Panasonic WV-SF135 Specifications

WV-SF135/WV-SF132
HD/1,280 x 960 H.264 Dome Network Camera with 2x Extra Zoom
VGA/640 x 480 H.264 Dome Network Camera

Key Features

• 720p HD images up to 30 fps (WV-SF135)
• 1.3 Megapixel high sensitivity MOS Sensor (WV-SF135)
• 0.32 Megapixel high sensitivity MOS Sensor (WV-SF132)
• Multiple H.264 (High profile) streams and JPEG streams ensure
simultaneous real time monitoring and high resolution recording by
"UniPhier ® ", Panasonic's proprietary System LSI platform.
• Full frame (Up to 30 fps) transmission at 1,280 x 960 image size
(WV-SF135)
• Full frame (Up to 30 fps) transmission at VGA (640 x 480) image size
(WV-SF132)
• ABS (Adaptive Black Stretch) technologies deliver wider dynamic
range compared with conventional cameras.
• High sensitivity with Day & Night (Electrical) function:
0.8 lx (Color), 0.6 lx (B/W) at F2.2 (WV-SF135)
2.0 lx (Color), 1.3 lx (B/W) at F2.9 (WV-SF132)
• VIQS (Variable Image Quality on Specified area) technology allows
the designated area to retain higher image quality while the
excluded area will have a decreased image quality, which enables
to use lower image file size and bit rate.
• Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions.
• Progressive scan ensures clear images with less motion blur and no
tearing even when the subject is moving.
• Superior color reproduction by primary (RGB) color filter
• Electronic sensitivity enhancement:
Auto (Up to 16x) / OFF (WV-SF135)
Auto (Up to 8x) / OFF (WV-SF132)
• 2x extra zoom under VGA resolution (WV-SF135)
• 2x, 4x digital zoom controlled by browser
• Selectable light control modes: Indoor scene (50 Hz) / Indoor scene
(60 Hz) / ELC (maximum exposure time)
Indoor scene (50 Hz/60Hz): Flicker caused by fluorescent lightning
will be automatically compensated.
ELC (maximum exposure time): The lightning control will be
automatically performed by adjusting shutter speed in the range of ELC.
• VMD (Video Motion Detection) with 4 programmable detection
areas, 15 steps sensitivity level and 10 steps detection size
HD Dome Network Camera
Dome Network Camera
Front View
(WV-SF135)
WV-SF135/WV-SF132
(WV-SF132)
• Face detection function detects the position of human face and the
information is sent by XML or video stream.
• Meta data for VMD works with the WJ-ND400 playback VMD
function.
• Privacy Zone can mask up to 2 private areas, such as house windows
and entrances/exits.
• Camera title display: Up to 20 alphanumeric characters on the browser
• Alarm sources including VMD and Panasonic alarm command can
trigger actions such as FTP image transfer, E-mail notification,
Indication on browser, and Panasonic alarm protocol output.
• JPEG Image compression ratio can be changed by alarm so that
higher quality image can be provided.
• Prioritized stream control: One of the video streams can be prioritized
when multiple recorders or client PCs are accessing the camera so
that the recorder or the client PC can maintain the frame rate.
• H.264 max. bit rate/client and Total bit rate control allows flexible
network traffic management. Frame rate priority mode controls bit
rate and compression ratio to provide the specified frame rate.
• Internet mode: H.264 images can be transmitted over HTTP protocol.
• Multi-language: English / Italian / French / German / Spanish / Russian
/ Chinese / Japanese
• IPv4/IPv6 protocol supported
• Supports SSL, DDNS (viewnetcam, RFC2136)
• Still images (JPEG) can be viewed on mobile phones via Internet.
• Onvif compliant model
• Low profile design for discrete installation
• Wide coverage
WV-SF135 Horizontal: 104°, Vertical: 85°
WV-SF132 Horizontal: 68°, Vertical: 53°

Standard Accessories

• Installation Guide ..........................1 pc.
• Important Safety Instructions ........1 pc.
• CD-ROM* 1 .....................................1 pc.
• Code Label* 2 .................................1 pc.
• Lens adjuster .................................1 pc.
WV-SF135
WV-SF132
(WV-SF135)
The followings are for installation.
• Installation Template Label ...........1 pc.
*1 The CD-ROM contains the operating instructions
and different kinds of tool software programs.
*2 This label may be required for network management.
The network administrator shall retain the code label.
