Input Terminal Pin Assignment; Input Signal & Power - Samsung LTN154X3-L01 - 15.4 WXGA Laptop LCD Screen Product Information

5. INPUT TERMINAL PIN ASSIGNMENT

5.1. Input Signal & Power LVDS, Connector :
PIN NO SYMBOL
1 VSS
2 VDD
3 VDD
4
VEEDID
5 NC
CLKEDID
6
DATAEDID
7
8
RxIN0-
9
RxIN0+
10
VSS
11
RxIN1-
12
RxIN1+
13
VSS
14
RxIN2-
15
RxIN2+
16
VSS
17
RxCLK-
18
RxCLK+
19
VSS
20 NC
21 NC
22
NC
23
NC
24
NC
25
NC
26 NC
27
NC
28
NC
29
NC
30
NC
Doc.No. LTN154X3-L01
Mating Connector :
FUNCTION
Ground
POWER SUPPLY +3.3V
POWER SUPPLY +3.3V
DDC 3.3V Power
No Connection
DDC Clock
DDC data
LVDS Differential Data INPUT (R0-R5,G0)
LVDS Differential Data INPUT (R0-R5,G0)
Ground
LVDS Differential Data INPUT (G1-G5,B0-B1)
LVDS Differential Data INPUT (G1-G5,B0-B1)
Ground
LVDS Differential Data INPUT (B2-B5,Sync,DE)
LVDS Differential Data INPUT (B2-B5,Sync,DE)
Ground
LVDS Differential Data INPUT (Clock)
LVDS Differential Data INPUT (Clock)
Ground
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
ISSUED DATE
Product Information
(JAE, FI-XB30SL-HF10
JAE FI-X30M or Compatible
(
2006-06-13
or Compatible)
)
POLARITY REMARK
Negative
Positive
Negative
Positive
Negative
Positive
Negative
Positive
Page
/ 13
8
