BOOK# 091-51
INSTRUCTION MANUAL
BATTERY SAVER VHO
POWER SUPPLY / AUTOMATIC LOAD SWITCH
MODEL #091-51-12
NOTE :
This Battery Saver is designed
for negative ground vehicles.
INPUT :120 Volts, 50/60 Hz, 8 amperes
OUTPUT: 12VDC, 40 AMPERES D.C.
3 YEAR WARRANTY
.
KUSSMAUL ELECTRONICS CO., INC
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796
TEL: in NY 631-567-0314
TOLL FREE: 800-346-0857
FAX: 631-567-5826
Advertisement
Related Manuals for KUSSMAUL 091-51
Summary of Contents for KUSSMAUL 091-51
- Page 1 This Battery Saver is designed for negative ground vehicles. INPUT :120 Volts, 50/60 Hz, 8 amperes OUTPUT: 12VDC, 40 AMPERES D.C. 3 YEAR WARRANTY KUSSMAUL ELECTRONICS CO., INC 170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796 TEL: in NY 631-567-0314 TOLL FREE: 800-346-0857 FAX: 631-567-5826...
-
Page 2: Installation
INTRODUCTION The BATTERY SAVER VHO is a power supply with transfer relays. Loads connected to the BATTERY SAVER VHO are energized from the vehicle’s battery when the A.C. battery is OFF. As soon as A.C. power is applied, the power supply provides 12 volts D.C. and the relay transfers the loads to the power supply. - Page 4 BATTERY SAVER VHO POWER D.C AMPERES LOAD 1 FUSE D.C AMPERES LOAD 2 10 AMP BAT + GROUND LOAD Battery Saver Loads: When the charger is disconnected from 120 volts AC the Chassis Battery Saver loads Ground automatically are connected to vehicle battery.
- Page 5 BATTERY SAVER VHO POWER D.C AMPERES LOAD 1 FUSE D.C AMPERES 10 AMP LOAD 2 LOAD BAT + GROUND Chassis Ground Chassis Ground Chassis Ground Accessories Accessories Battery Saver Loads: When the charger is disconnected from 120 volts AC the Battery Chassis Saver loads automatically are connected to Ground...
-
Page 6: Warranty
Kussmaul Electronics Company, Inc. shall have no liability for dam- ages of any kind to associated equipment arising from the installation and /or use of the Kussmaul Electronics Company, Inc. products. The pur- chaser, by the acceptance of the equipment, assumes all liability for any damages which may result from its installation, use or misuse, by the purchaser, his or its employees others.
