3.2.1.3 Setting up SNMP services on the receiving machine
Windows
To install the SNMP service on a machine running Windows:
1. Start > Control Panel > Add or Remove Programs > Add/Remove Windows Components.
2. Select Management and Monitoring Tools.
3. Click Details.
4. Select the Simple Network Management Protocol check box.
5. Click OK.
You might be asked for lmmib2.dll that can be found on the installation disc of your operating
system.
Linux
To receive SNMP messages on a machine running Linux, the net-snmp (for RHEL and SUSE) or the
snmpd (for Debian) package has to be installed.
SNMP can be configured using the snmpconf command. The default configuration files are located in
the /etc/snmp directory:

/etc/snmp/snmpd.conf - configuration file for the Net-SNMP SNMP agent
 /etc/snmp/snmptrapd.conf - configuration file for the Net-SNMP trap daemon.
3.2.2

Log cleanup rules

This option specifies how to clean up the Acronis Backup & Recovery 10 agent log.
This option defines the maximum size of the agent log folder (in Windows XP/2003 Server,
%ALLUSERSPROFILE%\Application Data\Acronis\BackupAndRecovery\MMS\LogEvents).
The preset is: Maximum log size: 1 GB. On cleanup, keep 95% of the maximum log size.
When the option is enabled, the program compares the actual log size with the maximum size after
every 100 log entries. Once the maximum log size is exceeded, the program deletes the oldest log
entries. You can select the amount of log entries to retain. The default 95% setting will keep most of
the log. With the minimum 1% setting, the log will be nearly cleared.
This parameter can also be set by using Acronis Administrative Template.
3.2.3

Online backup proxy

This option is effective only for backup to and recovery from Acronis Online Backup Storage over the
Internet.
This option defines whether the Acronis agent will connect to the Internet through a proxy server.
Note: Acronis Backup & Recovery 10 Online supports only HTTP and HTTPS proxy servers.
To set up proxy server settings
1. Select the Use a proxy server check box.
2. In Address, specify the network name or IP address of the proxy server—for example:
proxy.example.com or 192.168.0.1
