- Page 1 FOR CAR USE ONLY Advanced Video Interface for iPod 425i KCE- OWNER'S MANUAL Please read before using this equipment...
-
Page 2: Package Contents
Package Contents Package Contents: KCE-425i iPod Cable (2m) Power Cable (0.5m) IR Remote Eye with 3.5mm Jack (4.5m) IR Remote Control... -
Page 3: Table Of Contents
Contents Precautions ..........4 Introduction ..........5 Remote ..........6 On Screen Navigation ..........8 My Jukebox ..........9 Viewing Photos on Screen ........10 Switching OSD Languages ........12 Tips and Trouble Shooting ........13 ........14 Switching Video Formats Technical Specifications ........17 iPod Compatibility ........18 Using RUE-4191 ........21 Installation... -
Page 4: Precautions
APPEARS. Failure to do so may cause personal injury or damage USE ONLY IN CARS WITH A 12 VOLT NEGATIVE to the product. Return it to your authorized Alpine GROUND. dealer or the nearest Alpine Service Centre for (Check with your dealer if you are not sure.) Failure to repairing. -
Page 5: Introduction
You can use the KCE-425i as source in: · An Alpine mobile multimedia system with any touch screen monitor · An Alpine Rear-Seat entertainment system with roof or touch screen monitor · Any Rear-Seat entertainment system with A/V input · Any Factory system with a matching A/V interface... -
Page 6: Remote
Remote Control Remote Control Functions The Alpine KCE-425i lets you enjoy your iPod music through your in car multi media system as well as playing your iPod movies through your in car screen. You can either select your Music or Videos directly from your iPod (iPod Mode) when... -
Page 7: Remote Control
Remote Control Remote Control Functions MODE POWER Interface On or Off Toggle iPod Mode and UP NAV ARROW On-Screen Navigation Mode LEFT NAV ARROW RIGHT NAV ARROW/SELECT ENTER SELECT/MY JUKEBOX Press and hold for My DOWN NAV ARROW Jukebox selection VOLUME If Enabled PLAY/PAUSE... -
Page 8: On Screen Navigation
Any time a track is playing from your iPod using the Alpine KCE-425i, the current track info is displayed at the top of your screen with Album Art (if available). The Alpine KCE- 425i also displays a track countdown timer, the track progress bar, the name of your... -
Page 9: My Jukebox
Main Menu Screen to play selections from My Jukebox. 4. To clear your My Jukebox Playlist, simply select Clear List and hold. NOTE: My Jukebox will not save a Playlist after an iPod is disconnected or if the Alpine KCE-425i is powered off. -
Page 10: Viewing Photos On Screen
4. Control functions such as Play/Pause, Next Slide, Previous Slide from the comfort of your seat with the Alpine KCE-425i Remote Control. Refer to the Remote illustration to learn how to direct your photo slide shows using the Alpine KCE-425i Remote Control. - Page 11 Viewing Photos on Screen Controlling Your Photos in iPod Mode MODE POWER Switch to iPod Mode iPod MENU UP to view pictures SELECT ENTER iPod MENU DOWN DOWN NAV ARROW VOLUME (If Enabled) PLAY/PAUSE SLIDE SHOW PREVIOUS PHOTO NEXT PHOTO MUTE SLIDE SHOW MUSIC...
-
Page 12: Switching Osd Languages
Settings Language The Alpine KCE-425i has 9 different languages. Select yours from the Alpine KCE-425i Settings/Languages. Available Languages: English Spanish French German Italian Dutch Japanese Russian Swedish... -
Page 13: Tips And Trouble Shooting
Album Art to the Alpine KCE-425i. If your current selection does not have any Album Art, or if the Album Art is unavailable, the Alpine KCE-425i will display the icon below instead of Album Art. no album art... -
Page 14: Switching Video Formats
If you have a screen that is configured for PAL and your iPod’s video format is set for PAL, simply select the PAL setting in Alpine KCE-425i Settings. All Alpine screens are native NTSC screens, therefore we recommend that you set your iPod and KCE-425i to NTSC video format for best picture quality. - Page 15 Tips & Troubleshooting My Alpine KCE-425i isn’t working, what’s wrong? First, be sure that your Alpine KCE-425i is powered on. Next, make sure that you are in the desired mode - On-Screen Navigation Mode or iPod Mode. To change modes, simply push the Mode Button on your Remote Control.
- Page 16 Why? The response delay time, if any, is usually the Alpine KCE-425i waiting for informa- tion from the iPod. Hard-drive based iPods like the 5G iPod with video take longer than flash based iPods like the iPod nano.
-
Page 17: Technical Specifications
Technical Specifications Inputs/Outputs Left/Right Audio: analog audio output Video: composite video output S-Video: separated analog video output Power Input: 11-15volts/dc USB-A: standard universal serial bus, USB 2.0 (only to be used for firmware updates) Remote Control Battery: 3V, type CR2032 or equivalent Television Video Format NTSC/PAL (software switchable) Note: Due to continuous product improvement, specifications are subject to change without notice... -
Page 18: Ipod Compatibility
Technical Specifications iPod Models Supported MUSIC COMPATIBILITY: All Dockable iPods (excluding 3G & 4G iPod) NOTE: Apple iPod models listed as of Sept 2008... - Page 19 Technical Specifications iPod Models Supported Picture COMPATIBILITY: All iPods with Colour Display (excluding iPod 4G, nano 1G, nano 2G, iPod Touch 1G & 2G) NOTE: Apple iPod models listed as of Sept 2008...
- Page 20 Technical Specifications iPod Models Supported VIDEO COMPATIBILITY: All iPods with Video capability NOTE: Apple iPod models listed as of Sept 2008...
-
Page 21: Using Rue-4191
Alternative Remote Control Alpine RUE-4191 Universal Remote Controller A UDIO NAV. EXT DVD POWER PLAY/PAUSE NEXT/FF PREVIOUS/REV SHUFFLE PUSH TV/MONI.. EXT DVD AUDIO NAV. NAV JOYSTICK ENTER (up, down, left, right) Select (Push) MAIN SELECTOR SWITCH TO DISP/ RETURN REAR TOP.M... -
Page 22: Installation And Connections
Precautions WARNING Installation and Connections DO NOT DAMAGE PIPE OR WIRING WHEN MAKE THE CORRECT CONNECTIONS DRILLING HOLES. Failure to make the proper connections may result in When drilling holes in the chassis for installation, fire or product damage. take precautions so as not to contact, damage or obstruct pipes, fuel lines, tanks or electrical wiring. - Page 23 If When in doubt, consult your ALPINE dealer. wiring passes through a hole in metal, use a rubber grommet to prevent the wire’s insulation from being cut by the metal edge of the hole.
-
Page 24: Connection Diagram
Connections Connection Diagram DVD PLAYER FACTORY SCREEN CAR SPECIFIC iPod (NOT SUPPLIED) A/V INTERFACE KCE-425i BATT POWER SUPPLY AUDIO EXTERNAL REMOTE EYE VIDEO iPod IN ENTER S-VIDEO OUT REMOTE EYE INPUT I/O PORT UPDATE PORT... - Page 25 Connections Connection Diagram Note: Make sure to set the TOUCH MONITOR CONTROLS* selected AUX input of your Alpine *Please note that only basic controls touchscreen to 'EXT DVD’ MENU P 1/ 2 are available on some models TO P ENTER...
- Page 26 Connections Connection Diagram Note: Make sure to set the selected AUX input of your Alpine overhead monitor to 'EXT DVD’ CONTROLS To Remote-Out line of Alpine overhead monitor (white-brown) iPod (NOT SUPPLIED) KCE-425i BATT POWER SUPPLY AUDIO VIDEO iPod IN...
- Page 27 Support and manuals in other languages available at: www.alpine-europe.com Guide d'utilisateur disponsible sur: www.alpine-electronics.fr...
- Page 28 Wilhelm-Wagenfeld-Str. 1-3, 1-1-8 Nishi Gotanda,Shinagawa-ku, 80807 München, Germany Tokyo 141-0031, Japan Phone 089-32 42 640 Phone 03-5496-8231 ALPINE ELECTRONICS OF AMERICA, ALPINE ELECTRONICS OF U.K. LTD. INC. Alpine House 19145 Gramercy Place, Torrance, Fletchamstead Highway, Coventry CV4 California 90501, U.S.A. 9TW,U.K.
