- Page 1 INSTRUCTION MANUAL Version 1.2 8/23/2010...
-
Page 2: Table Of Contents
Comments & Suggestions ......................19 Troubleshooting ........................19 ESC Disconnected During Firmware Update ................19 NovaLink Not Displaying Properly on Windows 7 ..............19 NovaLink Firmware Updater Displays Error Message ............19 Product Warranty ........................20 Novak Electronics, Inc. www.teamnovak.com... -
Page 3: Product Overview
Ability to store and share settings; a secondary profile can be downloaded onto the ESC from the • Novak website or fellow driver (the driver's main profile can still be adjusted via the speed control's on-board programming) Ability to update the ESC's firmware in the field •... -
Page 4: Precautions
“Black” labels to aid in connecting your ESC correctly. Make sure to match the labels on the NovaLink module with the color of the wires on the ESC as shown in the image to the right. Black Novak Electronics, Inc. www.teamnovak.com... -
Page 5: Software Installation
7. Return back to the NovaLink Setup folder by clicking the “Back” button 8. Double-click the Installer folder 9. Install NovaLink by double-clicking on the Setup.exe file Click “Next” to begin the NovaLink Setup Wizard Novak Electronics, Inc. www.teamnovak.com... -
Page 6: Software Registration
The registration form can be found by navigating to Start -> All Programs -> Novak Electronics. Registering your NovaLink will ensure that you receive e- mails from Novak when new versions of the software or firmware are available. Novak Electronics, Inc. www.teamnovak.com... - Page 7 INSTRUCTION MANUAL Once the installation is complete, click “Close” to exit the installation wizard Novak Electronics, Inc. www.teamnovak.com...
-
Page 8: Novalink Instructions
6. If you are ready to upload and configure your ESC settings, refer to the Uploading /Updating a Profile section MENU ICONS Create New Profile Firmware Updater Open Existing Profile About Us Save Current Profile Suggestion Box Novak Electronics, Inc. www.teamnovak.com... -
Page 9: Creating & Saving A Profile
ESC during this process) a. Do NOT disconnect your ESC while it is updating (refer to Disconnecting Your ESC) 5. When the NovaLink screen re-appears, the updated profile has been successfully saved t the ESC Novak Electronics, Inc. www.teamnovak.com... -
Page 10: Resetting To Default Settings
1. Close the program 2. Remove your ESC Downloading Software Updates Please visit http://www.teamnovak.com/products/novalink/ regularly for software updates. If you have registered your NovaLink, we will notify you by e-mail when updates are available. Novak Electronics, Inc. www.teamnovak.com... -
Page 11: Esc Firmware Upgrade
2. Navigate to the NovaLink folder (default is Start -> My Computer (or Computer) -> C: Drive -> Program Files -> Novak Electronics -> NovaLink) 3. Place the downloaded firmware file into the NovaLink folder 4. -
Page 12: Novalink Parameter Definitions
This setting controls how the speed control’s brakes respond to the transmitters trigger input in the full brake direction. This setting is measured in kHz. Ten preset selections are available in the drop down menu. Novak Electronics, Inc. www.teamnovak.com... - Page 13 This is also useful for light vehicles as they will slow more controllably under initial braking. Current Limit The Novak-developed Electronic Power Control circuitry and software senses the amount of current passing through the speed control. It adjusts the motor output so the current throughput is kept at a preset value.
- Page 14 This is useful for heavier vehicles, minimizing the amount of trigger throw required before effective braking is applied. Minimum Brake can also be increased in high traction conditions when more braking is needed quicker. Novak Electronics, Inc. www.teamnovak.com...
- Page 15 ESC will have only forward and brakes. Selecting "On" will enable reverse in addition to forward and brakes. To use reverse, simply push the trigger in the braking direction a second time. Novak Electronics, Inc. www.teamnovak.com...
- Page 16 Smart-Stop Circuitry. It also allows adjustment of the voltage cut-off point based on the type of batteries used in the vehicles main battery pack. The Novak Smart-Stop Circuitry monitors battery voltage and folds back power output to the motor when a critical voltage threshold is reached for either Li-Po or Li-Fe cells.
-
Page 17: Advanced
Values from 1,150 to 20,000 RPM can be entered in increments of 1 RPM. The Timing Set Point value must be less than the Maximum Timing RPM value. The value shown initially in the field is the ESC’s current value if the ESC is connected to the NovaLink Novak Electronics, Inc. www.teamnovak.com... - Page 18 RPM for both the Timing Set Point and the Maximum Timing Point. These values can be fine-tuned by entering custom RPM values in the text boxes. Selecting one of these default settings is optional. Novak Electronics, Inc. www.teamnovak.com...
-
Page 19: Comments & Suggestions
INSTRUCTION MANUAL COMMENTS & SUGGESTIONS Team Novak welcomes all suggestions and comments! Feel free to send us any suggestions or bugs you may have encountered through our Suggestions form. 1. Start NovaLink 2. Click the Suggestions Box icon 3. Enter any suggestions, comments, or bugs into the text field 4. -
Page 20: Product Warranty
Because Novak Electronics, Inc. has no control over the connection and use of the NovaLink Interface and software or any other related electronics, no liability may be assumed, nor will be accepted, for any damage resulting from the use of this product.
