Desa CDCFPR Owner's Operation And Installation Manual
Unvented (vent-free) gas compact classic hearth dual burner fireplace
Hide thumbs
Also See for CDCFPR:
- Owner's operation and installation manual (48 pages) ,
- Owner's operation and installation manual (48 pages) ,
- Owner's operation (48 pages)
Table of Contents
Advertisement
Quick Links
UNVENTED (VENT-FREE) GAS COMPACT CLASSIC HEARTH
OWNER'S OPERATION AND INSTALLATION MANUAL
Shown with Optional Cabinet Mantel/Hearth Base Accessory
CDCFTNA, CDCFTPA, FDCFTN, FDCFTP, VDCFTN, VDCFTP
CDCFNR, CDCFPR, FDCFRN, FDCFRP, VDCFRN, VDCFRP
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency, or the gas supplier.
For more information, visit www.desatech.com
DUAL BURNER FIREPLACE
THERMOSTAT MODELS
REMOTE-READY MODELS
Save this manual for future reference.
®
