- Page 1 Copyright All products by GIGA-BYTE Communications mentioned in this document, including the device, accessories, software are owned or authorized by original manufacturers to GIGA-BYTE Communications. Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of GIGA-BYTE Communications Inc. is prohibited.
-
Page 2: General Information
General Information Welcome to use the GSmart ExpressCard MD800. With this, you can easily: - Access the Internet - Send and receive text messages - Use the function of contacts Before using the GSmart ExpressCard MD800, please read the safety precautions carefully, so that you can use your express card correctly and safely. -
Page 3: Safety Information
Follow any special rules and regulations and obey all signs and notices. Always turn off the host device and remove the GSmart MD800 from the card slot when instructed to do so, or when you suspect that it may cause interference or danger. - Page 4 Electrical and electronic devices are sensitive to electrostatic discharge (ESD). The Connection Manager will attempt to reinitialize the device should a substantial electrostatic discharge reset the device. If the software is not operational after an ESD occurrence, then restart the GSMART MD800. MD800...
- Page 5 Regulations CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.
-
Page 6: Table Of Contents
Table of Contents Copyright…………………………………………………………………………………………..…………1 General Information………………………………………………………………………………………..2 Sa fet y Info rmat io n… … ………… …… …… … …… …… ………… … …… …… …… …… ……3 Regulation……………………………………………………………………………………………………5 Chapter 1 Getting Started……………………………………………………………...………………1-1 1.1 Software Installation…....…………………………………………………………………..1-1 1.2 Remove your express card……...…………………………………………………………………..1-1 Chapter 2 Using Your Express Card…..……………………………………………………………. -
Page 7: Chapter 1 Getting Started
After the first pop-up, all other aspects for software installation will be identical in all compatible versions of Windows 1.2 Remove your express card You must shut down your GSmart MD800 correctly before you attempt to remove it. It ensures that your GSmart MD800 is removed safely. -
Page 8: Chapter 2 Using Your Express Card
2. Using Your Express Card 2.1 The Screen Setting: General, SMS, SIM, Radio. Home Screen: 1. GSmart Logo Status: connection status. 2. Signal Strength 3. Radio Technology Statistics: Upload, Download graphs. 4. SIM card 5. Minimize 6. Close Information: Device, Version specifics. 7. -
Page 9: Connection
1. Select a country name. Each country has a list of settings for many mobile networks. 2. If you want to exit MD800 program, press GSmart MD800 icon on the bottom, choose Exit to close the program. 3. If the Internet is still connecting when you close MD800 program. -
Page 10: Information And Status Displayed
2.3 Information and Status Displayed Status Information When you start the program, it shows “During the searching”. This area usually shows status of the program. To Edit a Mode 1. Create a new profile. Depending on the carrier, 4 fields may not really need to be filled. -
Page 11: Led Indicator Status
Orange 2.5 Saving power If you want to save the power, you have to check four places 1. Please press right key on My Computer > Properties > Hardware > Device Manager > Modems > Gigabyte USB Modem 6002 MD800... - Page 12 2. Please press right key on My Computer > Properties > Hardware > Device Manager > Ports (COM&LPT) > Gigabyte ATCOP Interface 6002 (COM4、COM5、COM6) > Power Management > Allow the computer to turn off this device to save power MD800...
-
Page 13: Chapter 3 Messages
3. Messages Messages have the same standard with any other mobile device. Each message is stored in the Inbox, Sent, Outbox, and Draft folders display the Number of the contact, the date it was and the content 3.1 SMS It contains the received messages. Reply to, Forward to or Delete the Inbox messages by highlighting them and pressing button. - Page 14 Outbox Outbox contains completed but unsent messages. Send or Delete message by highlighting one and pressing the button ：Press to add receivers Sent It contains all successfully sent messages. Highlight a message and press Delete to delete it Compose It contains all tools for creating messages. There are two tables：You can enter telephone number in the first table and name is not necessary.
- Page 15 telephone, and then press OK Note： New receiver you add here will not be newly added in the contact list After the receivers are all set, please edit text message in the white space below. When you finish it, press send to send the message. The message will be stored to Draft by pressing save Message...
-
Page 16: Chapter 4 Contacts
4. Contacts The contacts display all the contacts on the SIM card. Contacts can be added, edited, deleted. 4.2 Editing Contacts 1. Click the Contacts button 4.1 Adding Contacts 2. Select a contact to Edit 3. Click Edit button 1. Click Contacts button > Add 4. -
Page 17: Deleting Contacts
4.3 Deleting Contacts 1. Click the Contacts button 2. Select a contact to delete 3. Click the Delete button 4. Click OK to confirm Note: the phone book on the SIM card have limitations of phone number under twenty numbers and name within twelve words. MD800... -
Page 18: Chapter 5 Settings
5. Settings screen is getting darker. 5.1 General Setting Language We offer English and Traditional Chinese. To choose a language, click the menu and highlight or select a language. Click Apply to implement the chosen language. 5.2 SMS Setting New SMS New SMS Notify︰Check this function when a new text message arrives. -
Page 19: Sim Setting
SMS Center 5.3 SIM Setting Use default number in phone or uncheck to input service center number manually. Click Apply after making any changes. Enable/Disable or change the SIM card Personal Identification Number (PIN). Press Apply after making any changes. A SIM card must be inserted for this function to be active. -
Page 20: Radio Setting
PIN code will be changed. Note︰If a PIN code is enabled, it will be asked for during the SIM card initialization. After you enter incorrect PIN code three times, the SIM card will be locked. Please contact your operator to unlock it. 5.4 Radio Setting Mode- Features various network search options. -
Page 21: Chapter 6 Status, Statistic & Information
6. Status, Statistic & Information 6.1 Status 6.2 Statistic When you connect to the Internet, this screen The Statistics screen displays a graph of shows the whole information about the recent upload and download activity. If there is connection every second. no data, the Express Card is offline. -
Page 22: Information
6.3 Information The Information screen offers version or signal specifications. Click Menu > Information IMEI: International Mobile Equipment Identity number Software Version: GSmart ExpressCard software version Firmware Version: GSmart ExpressCard Firmware Version MD800... -
Page 23: Chapter 7 Q&A
Connection Radio icon; if the icon is light functioning (if applicable) up and it means on. If the icon stays dark - GSmart MD800 is not slid correctly into the and it means off. And GSmart MD800 is adapter casing... - Page 24 Flight Mode Q︰ How do I view the User Manual? A︰ Click Start > Programs > GSmart > MD800 User Manual, and the document which requires Adobe Acrobat 6.0 Q︰I cannot start my computer when I insert my MD800. Why? A︰...
-
Page 25: Chapter 8 Specifications
Downlink: 7.2Mbps/3.6Mbps/1.8Mbps/ in bps: Data Speed 384Kbps Uplink: 384Kbps (Max) GSmart MD800 Thank you for choosing the GSmart MD800. The user manual may be updated ir changed at anytime. Please download the latest version from our official website. GIGA-BYTE COMMUNICATIONS INC.
