- Page 1 PRO-DJ1 Front load professional single CD player Featuring: Fader “Q” Start, Flip Flop and Digital Output PRO-DJ1 © American DJ AUDIO Los Angeles, CA 90058 USA ®...
- Page 2 NOTE: IMPORTANT SAFETY ITEMS FOR This CD player uses a semiconductor laser. U.S.A. & CANADA MODEL ONLY It is recommended for use in a room at the WARNING: following temperature: 41˚F - 95˚F / 5˚C - 35˚C TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS CD PLAYER TO CAUTION WATER OR MOISTURE.
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS I. Read Instructions - All the safety and operating 10. Power-Cord Protection - Power-supply cords instructions should be read before the appliance should be routed so that they are not likely is operated. to be walked on or pinched by items placed upon or against them, paying particular 2. -
Page 4: Functions And Controls
FUNCTIONS AND CONTROLS PRO DJ 1 Control Layout TIME PITCH PITCH BEND LOOP RELOOP TRACK PITCH BEND SHUTTLE PITCH DISC OPEN Figure 1 1. OPEN/CLOSE - (Disc Tray Open/Close)- Press to load or eject the disc. Each press will open or close the disc tray on the transport. - Page 5 FUNCTIONS AND CONTROLS CONT. which play was started. Steady lighting of this LED indicates the ready condition. The CUE button can be held down to play a CD. When you release the CUE BUTTON it instantly returns to the CUE POINT. TRACK BUTTON - This button is used to select a Forward Skip track to be played.
-
Page 6: General Notes On Use
PREPARATIONS 1. Checking the Contents CAUTION: Check that the carton contains the following items: • Be sure to use the supplied control cables. Using other Main unit. types of cable may result in unit damage. Operating instructions (this booklet). • Be sure the power is off when connecting the control A pair of RCA cables. -
Page 7: Basic Operations
(a) SLEEP MODE PROTECTION: After 15 minutes in PAUSE or CUE Mode the CD drive mechanism will automatically go in to sleep mode. This function shuts down the laser pick-up diode extending the life of the unit. During sleep mode the LCD screen will flash repeatedly indicating sleep mode is activated - This is not a malfunction, to restart the drive simply press the Cue or Play/Pause Buttons (b) 60 SECOND TRANSPORT PROTECTION: Will automatically close transport if left open for more than 60 seconds to prevent... - Page 8 BASIC OPERATIONS CONT. • CUE POINT SETTING: A. Playback starts from pause or skip to a new track during play or pause. The beginning play point will be set to the cue point. B. Or, Press the IN BUTTON (5a) button during playback to set the new cue point. 8.
-
Page 9: Before Switching Off The Power
BASIC OPERATIONS (CONT.) 14. PITCH BENDING • The speed increases or decreases respectively when the (+) PITCH BEND BUTTON (14) or PITCH BEND (-) BUTTON (14) is pressed. The extent to which the speed changes is proportionate to the amount of time the button is pressed. -
Page 10: Specifications
SPECIFICATIONS GENERAL: Type: Twin mechanism compact disc player with wired controller. Disc type: Standard compact discs (5 in / 12cm and 3in/8cm discs) Dimensions: Player unit: 19"(W) x 3 15/32” (H) x 9 55/64” (D) Installation: Table-top mount Weight: 6 lbs. / 2.4 kgs Power supply: 110~120v/220~240v AC, 50/60Hz Power consumption:... - Page 11 Q-2221 “Q-DECK” USER INSTRUCTIONS djs wanted.
- Page 12 Q-2221 “Q-DECK” Featuring Fader “Q” Start Main Features • 2 phono, 2 line, 2 auxiliaries, & 1 microphone input • Hamster Switch for changing cross fader position • 100% cut buttons for treble, mid and bass of each channel • Fader "Q" Start w/ On/Off switch (for use with the American DJ CD Players with Fader "Q" Start) •...
-
Page 13: Table Of Contents
Index • Safety Instructions..................p.3 • Operating Determinations...............p.4 • Connections.....................p.4 • Functions (Front Panel)................p.5-6 • Inputs & Outputs (Rear Panel)............p.6-7 • Replacing the Crossfader...............p.7 • Changing the Transformer Switch............p.7 • Technical Specifications.................p.7 • Warranty & Service..................p.8 Thank you for purchasing this American DJ® product. The Q-2221 Is ready to be used, there Is no assembly required. -
Page 14: Operating Determinations
Operating Determinations When installing this mixer, please make sure that the device is not exposed to extreme heat, moisture or dust! There should not be any cables lying around. Doing so endangers you as well as others. Do not operate the mixer in extremely hot (more than 30°... -
Page 15: Functions (Front Panel)
Functions (Front Panel) (1) POWER SWITCH - Red LED will light when power is ON. (2) MASTER LEVEL - Dual LED's show the level of the left and right master output. (3) GAIN CONTROL - Used to set the level of the input signal for its designated channel. (4) BASS/MID/TREBLE CONTROL - Used to increase or decrease the LOW's, MID’s, and HI’s of the input signal. -
Page 16: Inputs & Outputs (Rear Panel)
Functions (Front Panel) Cont. (10) HAMSTER SWITCH - Changes the position of the Feather Fader™ Crossfader (9) (for crabbing). Channel 1 changes to the right side of the fader (mixing from right to left), and Channel 2 changes to the left side of the fader (mixing from left to right). -
Page 17: Replacing The Crossfader
Inputs and Outputs Rear Panel) Cont. (19) DJ MICROPHONE LEVEL / DJ MIC TREBLE CONTROL / DJ MIC BASS CONTROL - The DJ MIC LEVEL CONTROL adjusts the microphone volume output level. The DJ MIC TREBLE CONTROL and DJ MIC BASS CONTROL under the DJ MICROPHONE are used to adjust treble and bass of the DJ MICROPHONE. -
Page 18: Technical Specifications
Technical Specifications - model Q-2221 Inputs: Line: 75mV, 3k Ohm • Microphone: 2.5mV, 600 Ohm • Phono: 1.5mV, 47k Ohm Output: Line: 25V, peak to peak • Headphones: 5W @ 47 Ohm • Distortion: <0.03% Signal-To-Noise Ratios: Line: Better than 85dB • Microphone: Better than 78dB • Phono: Better than 80dB Frequency Response: Line: 20Hz - 15KHz, ±...
