HP rp5800 Illustrated Parts And Service Map

Illustrated Parts & Service Map
HP rp5800 Retail System
©
2011 Hewlett-Packard Development Company, L.P. The information con-
tained herein is subject to change without notice. HP shall not be liable for tech-
nical or editorial errors or omissions contained herein. Intel, Pentium, Intel
Inside, and the Intel logo are trademarks or registered trademarks of the Intel
Corporation and its subsidiaries in the U. S. and other countries.
Document Number 659816-001.
Key Specifications
Processor Type Intel® Core i7, i5, i3, Pentium Dual-Core
RAM Type Non-ECC DDR3 PC3-10600 (1333 MHz) & PC3-8500 (1066 MHz)
Maximum RAM 16 GB
Expansion Slots •
(Low profile)
•
•
Chipset Intel Q67 Express
Graphics Adapter Integrated Intel HD graphics
Bays •
•
I/O Interfaces Front: USB 2.0 (2; covered)
Rear: USB 2.0 (5), 24V powered USB, serial (RS-232 compat-
ible), parallel (optional), eSATA (optional) RS-232 (2; up to 4
total), USB+PWR 12V (USB+PWR 12V cards optional (3 per
card) for a total of 6), PS/2 (2), RJ-11 (Cash Drawer port),
VGA, DisplayPort v1.1a, line-in, line-out, RJ-45
Preinstalled Operating •
Systems
•

Spare Parts

System Unit
1 Access panel
2 Power supply, 90% efficient
3 Chassis
4 Front bezel
* Not shown
HP rp5800 Retail System
1st Edition May 2011.
(2) PCIe-x16
(1) PCIe-x1
(1) PCI
(1) external 5.25-inch
(2) internal 3.5-inch
Windows 7 Professional 32/64
Windows Embedded POSReady 2009
Cables
1 Front I/O cable and power switch assembly
2 SATA cable, 19.5 inch, 2 straight ends
* SATA cable, 25.2 inch, 1 straight end, 1 angled end
* Powered serial cable
* Adapter, DisplayPort to VGA
* Adapter, DisplayPort to DVI
* Adapter, DisplayPort to HDMI
* DisplayPort cable
Cable cover
*Not shown
Keyboards (not illustrated)
PS/2, Basic*
USB, Basic*
USB Mini (-001, -121 only)
Washable
French Canadian
*-001 only
Mass Storage Devices (not illustrated)
16X SATA DVD±RW drive with LightScribe
16X SATA DVD-ROM drive
Blu-ray BD-RW SuperMulti DL Drive with LightScribe
1 TB, 7200 rpm SATA hard drive
500 GB, 7200 rpm SATA hard drive
250 GB, 7200 rpm SATA hard drive
160 GB Solid State Drive (SSD)
80 GB Solid State Drive (SSD)
System Boards, Memory, Processors
System boards with thermal grease, alcohol pad, and CPU socket cover
1 System board, includes Trusted Platform module (TPM)
653025-001
* System board, does not include TPM
659246-001
Memory modules (PC3-10600, CL9)
Not spared
2 1 GB
653025-001
* 2 GB
* 4 GB
Processors (include thermal replacement material)
* Intel Core i7 2600 processor, 3.4 GHz, 8-MB L3 cache, 95W
* Intel Core i5 2400 processor, 3.1 GHz, 6-MB L3 cache, 95W
* Intel Core i3 2120 processor, 3.3 GHz, 3-MB L3 cache, 65W
* Intel Pentium Dual-Core G850 processor, 2.9 GHz, 3-MB L3 cache, 65W 655973-001
* Not shown
659816-001
537745-xx1
537746-xx1
535873-xxx
577495-xxx
-121 U.S.
655579-001
638813-001
638814-001
653023-001
603250-001
484156-001
617450-001
487562-001
653028-001
-001
581600-001
581599-001
617030-001
636930-001
636929-001
636927-001
646809-001
607817-001
655580-001
628930-001
635802-001
635803-001
585157-001
638632-001
638630-001
638412-001
