Loop: pre aMp (post Distortion, pre Amp Model/Amp Loop send), or pOst aMp (Post
Amp Model/Amp Loop return). Note that the Stomp Loop button's LED turns red when
it's pre amp, and green when it's post amp or post FX.
4. Store these changes using the Store procedure.
Note: If you try to enable the Stomp Loop but nothing is connected to the Stomp Loop jacks,
the Display will briefly read nO loop. The Stomp Loop will not enable when no connections
are present at these jacks.

Connection Setups

The RP1000 has many different connection options. Here are some more common ways it can
be used:
Mono Amp
Connect your guitar
to the RP1000's Input.
Connect the RP1000's
Left (mono) Line Output
to the amp's Input.
Amp/Mixer switch on 1/4"
outputs is set to AMP.
