Summary of Contents for Denso CU-7011
- Page 1 User's Manual...
- Page 2 Copyright © DENSO WAVE INCORPORATED, 2001 All rights reserved. No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher. Specifications are subject to change without prior notice. All products and company names mentioned in this manual are trademarks or regis-...
- Page 3 Preface Please READ through these operating instructions carefully. It will enable you to operate your CU-7011 correctly. After you have finished reading the instructions, keep this manual handy for speedy reference.
-
Page 4: How This Book Is Organized
Functions of the CU-7011 Chapter 3 Components and Functions Chapter 4 CU Status Indication by LED Indicators Chapter 5 Applying Power to the CU-7011 Chapter 6 Connecting to Ethernet Chapter 7 Charging the Rechargeable Battery Cartridge Chapter 8 Displaying the CU System Information on the BHT... - Page 5 ■ Related Publications BHT-7000 User's Manual BHT-7000 User's Manual "LAN Support Version" BHT-100 Series User's Manuals BHT-100 Series User's Manual "LAN Support Version" BHT-BASIC Programmer's Manual BHT-BASIC Programmer's Manual (BHT-100 series)
-
Page 6: Safety Precautions
SAFETY PRECAUTIONS Be sure to observe all these safety precautions. Strict observance of these warning and caution indications are a MUST for preventing accidents which could result in bodily injury and substantial property damage. Make sure you fully understand all definitions of these terms and related symbols given be- low, before you proceed on to the text itself. - Page 7 • Avoid dropping the battery cartridge or letting it undergo any shock or impact. Doing so could cause the batteries to break, generate heat, rupture or burn. • Only use the dedicated charger (CU-7011, CU-7001, C-700 or C-750) for charging the battery cartridge. Using a different type of charger could...
- Page 8 Handling the battery cartridge • Never charge a wet or damp battery cartridge. Doing so could cause the batteries to break, generate heat, rupture, or burn. Handling the CU • Never put the CU in places where there are excessively high temperatures, such as inside closed-up automobiles, or in places exposed to direct sunlight.
- Page 9 ■ Limited Warranty on Software Products In no event will DENSO WAVE be liable for direct, indirect, special, incidental, or conse- quential damages (including imaginary profits or damages resulting from interruption of operation or loss of business information) resulting from any defect in the software or its documentation or resulting from inability to apply the software or its documenta- tion.
-
Page 10: Table Of Contents
Chapter 5 Applying Power to the CU-7011 ... 4 Chapter 6 Connecting to Ethernet ... 5 Setting the Transmission Speed of the CU-7011 ... 5 Interface Cable Connection ... 6 Communication with the Host Computer ... 7 Chapter 7 Charging the Rechargeable Battery Cartridge ... 8 Chapter 8 Displaying the CU System Information on the BHT ... -
Page 11: Chapter 1 Ethernet System Configuration
Chapter 1 Ethernet System Configu- ration Connecting CU-7011 units to an Ethernet enables you to use BHTs as a LAN client. Host computer Ethernet 10Base-T For details about FTP and Socket API, refer to the BHT-BASIC Programmer's Manual. For procedures about setting the TCP/IP and FTP on the BHT, refer to the BHT User's Manual. -
Page 12: Chapter 3 Components And Functions
Lights when the BHT is communicating with the host computer. POWER (Power LED, green) Lights when the power is applied to the CU-7011. Optical interface port Used to exchange data optically with the BHT. Place the CU on a flat, horizontal plane. Do not install the CU on a wall or in a vertical position. -
Page 13: Chapter 4 Cu Status Indication By Led Indicators
Chapter 4 CU Status Indication by LED Indicators According to the ON/OFF states of the POWER and DATA LED indicators, you may check the machine status of the CU-7011 as listed below. POWER DATA Flashing slowly* Flashing slowly Flashing* Flashing slowly... -
Page 14: Chapter 5 Applying Power To The Cu-7011
CU-7011 Apply power to the CU-7011 via the dedicated AC adapter. Connect the outlet plug of the AC adapter to the power inlet connector of the CU-7011, then plug the other end of the AC adapter into a wall socket. -
Page 15: Chapter 6 Connecting To Ethernet
Chapter 6 Connecting to Ethernet Setting the Transmission Speed of the CU-7011 Set the transmission speed of the CU-7011 to the same value as that of the BHT, by using the DIP switch provided on the bottom of the CU-7011. -
Page 16: Interface Cable Connection
• When connecting the modular plug, insert it until it snaps into place. To disconnect it, press the lock lever and pull it out. • Do not force the modular plug in or out. Doing so will result in a CU-7011 failure. -
Page 17: Communication With The Host Computer
Turn on the BHT and run System Mode. Set the TCP/IP parameters (incl. IP address and subnet mask)) and FTP parameters (incl. server IP and user ID). Put the BHT on the CU-7011. CU-7011 Take care not to put the hand strap or get any foreign material between the CU and BHT. -
Page 18: Chapter 7 Charging The Rechargeable Battery Cartridge
Generally, it is necessary to replace the battery cartridge after it has undergone approx. 300 cycles of charging and discharging operation. Plug the AC adapter of the CU-7011 into a wall socket. The POWER LED on the CU-7011 comes on. - Page 19 ■ Charging Operation and BHT's Indicator LED Operator's Action Place the BHT on the CU-7011. ⇓ After approx. 6 hours ⇓ Remove the BHT. The charging time is approx. 6 hours if the "Charge the battery!" message is displayed on the BHT. The battery cartridge not discharged so much will be fully recharged in shorter time.
-
Page 20: Chapter 8 Displaying The Cu System Information On The Bht
You may display the CU-7011 system information on the BHT's LCD. Set the BHT on the CU-7011 and operate the BHT to display the SYSTEM INFORMA- TION screen on the LCD. From that screen, you may call up the system program version and MAC address. -
Page 21: Chapter 10 Mac Address
Chapter 10 MAC Address The MAC address of the CU-7011 is printed on the nameplate. Nameplate MAC address (example) -
Page 22: Appendix Specifications
Appendix Specifications [ 1 ] Product Specifications Power Source -Europe -U.S. -Australia Power Consumption Dimensions (W) x (L) x (H) Weight Operating Ambient Temperature Operating Humidity [ 2 ] Charging Requirements Charge current: Charge time: [ 3 ] Interface Ethernet interface 230 VAC, 16 VA 120 VAC, 13 VA 10 to 18 VDC, 450 mA (on 12 VDC) - Page 23 In no event will DENSO WAVE be liable for any direct or indirect damages resulting from the application of the information in this manual.
