 387 Clean Air ......262 Ethanol ......262 Filler Cap (Gas Cap) .
Page 388 388 INDEX Heater, Engine Block ....211 High Beam/Low Beam Select (Dimmer) Switch . 99 Hitches Trailer Towing ..... . . 273 Holder, Cup .
Page 389 Hood ....... 95 Lead Free Gasoline ..... . 261 Life of Tires .
Page 390 390 INDEX Load Leveling System ....131 Loading Vehicle ..... 267,268 Capacities .
Page 391 Odometer ......140 Trip ....... 140 Oil, Engine .
Page 392 392 INDEX Pretensioners Seat Belts ......38 Programmable Electronic Features ..111,114,156 Programming Transmitters (Remote Keyless Entry) .
Page 393 Satellite Radio Antenna ....187 Schedule, Maintenance ....354 Seat Belt Maintenance .
Page 394 394 INDEX Starting ......208 Automatic Transmission ....209 Engine Fails to Start .
Page 395 Jacking ......286,289 Life of Tires ......250 Load Capacity .
Page 396 396 INDEX Turn Signals ......99,142 Trip Odometer ......140 UConnect™...
Page 397 NOTES...
Page 398 NOTES...
Page 399 NOTES...
Page 400 NOTES...

This manual is also suitable for:

2007 magnum 2007 charger

Dodge 2007 LX Magnum Owner's Manual

Table of Contents

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Quick Links

INTRODUCTION

TABLE OF CONTENTS

Chapters

Related Manuals for Dodge 2007 LX Magnum

Summary of Contents for Dodge 2007 LX Magnum
