YORKVILLE K2 Parts List

1
2
6
7
12/13
14/15
19
*NOTE: Replacement grills & HF Driver supports are 'Special-Order'
and are only available while the model is in production.
‡ Grilles & Support replacements are for CURRENT models only.
SERVICE-QuickGuide-K2-00-1v0.xls
3
5
4
8
9
9
10
11
16
17 18
21
20
25
ftp.yorkville.com
# Part# Description
Labeled Components
1 7286
_8R 30W 4.75"TWEETER
2 7464
4.5"8R 30WPGM SPEAKER SEALED BACK
3 7462
10" 2R 170W WOOFER POLY/RUB SRND
4
Z741 K2 GRILLE*
5 8267
SMALL TRAYNOR LOGO EMBOSSED ALUMIN.
6
8770 1/4-20 X 1 5/16 TRUSS PH MS JS500
7 8565
BAR HANDLE ALL METAL RECTANGULAR
8 8521
RUBBER BUMPER WITH WASHER VERYSMALL
9
8547 PLASTIC FOOT BLACK
10 8504
CORNER, 2 LEGS NOTCED LIP NICKEL
11
8483 ADAPTOR,SPEAKER STAND,METAL,BLACK
12/13
8876/8981
#6X1 1/2 PAN A JS500/RUBBER .312OD .150ID .093TH
14/15
8722/8701
#8 X 1" PAN QUAD TYPE AB B/O/ 4-40 KEPS NUT ZINC
16
3428 8' 3/18 SJT AC LINE CORD REMOVABLE
8399
17 BASSMASTER KNOB, NICKEL/CHROME
18 8400 BASSMASTER KNOB, NICKEL/CHROME
19 3425/8636
DPDT PUSH SW PCMT MAKE B4 / KNOB FLAT BLACK
3450
20 1/4 ALL GOLD PC MNT JK SKT
6405
21 RED 3MM LED 1V7 5MA
22 3445 1/4"&XLR PCB MT HORZ COMBO
3460
23 RCA DUAL PCB MT VERT GOLD .475"
24 3698
SPST ROKR SW QUIK 180" AC PWR BL/BL
25
3645 AC SOCKET RECEPTACLE WITH 0.250 TAB
26
8400 BLACK KNOB FROM SEIKAKU
27 6405 RED 3MM LED 1V7 5MA
28 6554 BLUE 3MM LED 3V9 20MA TLHB440VISHAY
Tube 12AX7 REPLACEMENT PREAMP TUBE
Control Pots and Switch
Gain 4452 _10K 5C R/A 12MM 4PIN HORZ
Tone 4453 _50K B LIN 12MM 4PIN HORZ DT P40
3393 5POS 2S NONSHORTING HORZ ROT SWT
Voice
Mast 4452 _10K 5C R/A 12MM 4PIN HORZ
Mon 4454 _10K 1B LIN 9.5MM HORIZONTAL P41
17
23
22
BRT
P40
P40
28
24
27
20
26
20
QuickGuide
