UNVENTED (VENT-FREE)
PROPANE/LP GAS LOG HEATER
OWNER'S OPERATION AND INSTALLATION MANUAL
FLAME-MAX™
Golden Oak Log
Design
18", 24", 30", and 36" Variable
Manually-Controlled Model
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury, or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas sup-
plier, call the fire department.
— Installation and service must be per-
formed by a qualified installer, service
agency, or the gas supplier.
Models Also Designed Certified as Vented Decorative Appliances
This appliance may be installed in an aftermarket* manufactured (mobile) home, where
not prohibited by state or local codes. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not convertible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
FLAME-MAX™
Vintage Oak
Log Design
18" and 24" Variable
Manually-Controlled Models
Save this manual for future reference.
®
18", 24", and 30" Variable
Manually-Controlled Model
WARNING: Improper installation, adjust-
ment, alteration, service, or maintenance
can cause injury or property damage.
Refer to this manual for correct installa-
tion and operational procedures. For
assistance or additional information con-
sult a qualified installer, service agency,
or the gas supplier.
WARNING: This appliance has been spe-
cifically tested and design certified for
installation only in a solid-fuel burning
fireplace, including factory-built UL127
fireplaces and masonry fireplaces, or in
a listed ventless firebox
WARNING: This is an unvented gas-
fired heater. It uses air (oxygen) from
the room in which it is installed. Provi-
sions for adequate combustion and ven-
tilation air must be provided. Refer to
Air for Combustion and Ventilation sec-
tion on page 3 of this manual.
FLAME-MAX™
Birch
Log Design
®
Patent Pending
Advertisement
Table of Contents
Related Manuals for Vanguard FLAME-MAX UNVENTED (VENT-FREE) PROPANE/LP GAS LOG HEATER
Summary of Contents for Vanguard FLAME-MAX UNVENTED (VENT-FREE) PROPANE/LP GAS LOG HEATER
- Page 1 UNVENTED (VENT-FREE) PROPANE/LP GAS LOG HEATER OWNER’S OPERATION AND INSTALLATION MANUAL FLAME-MAX™ Golden Oak Log Design 18", 24", 30”, and 36" Variable Manually-Controlled Model WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.
-
