BOOK#091-36
INSTRUCTION MANUAL
AUTO-TROL
Model 091-36
A CONTROL TO PROTECT ALTERNATING CURRENT
LOADS FROM LOW FREQUENCY POWER INPUT
3 YEAR WARRANTY
.
KUSSMAUL ELECTRONICS CO., INC
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796
TEL: in NY 631-567-0314
TOLL FREE: 800-346-0857
FAX: 631-567-5826
Advertisement
Related Manuals for KUSSMAUL AUTO-TROL 091-36
Summary of Contents for KUSSMAUL AUTO-TROL 091-36
- Page 1 INSTRUCTION MANUAL AUTO-TROL Model 091-36 A CONTROL TO PROTECT ALTERNATING CURRENT LOADS FROM LOW FREQUENCY POWER INPUT 3 YEAR WARRANTY KUSSMAUL ELECTRONICS CO., INC 170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796 TEL: in NY 631-567-0314 TOLL FREE: 800-346-0857 FAX: 631-567-5826...
-
Page 2: Installation
NOTE: The “neutral” of the A.C. generator must be connected to the vehicle ground and battery “negative”. If this does not exist, contact Kussmaul Electronics Co. for special instructions. 2.0 Wire the White/Red wire to the +12 Volts D.C. 3.0 Wire the Black wire to the vehicle ground. - Page 3 TEST: 1.0 Start the engine and operate the generator at it normal speed and frequency (60 Hz). The Green LED indicator on the side of the AUTO-TROL should be lit. The relay is closed and the load energized. 2.0 Set the engine to low idle to produce a generato frequency less than 50 Hz. The Green LED indicator will be “off”...
- Page 4 87 to 30 AUTO-TROL BLACK GROUND WHITE/RED +12 VOLTS 115 VAC LOADS Figure 1 AUTO-TROL 091-36 WIRING...
-
Page 5: Warranty
Kussmaul Electronics Company, Inc. shall have no liability for dam- ages of any kind to associated equipment arising from the installation and /or use of the Kussmaul Electronics Company, Inc. products. The pur- chaser, by the acceptance of the equipment, assumes all liability for any...
