Honeywell HCX3W Specifications

HCX3W Camera
3.1 MEGAPIXEL COLOR NETWORK CAMERA
Honeywell's HCX series of megapixel cameras offers world-class video and
leading-edge IP networking technologies. When object recognition is needed over
a vast field of view, one megapixel camera can often do the same job as several
standard analog cameras. Megapixel technology increases the effectiveness of
your security system by providing greater detailed images while saving on
installation and equipment costs.
The HCX3W is a megapixel color network camera that offers up to 3.1 MP
(2048 x 1536) with frame rates up to 30 frames per second. It adapts to varying
lighting conditions to ensure the highest picture quality even in low-light conditions
down to 0.3 lux. User selectable exposure windows optimize video performance in
the areas of interest. More detailed viewing can be performed using the digital PTZ
control.
The HCX3W network camera includes advanced bandwidth management tools to
optimize performance over any network. A built-in Web server provides password
protected access to video and network setup. Setup is quick and easy and can be
customized through a Web client or from an NVR multi-zone motion detection to
trigger motion-based video streaming and privacy zones for blocking portions of
the scene that are not to be recorded. An analog output facilitates setup of zoom
and focus of the lens using spot monitors and allows easy integration with public
view monitors. Choose between 12 VDC/24 VAC power input or PoE 802.3 af for
additional installation flexibility.
Market Opportunities
The HCX3W provides optimum performance for both indoor and outdoor
applications requiring higher resolution over a larger field of view than is available
from a high resolution analog camera. Retail and banking industries greatly benefit
from using megapixel cameras. When properly positioned, both the full transaction
as well as a person's identifying features can be zoomed in to analyze transactions
or identify fraud. Other applications include multi-lane driveways, wide lobbies,
gated entrances and loading docks.
Features
• 1/2" progressive scan imager
• Up to 2048 X 1536 pixel
(3.1 megapixel) resolution
• Excellent low light performance down
to 0.3 lux
• Up to 30 fps @ 1.3 MP 1
20 fps @ 2.0 MP
12 fps @ 3.1 MP
• Includes 4.0 mm to 10 mm VFMI F1.8
lens
• Full time analog video output
• MJPEG compression
1 with image cropping
• Alarm I/O
• Multi-zone motion detection
• E-mail notification of alarms or motion
• Digital image cropping
• User selectable exposure window
• Password protection prevents
unauthorized users from altering
system settings
• Web server for remote setup of
camera video and network parameters
• 12 VDC/24 VAC or PoE 802.3 af
choice of power inputs
www.honeywellvideo.com
