  • Page 1 NAV 101 Installation and Operation Manual...

  • Page 2: Table Of Contents

    CONTENTS Thank you for choosing a Audiovox product. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new Audiovox NAV101 navigation system for maximum enjoyment.

  • Page 3: Introduction

    INTRODUCTION We hope that you enjoy using your new Audiovox NAV101 navigation system. This manual is designed to help you get the most out of your system. This navigation system leads you straight to your destination. You can navigate and plan your route...
  • Page 4 • Four rubber feet (to affix to the bottom of the NAV101 in the recessed area near each corner) • SmartBus cable (used to connect the NAV101 to the Audiovox navigation-ready radio) • Four 6mm (.25in) screws (to secure the left and right mounting brackets to the NAV101 navigation module) •...
  • Page 5 Kingdom (incl. 7 PIN ZIP Code) , Vatican city state (holy see). Map data update If you are in need of new or updated map data in future, then please contact: a) Your local dealer or b) Your distributor or c) Our technical service department: www.audiovox.de...

  • Page 6: Safety Information

    SAFETY INFORMATION When the Audiovox NAV101 is first turned on, the following message appears: You must agree to the above notice before operating the NAV101. The following safety rules must be followed to prevent accidents that can result in injury or death to yourself or others: •...
  • Page 7 l. Traffic congestion. • While every attempt is made to ensure that the database is accurate, roadways, points of interest, and business and service locations may change over time. • Do not use the NAV101 to navigate to a police station, hospital, etc. in an emergency.

  • Page 8: Installation

    INSTALLATION The NAV101 can be used with a Audiovox navigation-ready DVD unit (VME 9312 TS, VME 9512 TS, VME 9122TS). Warnings • Do not install components in areas which are susceptible to rain, moisture, direct sunlight, extreme heat or cold, excessive dust, dirt or humidity.
  • Page 9 Antenna Placement Since the NAV101 uses GPS technology for navigation, proper antenna place- ment is crucial for optimal performance of the GPS receiver. When using GPS antennas, the antenna plane should be parallel to the geographic horizon. There should be nothing between the antenna and the sky to ensure a direct line-of- sight between the antenna and available satellites.

  • Page 11: Getting Started

    NAV101 and secure it with a 11mm (.4in) screw (provided). Connect the other end of the cable to the NAV101 input on the back of your Audiovox navigation- ready head unit (VME 9122 TS VME 9512 TS, VME 9312 TS) If using a VME 9312TS or VME 9512TS, secure the cable to the radio using a 11mm (.4in)

  • Page 12: Main Features

    MAIN FEATURES Main Menu The main menu is your central point of access to all functions of your NAV101. It allows you to set your destination, manage your favorites and control all settings of your device. The “Main Menu” consists of the following options: •...
  • Page 13 In Tracking mode, the map follows your actual position (GPS position), displaying information about your geographic position, your speed, etc. The GPS position is indicated by a green arrow or a haircross. Use a stylus or your finger to browse the map and enter Browsing mode. The selected position will be identified by a crosshair ( cursor.
  • Page 14 NOTE: Pressing an icon on the map opens an overlay window with information about the selected item. • To zoom in or out, press the + or – icons. After pressing one of the icons, the zoom slider will appear, enabling smooth zooming. •...

  • Page 15: Choosing And Finding Locations

    CHOOSING AND FINDING LOCATIONS This section describes the different ways of finding and choosing locations. You can search for an Address, search POI (Point of Interest) directories and city guides, select a recent destination or choose from your Address Book, or select a location on the Map.
  • Page 16 • After entering the second character, only letters that can be used to spell an existing destination will be available for selection of the third character, the fourth character, and so on. • Continue entering characters until you have narrowed down the search to only one result, or press the OK button to display a list of search results, from which you can choose.
  • Page 17 5. Enter Zip Code You may enter a known zip code instead of the Cityname to advance faster. 6. Select a Street. a. Press the “Street” data field to access the “Enter...” screen. b. Use the on-screen keypad to enter the Street name. If the first two characters are not part of an existing Street name, “No entries found”...
  • Page 18 Searching for and Choosing a POI (Point Of Interest) The POI finder allows you to quickly find points of interest, like gas stations and restaurants, in a database of millions of POIs. These places can be near your current position (the default) or at any other location. Browse POIs 1.
  • Page 19 a. To search for a POI in another location, press the “Where?” button. A screen with navigation options appears. b. Press the corresponding button to search for a new address using the “Enter...” screen (Find Address), My Address Book, or your current GPS Position. To skip this step and return to the “POI Search”...
  • Page 20 4. Select a sub-category from the POI Search list. A list of POIs will be shown. Use the scroll bar on the right side of the screen to see all of the choices. • To return to the previous category, press the button.
  • Page 21 Search POIs 1. To search for a POI, return to the “POI Search” screen and press the ABC button. The “Enter...” screen will appear. 2. Enter the search keyword (at least three characters), and press the OK button. A list of POIs beginning with the search keyword appears on the screen. (If there are no POIs containing your search criteria, “No entries found.”...
  • Page 22 2. Press any part of the map area to enter browsing mode and navigate the map. During browsing, the map screen borders will turn orange. Use the +/– buttons to zoom in/out. Point the cursor at any location on the map to view location information in a pop-up box.
  • Page 23 NOTE: The “Recents” list stores the last 15 addresses or destinations. After 15 entries, the oldest destination will be deleted and the newest entry added to the top of the list Recent addresses can not be deleted manually. Choosing a Location from your Address Book 1.

  • Page 24: Navigating

    NAVIGATING The powerful navigation capabilities of your NAV101 will guide you along the shortest or quickest route from A to B – with voice commands and in 3D (selectable). To begin navigation, select a location using the Drive to... feature (see “Choosing and Finding Locations”...
  • Page 25 Browsing the Map During Navigation You can browse the map while navigating without interrupting the current route – you will still be guided through voice commands. • To browse during navigation, simply touch the "map" (the screen) and the Map Browsing feature is automatically activated.

  • Page 26: Planning A Route

    PLANNING A ROUTE This section describes the route planning feature. This feature allows you to plan your route in advance, choosing multiple stopovers along your journey. 1. To begin navigation, select a location using the Drive to... feature (see “Choosing and Finding Locations” on page 52). 2.
  • Page 27 6. Once you have chosen your route, press the MENU button in the bottom right-hand corner of the screen. The following options are available: To begin navigation, press Start Navi. The display will switch to the navigation map. • To simulate the planned route, press Simulate. The device will calculate the route based on a user entered destination, but not actually perform navigation guidance based on GPS signals.

  • Page 28: Managing Your Address Book

    MANAGING YOUR ADDRESS BOOK The Address Book allows you to save your home and work locations, as well as other frequent destinations for easy recall. After entering an address or searching for a POI, you can choose the Save option to bookmark your selection, eliminating the need to perform repeated searches.
  • Page 29 To set the initial default address for work or home, press Home or Work and then choose one of the following options: • To return to the previous screen, select Back. • Select Address to open the “Find Address” screen and enter the address (see “Finding an Address”...
  • Page 30 Favorites To access your list of favorites, press the Favorites button. The “Favorites” screen appears: NOTE: Use the scroll bar and arrows on the right side of the screen to move up and down the list and view all entries. Select an item and then press the MENU button to choose from the following options: •...
  • Page 31 Trips To access your list of saved trips, press the Trips button. The “Trips” screen appears: Select a trip and then press the MENU button to choose from the following options. • To calculate the route for the selected trip, select Navigate. •...

  • Page 32: Settings Menu

    SETTINGS MENU When using the NAV101 for the first time, it is recommended that you customize the system parameter settings. For example, regarding navigation, you can choose to avoid or allow toll roads or ferries. You can also edit display settings, including 2D or 3D mode, day or night mode, map complexity, etc.
  • Page 33 Press Language to view the “Language” screen. The following languages can be selectet: Catalan, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Norwegian, Polish, Portugese, Russian, Spanish, Swedish and Turkish. Press the “UK” (English) flag and then select one of the following voice types for voice commands :English, French, German, Italian, Portugese and Spanish.
  • Page 34 • To select which and how many icons are displayed on the map, press Display POI. • Check the boxes of any category you want to have displayed on the map. Uncheck those that should be hidden. Note that this will NOT affect any searches that you perform.
  • Page 35 Route Settings Select Route Settings to modify the following options. Table 1: Route Settings Press each button to toggle between the options listed in Table 1.
  • Page 36 Road Selection Setting When you enter the settings screen of the software, you are asked to select routing options. The Fastest Time setting takes into account the posted speed limits of the various roads and streets along a route in order to determine the correct route.

  • Page 37: Troubleshooting
