- Page 1 PARTS LIST MODEL 1082 PART NO. 619716 NORCOLD 09/02/2010...
- Page 2 UPPER DOOR - 1082 PART # DESCRIPTION 61648838 DOOR HANDLE ASSY-LOWER/BLACK 61593830 END CAP-BLACK/STOP CATCH 61593730 END CAP-BLACK/SPRING CATCH 61648422 DOOR HANDLE-LOWER 61581738-B DOOR LINER ASSY-FOAMED/LOWER/BLACK/WHITE 61712222 DOOR PANEL-LOWER/WHITE/1082 61631430 HINGE PLATE-BLACK/LH TOP/RH BOTTOM/PLASTIC 61564025 BIN-DOOR SHELF/WHITE (SIX PER LOWER DOOR) 61714022 DOOR PANEL INSERT-LOWER DOOR 61631330...
- Page 3 LOWER DOOR - 1082 PART # DESCRIPTION 61648838 DOOR HANDLE ASSY-LOWER/BLACK 61593830 END CAP-BLACK/STOP CATCH 61593730 END CAP-BLACK/SPRING CATCH 61648422 DOOR HANDLE-LOWER 61581738-B DOOR LINER ASSY-FOAMED/LOWER/BLACK/WHITE 61712222 DOOR PANEL-LOWER/WHITE/1082 61631430 HINGE PLATE-BLACK/LH TOP/RH BOTTOM/PLASTIC 61564025 BIN-DOOR SHELF/WHITE (SIX PER LOWER DOOR) 61714022 DOOR PANEL INSERT-LOWER DOOR 61631330...
- Page 4 CABINET ASSEMBLY - FRONT VIEW - 1082 1082 PARTS LIST - PAGE 4...
- Page 5 CABINET ASSEMBLY - FRONT VIEW - 1082 PART # DESCRIPTION 61652422 COVER-CABINET/SIDE/LH/WHITE 61670822 SPACER-STYROFOAM (NOT SHOWN) 61652322 COVER-CABINET/TOP/WHITE 61671322 SPACER-TOP/STYROFOAM (NOT SHOWN) 61652222 COVER-CABINET/SIDE/RH/WHITE 61670822 SPACER-STYROFOAM (NOT SHOWN) 61578522 DOOR LATCH 61509522 DRAIN HOSE (USE 618217) 61572830 DRIP TRAY-INSIDE/WHITE 61505122 HOSE CLAMP (NOT SHOWN) 61564122 CRISPER COVER-GLASS SHELF...
- Page 6 CABINET ASSEMBLY - REAR VIEW - COOLING UNIT - 1082 PART # DESCRIPTION 632325 NSC SYSTEM PACK-COOLING UNIT/BACKER HEATER 61686823 FINS-COOLING 61695022 CAP-HEAT DEFLECTOR 621702 HEATER-AC (COOLING UNIT SERIAL# 11247955 & BELOW) 630811 HEATER-AC (COOLING UNIT SERIAL# 11247956 & ABOVE) 61712637 COVER ASSY-BURNER BOX 61695322...
- Page 7 BOTTOM PAN CONTROL ASSEMBLY - 1082 1082 PARTS LIST - PAGE 7...
