536EPXX
Host Accelerated Modem 56K V.92 Chipset
Product Features
Merges benefits from software and
hardware modems
Uses host's CPU without degrading
performance
Distributes functions optimally between
CPU and DSP
Cost savings
— CPU eliminates need for controller chip
— Reduced board size
— Superior price/performance ratio
Data modulation
— Data rates up to 56
— ITU-V.92, V.90 compliant
— ITU-T V.34 (33,600 to 2,400 bps)
— ITU-T V.32 bis, V.23, V.22 bis, V.21
— Bell‚ 212A and 103
— Error correction: ITU V.42 and MNP‚ 2–
4
— Data compression: ITU V.44, V.42 bis
and MNP‚ 5
Fax modulation
— ITU-T V.17, V.26ter, V.29 to 14,400 bps
— Fax Class 1 commands
PCI
— PCI 2.2-compliant
† Maximum speed allowed by the FCC is 53.333 kbps.
Notice: This document contains preliminary information on new products in production. The
specifications are subject to change without notice. Verify with your local Intel sales office that
you have the latest datasheet before finalizing a design.
Intel Confidential
kbps†
Preliminary Datasheet
PC telephony
— International telephony support
— Voice compression: ADPCM, linear, and
CL1
— 4800, 7200, 8000, 9600, and 11025
samples/sec.
— Full-duplex, echo-cancelled digital
speakerphone
— Telephone emulation for headset
applications
— IS-101 Voice commands
— ITU-V.80 for videoconferencing
Power requirements
— DSP 3.3 V Pad, 1.3 V Core
— Automatic sleep and wake-up modes
— ACPI (advanced configuration power
interface)
Packaging
— DSP: 128-pin LQFP
— AFE: 44-pin VQFP
Exceeds Microsoft*‚ PC 00 requirements
Microsoft‚ Windows*‚ TAPI-compliant
AT command-driven
Order Number: 273503-001
June 2001
Advertisement
Table of Contents
Summary of Contents for Intel 536EPXX - PRELIMINARY
-
Page 1: Product Features
536EPXX Host Accelerated Modem 56K V.92 Chipset Preliminary Datasheet Product Features Merges benefits from software and PC telephony hardware modems — International telephony support Uses host’s CPU without degrading — Voice compression: ADPCM, linear, and performance Distributes functions optimally between —... - Page 2 ® Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
- Page 3 Host Accelerated Modem 56K V.92 Chipset — 536EPXX Overview The software upgradable 536EPXX chipset and reference design from Intel is targeted at modem and computer manufacturers. This new product is a leap forward in technology, performance and cost savings. The 536EPXX is a Host Accelerated Modem solution that combines and optimizes the best features from software and hardware modems.
- Page 4 536EPXX — Host Accelerated Modem 56K V.92 Chipset Satisfies Legacy Applications The 536EPXX supports all PC-based communication requirements. Its robust host-based controller software and powerful DSP support all standard AT commands for data, Class 1 fax and IS-101 voice. Comprehensive Telephony Features Voice telephony is becoming increasingly important.
- Page 5 Host Accelerated Modem 56K V.92 Chipset — 536EPXX Figure 3. Functional Block Diagrams 536EPU/G HOST PCI BUS COMPUTER Silicon RING CODEC/DAA DQ82536 NVRAM 536EPA HOST PCI BUS COMPUTER RING MD1724 DQ82536 MICROPHONE / SPEAKER (OPTIONAL) NVRAM Intel Confidential Preliminary Datasheet...
- Page 6 536EPXX — Host Accelerated Modem 56K V.92 Chipset Figure 3. Functional Block Diagrams (Continued) 536EPUS/GS/GL HOST PCI BUS COMPUTER Silicon RING CODEC/DAA DQ82536 MICROPHONE / SPEAKER (OPTIONAL) MD1724 NVRAM (OPTIONAL) 536EPAS HOST PCI BUS COMPUTER RING MD1724 DQ82536 MICROPHONE / SPEAKER (OPTIONAL) MD1724 NVRAM...
- Page 7 Host Accelerated Modem 56K V.92 Chipset — 536EPXX Chipset Descriptions The 536EPXX is a Host Accelerated Modem chipset family consisting of a DSP (digital signal processor), and a Silicon Laboratories CODEC/DAA or an Intel Analog Front End (AFE). These chipsets support a variety of applications and need no additional firmware development. The current 536EPXXchipsets are shown in Table 12 “Chipset Composition (PCI &...
-
Page 8: Modes Of Operation
536EPXX — Host Accelerated Modem 56K V.92 Chipset Modes of Operation The 536EPXX chipset family provides complete modem functions for the following modes: Group 3 Fax, Data, IS-101 Voice, V.42/MNP 2–4 (Microcom Networking Protocol Classes 2 through 4), Error correction, V.44, V.42 bis/MNP 5 (Microcom Networking Protocol Class 5), and Videoconferencing. -
Page 9: Other Features
Host Accelerated Modem 56K V.92 Chipset — 536EPXX 7.1.5 Videoconferencing (V.80) Support The 536EPXX supports the ITU-V.80 recommendation. This option ensures compatibility with host-based H.324 videoconferencing application software. The 536EPXX chipsets support both transparent and framed submodes of the V.80 synchronous access mode, plus Voice Call First and full-duplex speakerphone. -
Page 10: Call Progress
536EPXX — Host Accelerated Modem 56K V.92 Chipset 7.2.7 Call Progress The modem monitors the detection of call-progress tones during call origination and reports them to the DTE. Call-progress tones include dial, busy, ringback, and answer. 7.2.8 Caller ID Caller ID is a service that allows the user to see the caller’s telephone number and name. Caller ID also provides information on call date and time. - Page 11 Host Accelerated Modem 56K V.92 Chipset — 536EPXX Table 14. DTMF Tone Pairs (Continued) Dial Tone 1 Tone 2 Digit (Hz) (Hz) 1633 1633 1633 Table 15. Communication Modes and Data Rates Baud Rate Carrier Constellation Application Mode Data Rate (bps) Modulation (symbols/sec.) Frequency (Hz)
- Page 12 536EPXX — Host Accelerated Modem 56K V.92 Chipset Table 15. Communication Modes and Data Rates (Continued) Baud Rate Carrier Constellation Application Mode Data Rate (bps) Modulation (symbols/sec.) Frequency (Hz) Points 57333 , 56000, 54666, 53333, 52000, 50666, 49333, 48000, V.92 46666, 45333, Mode 44000, 42666,...
-
Page 13: Hardware Interfaces
Host Accelerated Modem 56K V.92 Chipset — 536EPXX Hardware Interfaces The 536EPXX chipset supports hardware interfaces for the host, expansion bus, non-volatile RAM (NVRAM), CODEC/DAA, speaker, microphone, and general-purpose I/O functions. The hardware interfaces are demonstrated below. Figure 4. Modem System Block Diagram (536EPXX) 536EPXX NVRAM CODEC... -
Page 14: Daa Interface
536EPXX — Host Accelerated Modem 56K V.92 Chipset Table 16. PCI Subsystem Vendor ID and Subsystem ID with No EEPROM (Continued) GPIO[10:8] Subsystem Vendor Subsystem ID Intel (ID = 8086) 1001h Intel (ID = 8086) 1002h Intel (ID = 8086) 1003h Intel (ID = 8086) 1004h... -
Page 15: Speaker Interface
Host Accelerated Modem 56K V.92 Chipset — 536EPXX Important: A minimum recovery time of 200µs from D2 to D0 is required before the next function can be accessed. Attempted access sooner than this could result in undefined system behavior. 8.3.3 cold Switching from main supply outputs to the auxiliary power source requires strict power budgeting of slots, determining those to consume full 3.3V...
