Linksys VGA2200 - One Analog Voice Gateway 2 Stations Quick Installation Manual
Analog voice gateway 2 stations
Hide thumbs
Also See for VGA2200 - One Analog Voice Gateway 2 Stations:
- Administration manual (193 pages)
Related Manuals for Linksys VGA2200 - One Analog Voice Gateway 2 Stations
Summary of Contents for Linksys VGA2200 - One Analog Voice Gateway 2 Stations
- Page 1 Analog Voice Gateway 2 Stations Model VGA2200...
- Page 3 Voice Gateway Model VGA2200 Phone Cables (2) LAN Cable...
- Page 4 (not included) 3.75" (95.25 mm) 2-#10 (M5) 1" (25.4 mm)
- Page 6 Phone 2 Phone 1...
- Page 7 (Optional; Not included)
- Page 8 VGA2200 Voice Gateway Regulatory Compliance and Safety Information The Linksys One VGA2200 Voice Gateway meets the following regulatory compliance and safety standards Specification Description Regulatory Compliance Products with the CE Marking indicate compliance with the 89/336/EEC and 73/23/EEC directives, which include the safety and EMC standards listed below.
- Page 9 FCC Part 15 Class B Compliance This Equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 10: Safety Information
Safety Information The following statements are warnings or safety guidelines. A warning means danger. You are in a situation that could cause bodily injury. Before working on equipment, be aware of the hazards involved with electrical circuitry and standard safety practices to prevent accidents. IMPORTANT SAFETY INSTRUCTIONS Warning This warning symbol means danger. - Page 11 Warning Installation Instructions Read the installation instructions before connecting the system to the power source. Warning SELV Circuit To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some LAN and WAN ports both use RJ-45 connectors.
- Page 12 Installation of the equipment must comply with local and national electrical codes. Warning Product Disposal Ultimate disposal of this product should be handled according to all national laws and regulations. Caution Inline power circuits provide current through the communication cable. Use the Linksys-provided cable or a minimum 24AWG communication cable.
- Page 13 Power Supply Safety Warnings When using the VGA2200 Voice Gateway with the optional external power supply, observe the following safety warnings: TN Power Warning The device is designed to work with TN power systems. Ground Conductor Warning Warning Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor.
- Page 14 120 VAC, 15A U.S. (240 VAC, 10A international) Warning Main Disconnecting Device The plug-socket combination must be accessible at all times, because it serves as the main disconnecting device. Caution Only use the Linksys-specified power supply. Refer to the installation manual provided with this product.
- Page 15 Open Source Software. The GPL source code incorporated into the Software is available for free download at http://www.linksys.com/gpl. If You would like a copy of the GPL source code in this Software on a CD, Linksys will mail to You a CD with such code for $9.99 plus the cost of shipping upon request.
- Page 20 ©2006 Cisco Systems, Inc. All rights reserved. Linksys is a registered trademark and the Linksys One logo is a trademark of Cisco Systems, Inc.
