Table of Contents A. Introduction ........................2 General Description......................2 Features ..........................2 D. Before Using the Security Application Program – Memorex LOCK ........ 3 Introduction to Memorex LOCK..................5 Main Screen......................5 Set Password / Change Password................5 Disable Password ....................8 Password Management...................
It allows you to create variable sized public and secure partitions. Secure partitions are assigned your own password (to a maximum of 16 characters). Memorex LOCK provides users with convenience and privacy, as well as high security for data on your USB flash memory storage device.
“Removable Disk” icon. This is the “Public” partition. The security application program – Memorex LOCK will be stored in this area as well as the “Secure” partition area. Double clicking on the Removable Disk icon will open the following screens: Partition 1 –...
Page 5
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 4 - Partition 2 – Secure Area The secure area is password protected and can be accessed by typing in the correct password only. If NO password exists or has been disabled, display defaults to the Public area.
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 5 - E. Introduction to Memorex LOCK E1. Main Screen Password Hint About Disable Password Set Password Configure size Log Out Move the mouse cursor over the icons, and the description of each button will appear, as shown in the above labels.
Page 7
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 6 - Setup Password : If no password exists, simply enter a password of your choice up to 16 characters in length. You may also enter a password hint (maximum 32 characters including spaces) to remind you of your password in the event that you forget it.
Page 8
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 7 - Change Password : If a password exists, before you make any changes you will need to enter the current password. Enter the current password, and new password of your choice. You may also edit the password hint at the same time. Click the “Show Password”...
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 8 - E3. Disable Password Press the second button on the lower left to “Disable” (remove) the password. You will be prompted to enter your password. Press (cancel) to cancel if you do not want to remove your current password and password hint. Enter the correct password and your password will be disabled (removed).
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 9 - E4. Password Management You have six chances to enter the password correctly, before the secure partition of your device gets re-formatted. A screen displays at each unsuccessful trial. If you have forgotten your password, click on the password hint to remind you of your password.
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 10 - The capacity of the secure partition will appear on the screen after successfully re-formatting. E5. Unlock Device If you have setup a password, when you remove your device from the USB port (or if there is a suspension in power), the secure partition of your device gets locked automatically.
E6. Configure Partition Sizes You can change the sizes of the two partitions (public and secure). Public Partition Press the lower right button of the Memorex LOCK program to resize public and secure partition areas, as shown on the next page.
Page 13
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 12 - You need to “Disable” your password first before you can use this “Configure Size” (resizing) function if you have already setup a password. Follow section E3 of this manual to disable your password. It may be necessary to remove and plug your device in again after disabling the password.
Page 14
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 13 - Move the pointer to the left or right to change the size of the public and secure area (minimum capacity that can be set for public area is 2MB). Press (cancel) to cancel the operation if you do not want to change the current public and secure area;...
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 14 - The change in capacity sizes of each partition can be verified by right clicking the drive icon and choosing properties. The secure Partition is shown in this example. Secure partition Before Configure Size After Configure Size NB :...
Document No.: M0-0001-4504-1 Effective: 14-Oct-2009 Version: Page: - 15 - G. Running the Program As Privileged User Some users may see this following screen. Check and make sure that you have plugged in your device and your Windows operating system did recognise your device. Otherwise, please check FAQ Q3 for more detail. H.
