GE Café CV936MSS Dimensions And Installation Information

CV936MSS
GE Café Designer Hood
™
Dimensions and Installation Information (in inches)
Installation Information:
Before installing, consult Use & Care/
installation instructions packed with
product for current dimensional data.
Optional Kits for 30" Designer hoods
JXCHSS—Stainless Chimney Kit
Amp Rating
120V 3.9
For answers to your Monogram, GE Profile
®
GE ® appliance questions, visit our website at
ge.com or call GE Answer Center
®
800.626.2000.
Installed above a cooktop
(shown with optional chimney kit)
Telescopes for
9' and 10'
ceilings
Hood
Installation
Height
(24" to 36")
(Standard 8 ft. ceiling 96")
or
™
service,
11
42" min.
52" max.
12
30
18
21
36
Installed above a range
(shown with optional chimney kit)
Telescopes for
9' and 10'
ceilings
Hood
Installation
Height
(24" to 36")
Specification Revised 7/09
11
42" min.
52" max.
12
30
18
21
36
Listed by
Underwriters
Laboratories
220976
