Diamond Multimedia SM56PCI Specification Sheet

SKU
SYSTEM BUILDER SKU
PRODUCT
PRODUCT DETAILED DESCRIPTION
PRODUCT FEATURES
PRODUCT SPECIFICATIONS
SYSTEM REQUIREMENT
OPERATING SYSTEM
FORM FACTOR
DIMENSIONS
WEIGHT
UPC
PACKAGE CONTENT
DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU SM56PCI
BRAND Supra
February 4, 2011 - 6:25 am
SM56PCI
DIAMOND SupraMax PCI Pro 56K Modem
Diamond Supra unleashes the highest performance SupraMax modems with newly adopted ITU, V.92 and V.44
compression standards.
SupraMax gives you the advantages of extensive analog access to the Internet with an added boost of speed over earlier
standards. These improvements includes accelerated upstream data transfers (up to 40% faster), faster Internet dial-up
connection times using an intelligent start-up sequence, and advanced compression algorithms that let you send common
file type (such as HTML, e-mail, and executable files) more efficiently. The new Modem-On-Hold feature lets you receive
incoming voice calls without dropping your current modem connections. And, because the SupraMax V.92 is backward
compatible with V.90 and earlier standards, you can relax and enjoy faster Internet speeds without worry. (For more
information on V.92 features, please see below.)
WHAT IS V.92?
V.92 is an International Telecommunications Union (ITU) standard for analog modem connections, a new improvement
over the existing V.90. Though the top speed for downloads is still 56K, V.92 has a number of enhancements.
WHAT FEATURES ARE INCLUDED IN V.92?
There are four important benefits to the V.92 standard; Quick Connect, Modem-on-hold, PCM upstream and V.44 data
compression.
Quick Connect - by reducing the amount of time it takes for the modem and server to handshake, connect time is reduced
dramatically. Instead of taking around 25 seconds to connect, this may be reduced to 8 seconds.
Modem-on-hold - the end user can put the modem on hold and stay connected to the Internet. The user can take an
incoming voice call, or even place a call while still connected. When the call is through, the end user can resume Internet
activities without having to re-dial and connect.
PCM upstream - increases maximum upload speed to 44 Kbps.
V.44 - a new standard for data compression specifically for HTML (normal website), text and other common file types, for
faster downloads. Throughput can increase up to 30-40%. This will supercede the current V.42bis standard.
WHAT IS REQUIRED FOR V.92 AND V.44
Your ISP carrier must provide support for V.92 and V.44 compression. Please consult with your ISP for details.
Full featured data/fax Internal modem
Easy PCI installation
Supports V.92 for speeds up to 56,000 bit/s
Sends and receives faxes with speeds up to 14,400 bit/s
Top-rated communications and Internet access software
Receive Phone Calls While Online
Increase Upload Speed
Complete Internet & Fax Solution
V.90, V.92 & V.44 ITU standard 56K
V.34 and backwards compatible protocols
Fax speeds up to 14,400 bit/s, Group III, Class 1
Data compression V.42bis and MNP 5
Error correction V.42 LAPM and MNP 4
EXTERNAL POWER REQUIREMENT
CPU
CPU SPEED
MEMORY
HARD DISK
SYSTEM BUS
SLOT
CHASSIS
MONITOR
INTERNET ACCESS
USB
CD DVD
POWER SUPPLY
WINXP WIN98SE WINME WIN2000
[PRODUCT] : 11 13/16 X 9 1/8 X 3 1/8 [RETAIL BOX] : 11 13/16 X 9 1/8 X 3 1/8 [S BUILDER] : 12 X 7 1/4 X 2
[PRODUCT WEIGHT] : 0.45LBS [PRODUCT WITH CONTENT WEIGHT] : 2.0 LBS
RETAIL PACKAGE UPC : 018258009621
DIAMOND SUPRAMAX PCI PRO 56K MODEM
QUICK START GUIDE
INSTALL CD
AMD Athlon® or Intel ® Pentium ® 4
133 MHZ
N/A
20 MB
PCI
N/A
ATX
Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
YES
YES
N/A
TELEPHONE CABLE (RJ-11)
ENG APVD - LK 2007-09-20
MRKTG APVD - LL 2008-03-21
