Sylvania SCD290 Instruction Manual

DIGITAL ANTI-SHOCK OPERATION
The digital ELECTRONIC SHOCK PROTECTION function uses semiconductor
memory to prevent the second from skipping when the unit is subjected to shocks
and vibration during play.
When the PLAY/PAUSE button is pressed and the power turns on, the digital
Electronic Shock Protection function turns on automatically.
The display will show and the function is initialized, when shows in the
display, the data buffer is full.
It will give approximately 45 seconds of protection against interruption of sound output,
if the player is subjected to shocks of more than 45 seconds duration, some
interruption of sound output will occur, this is normal and to be expected, the sound
will resume once the player has stabilized from the shock.
To turn this function off, press ASP button once, the ESP indicator will disappear.
MAINTENANCE
Cleaning the Lens
If the lens becomes dusty, clean it with camera lens blower. Be careful not to scratch the
surface of the lens.
Cleaning the Cabinet
From time to time, clean the cabinet with a soft dry cloth. For more stubborn stains, slightly
moisten the cloth with water or a mild detergent solution. Never use benzene, alcohol or
other solvents as they may damage the finish of the cabinet.
SPECIFICATIONS
RADIO
Frequency range : AM522 - 1620kHz
FM87.5 - 108MHz
CD
Output Power : 20MW (32 )
Freq. Response : 100 ~ 20000 Hz
Power : DC 4.5V external and size "AA" batteries 1.5V x 2, UM-3,
HP-7, R6
Dimensions : 130mm(W) x 138mm(D) x 28mm(H)
** For improvement purposes, specification and design are subject to change without
notice. **
— 6 —
TROUBLE SHOOTING GUIDE
Cleaning the Disc
When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from
the center out.
Note - Do not use solvents such as benzine, thinner, commercially available
cleaners or anti-static spray intended for analogue discs.
** Should you experience difficulties in the use of this player please
refer to the following chart before contacting your dealer or the place of
purchase.
— 7 —
SCD 290
PORTABLE COMPACT DISC PLAYER
WITH 45 SECONDS ANTI-SHOCK SYSTEM
AND PLL AM/FM STEREO RADIO
D Y N A M IC
B A S S B OO S T S Y S T E M
INSTRUCTION MANUAL
— 1 —
