Hardware Features
Before you install and connect your router, take a moment to become familiar with the front and
back panels of the router—especially the LEDs on the front panel.
Front Panel
The wireless-N modem router front panel shown below contains status LEDs.
Figure 3
You can use the LEDs to verify various conditions.
Table 1.
LED Descriptions
Label
LED Activity
Solid Green
Solid Red
Off
1. Power
Factory reset
Getting to Know Your Wireless Router
1
2
3
4
5
6
Description
Power is supplied to the router.
POST (Power-On Self-Test) failure or device malfunction
Power is not supplied to the router
Lights momentarily while the rest button is depressed for 6 seconds, then
blinks red three times when the reset button is released, and then turns
green as the gateway resets to the factory defaults.
Table 1
describes each LED.
3
