Continental Access CA3000 Function Manual

DVR Integration
Complete Access Control & Digital Video Solution
T
he Continental Access DVR Integration solution
provides seamless integration with the Integral
Technologies and Salient Systems DVR product
line. By combining the power of the Continental
Access CA3000 Version 2 Access Control System and ei-
ther the Integral Technologies or Salient Systems state-
of-the art DVR products, real-time video can be auto-
matically associated to any alarm event from a READER,
INPUT or NAPCO ZONE in the CardAccess system.
Then, from any CardAccess workstation, the operator
can instantly retrieve recorded video associated with the
event with a simple click of an icon.
The recorded video window has a play button, stop but-
ton and a scroll bar for simple VCR-like control. When the
Recorded Video Window is on display, the occurrence of
a new Event will replace the recorded video display with
the recorded video of the newly occurred event.
In addition, the user may monitor live video from either
4 or 9 cameras simultaneously directly from the CA3000
GUI.* The user may also remotely search for recorded
video from 1, to as many as 99, DVR servers on the net-
work by using the CA3000 Integrated Search Feature.
Other CA3000 DVR Integration features include: Remote
4/9 camera viewing, Video Picture Enhancement, PTZ
control*, Camera Preset Recall**, Zoom**, Focus**and
Iris Control**.
(**Camera must support these functions)
The CA3000 software communicates with any supported
DVR Server on the network via TCI/IP protocol. All DVR
servers are time-synchronized with the CA3000 Server.
So no matter where the video is being stored, across the
street or across the country, the CA3000 can find it.
����������
Feature Description
Video Event
Custom icon displays in the CA3000 whenever there
Notification
is video associated with an event or alarm
Motion Event Camera starts to record on motion in an area
Recording
Alarm Recording Setup events from the CA3000 to trigger camera
recording
Recording Notifies the user through the CA3000 GUI when a
Notification Event camera starts recording due to motion or alarm
Audio Inputs
Allows monitoring and recording of up to 4 audio
devices
4/9 Video View
Monitor 4 or 9 cameras* from different DVR's
simultaneously from the CA3000 GUI
PTZ Control
Pan, Tilt & Zoom control from the CA3000 GUI
(camera must be capable of these functions)
Recorded Video Search for recorded video directly from the CA3000
Search GUI.
TCP/IP
The CA3000 uses reliable TCP/IP communication to
Communication
all DVR Servers on the network
User Setup
Video monitoring is controlled and limited by a user
name and password.
Preset Control Setup and run custom camera presets directly for the
CA3000 GUI.
IP Camera Connect to IP cameras on your network
Support***
*Dependent on DVR system manufacturer. *** Salient Systems only
������������������������������
����
�
