OPERATING INSTRUCTIONS FOR THE
SGX 2000 EXPRESS
ADDENDUM TO THE SGX 2000 REFERENCE MANUAL
A.R.T. has increased the power of the SGX 2000 by 400% and kept the
ease of use factor unchanged. There are some variations between the two
units which will be explained in this addendum. All other functions remain
the same.
Included in the EXPRESS are:
* Hundreds of new presets!
* Enhanced reverb algorithms!
* More gain!
* Dual pitch transposer
* Expanded digital tuner
* Space Phaser!
* Regenerated delay time increased
* Refined acoustic environment simulator!
* Expanded MIDI implementation!
Use this manual to reference all features and functions of your new SGX
2000 EXPRESS processor. Refer to the large reference manual for hook-up
diagrams and "getting started" suggestions.
505-5004-100
Advertisement
Related Manuals for Art SGX 2000 - ADDENDUM
Summary of Contents for Art SGX 2000 - ADDENDUM
- Page 1 OPERATING INSTRUCTIONS FOR THE SGX 2000 EXPRESS ADDENDUM TO THE SGX 2000 REFERENCE MANUAL A.R.T. has increased the power of the SGX 2000 by 400% and kept the ease of use factor unchanged. There are some variations between the two units which will be explained in this addendum.
- Page 2 Throughout this text TITLE EDIT Characters in title Throughout this text Utility Addition of utilities Throughout this text X-15 How to use with ART X-15 SWEPT Addition of Phaser Space Phaser REGEN DDL Delay time longer Refined Algorithms TUNER Expanded parameters Digital Tuner MISC.
- Page 3 SGX 2000 EXPRESS does! X-15 ready patches (23-28) show off just what the SGX 2000 Express is capable of when used with the ART X-15 MIDI Controller pedal. To finish off the tour, there are ten semi-dirt, lead/rockin' rhythm patches (29-40).
- Page 4 Bank "C" PRODUCTION Individual effects in a patch, small rooms with different mic placements, clean/dirty miced amps, drum and vocal reverb patches are all represented here. From preset 1 to preset 29, each individual effect has its own patch. This allows you to just use chorus or compression or any other effect alone.
-
Page 5: Store Preset
This diagram displays a preset in bank "A". The top line shows the preset title and the bank designator (last character space). Look at the numeric display to the right of the LCD for the actual preset number. To switch between presets in a bank, be sure the PRESET LED is lit. If it isn't, press the Preset button. - Page 6 which bank the preset came from. If you modified a preset or created one from scratch, the bank designator letter will change to a "U" indicating the preset is your work. If the preset location was blank, the LCD will look like: BLANK PRESET <no effects>...
- Page 7 Edit button and select a preset slot with the Encoder and then press Store. USING THE ART X-15 WITH YOUR SGX 2000 EXPRESS RECALLING PRESETS You can access all two hundred memory slots of the SGX 2000 Express with your X-15.
- Page 8 :PITCH 2 = [0] (-)12 to (+)12 half steps in 1 half step increments :FINE 2 = [0.00] (-)4.00 to (+)4.00 half steps in 0.06 (six cents) increments :REG-FD = [PRE] PRE, POST :LEVEL = [100%] 0 to 100 percent level in % increments :POSTN1 = [31] 0 to 63 in on step intervals :POSTN2 = [31] 0 to 63 in on step intervals Pitch Transposing or pitch shifting can be used to develop helpful second harmonies or...
-
Page 9: Digital Tuner
Regeneration Feed ([RGN-FD]) controls where the digital delay's (if used) regeneration comes from. The insert point is either before (PRE) or after (POST) the first voice. When the Stereo Digital Delay is used with the Dual Pitch Transposer and the RGN-FD is set to POST, the glissando effect of the normal Pitch Transposer is the result. -
Page 10: Things To Note
Type allows you to choose what instrument you are going to tune. There are four choices, two for Guitar and two for Bass. Open string tuning can be done when you select either the GUITAR or BASS TYPE. Select TYPE GTR12F or BASS 12F to tune your instrument to the twelfth fret. - Page 11 This warranty is void if the serial number is altered, defaced, or removed. ART reserves the right to make changes in design or make additions to or improvements upon this product without any obligation to install the same on products previously manufactured.
