Ignition Coil
IGT004 Type
Features
Via the system-provided input voltage 230-240V, the high voltage coil is stimulated
and gives the voltage output between 14KVo-p & 25KVo-p to start up the ignition system
of the gas furnance or the molecule ozonization of air cleaning M/C.
Applications
Gas Igniter
Oil Igniter
Air Cleaner
Electronic Ozonizer
Mechanical Dimension:
25.0 Max.
4
13.7 0.5
1
Electrical Characteristics:
o
AT 25 C, 65%RH, INDUCTANCE TESTED@1KHz/1V
PART NO.
INDUCTANCE (uH)
IGT-004
o
Operation temperature: -40C to +105C
o
Storage temperature: -20C to +85C
Input voltage: 240 Vdc
No-load voltage: 14KV min.
Insulated with epoxy resin
Recommended Circuit:
+
-
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
Unit: mm
28.5 Max.
4.0 0.5
23.0 0.5
3
16.0 0.5
2
PRIMARY
SECONDARY
INDUCTANCE (mH)
INDUCTANCE (uH)
22.0 25%
290.0 25%
o
o
SW1
DC
C1
SUPPLY
2.2nf
240 Vdc
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
0.5x1.0
23.0 Max.
PRIMARY
PRIMARY
SECONDARY
DCR (m ) MAX.
DCR ( ) MAX.
55
T1
SW2
1
4
2
3
72
Schematic :
1
PRI
2
WEIGHT
500
32g
OUTPUT
C2
50pf
4
SEC
3
