Compaq 252663-B24 - PDU Power Distribution Strip Installation Instructions

M P
ODULAR OWER
D
ISTRIBUTION
E B
XTENSION
Installation Instructions
Read Instructions Completely Before
Beginning Installation Procedures
Printed on recycled paper
NOTICE
© 2001 Compaq Information Technologies Group, L.P.
Compaq and the Compaq logo are trademarks of Compaq Information
Technologies Group, L.P. in the U.S. and/or other countries. All other
product names mentioned herein may be trademarks of their
respective companies.
Compaq shall not be liable for technical or editorial errors or
omissions contained herein. The information in this document is
provided "as is" without warranty of any kind and is subject to change
without notice. The warranties for Compaq products are set forth
in the express limited warranty statements accompanying such
products. Nothing herein should be construed as constituting an
additional warranty.
Compaq Modular Power Distribution Unit Extension Bar Brackets
Installation Instructions
First Edition (January 2002)
Part Number 270078-021
270078- 021
U
NIT
B
AR RACKETS
About This Device
These instructions serve as an outline to assist qualified
personnel with the installation of the Compaq Modular Power
Distribution Unit Extension Bars into the Rack Extension Kit.
Four Extension Bars are provided with each Compaq Modular
Power Distribution Unit. The mPDU installs in the Rack
Extension Kit of Compaq 9000 series racks.
Important Safety Information
Read Before Installing Product
Please refer to the Important Safety Information guide (included
with the mPDU kit) before installing this product.
Kit Contents
I
Extension Bar L-brackets (8)
I
Screws to attach brackets to rack (8)
For L-bracket spares, order P/N 271658-001.
Installing the Extension Bars
Align the L-brackets with the screw hole in the extension bars.
Use the 5mm screws provided in the Modular Power
Distribution Unit Kit to attach the brackets to the extenstion
bars. Align the slots on the L-brackets with the holes in the Rack
Extension Kit, and then secure the extension bars by using the
screws provided in this kit.
Translated versions of this document are available at
.
www.compaq.com
Installation is complete.
