24 VAC SYSTEM CONTROL KIT
Tubing
The CK-43 is designed for use with the SWG Series Power
Venter for controlling Natural Gas and L.P. Gas Draft Induced
appliances.
Control kits control the operation of SWG Power Venters. Control
Kits can also control the operation of Field Draft Inducers and
Combustion Air Systems.
I
K
TEMS INCLUDED IN
IT
1) Junction box with mounted pressure switch and
relay/timer.
1) 1 Ft. Length of 1/4 inch aluminum tubing.
1) 1/4 inch tubing connector
1) Flexible conduit connector
1) 4" MG1 Barometric Draft Control or 5" AF Barometric
Draft Control
DO NOT DESTROY
THESE INSTRUCTIONS MUST REMAIN WITH EQUIPMENT
Model: CK-43
MG1 Barometric
Draft Control
Advertisement
Related Manuals for Field Controls 46190700
Summary of Contents for Field Controls 46190700
- Page 1 24 VAC SYSTEM CONTROL KIT Model: CK-43 Tubing MG1 Barometric Draft Control The CK-43 is designed for use with the SWG Series Power Venter for controlling Natural Gas and L.P. Gas Draft Induced appliances. Control kits control the operation of SWG Power Venters. Control Kits can also control the operation of Field Draft Inducers and Combustion Air Systems.
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS OUNTING UNCTION The junction box can be mounted at the venter or remotely mounted away from the venter. (See Figure 1 & Figure 2) 1. Remove one of the knockouts from the side of the junction box where the pressure switch is mounted. - Page 3 DRAFT CONTROL INSTALLATION See Figure 4 for typical vent system layout. CAUTION: This draft control is shipped as a single acting draft control. If the draft control is not being used on a gas draft induced furnace, remove the gate stop on draft control ring...
- Page 4 RAFT ONTROL NSTALLATION IN CAUTION: DO NOT use the supplied collar when mounting draft control to Type B Vent Pipe. Install by using a Type B Vent Pipe Tee. 1. Install a vent pipe reducer or increaser into the inner pipe and fasten using sheet metal screws.
- Page 5 PROVING SWITCH ADJUSTMENTS After proper air flow is established, the pressure switch adjustment is made by turning pressure switch adjustment screw clockwise (See Figure 10) until burner operation stops. Turn the adjustment screw counter clockwise until burner ignites. Turn the adjustment screw an additional 1/4 to 3/4 turn counterclockwise to ensure adequate switch adjustment.
-
Page 6: Troubleshooting Hints
SYSTEM CONTROL CHECK OUT PROCEDURES 1. Adjust the thermostat to call for heat and observe the power venting system for proper operation sequence (Repeat if necessary). a. Thermostat calls for heat. b. Relay is energized and venter motor starts. c. Pressure switch closes and burner starts. d. - Page 7 INSTALLATION INFORMATION CK-43 Control Kit MODEL NO.:_____________________________________________________________ INSTALLER’S NAME: _____________________________________________________ INSTALLER’S COMPANY:__________________________________________________ INSTALLER’S PHONE NO.:_________________________________________________ DATE OF INSTALLATION: _________________________________________________ Page 7...
- Page 8 Page 8 P/N 46190700 Rev C 09/01...
