Universal Remote Control User's Manual
Application: Universal Remote Control for TV, VCR, SAT, Cable TV, Hi-Fi Audio System, DVD, STB etc
Application Manual
MANUAL SETTING
1.Look up the three-digit code for your brand and type of device in the Code Tables, then turn on the device.
2.Press and hold the SET key then press the DEVICE Key, then the indicator lights will turn on.
3.Press the three-digit code for your device. Each time LED blinks one time.
4.Press Device Key. The activity indicator should flash, then turn off to indicate that the code is accepted.
Note: If no key on your remote is pressed for 10 seconds, the programming process will stop automatically,
and you will have to start over.
QUICK POWER SCAN (AUTO FIND) SETTING
1.Turn on the device you want the remote to control, and point the remote toward it.
2.Press and hold the SET key then press the DEVICE Key , then the indicator lights will turn on.
3.Press the SET key again, the indicator light will flash.
4.Press the POWER once at a time (setup counter up) until the device turns OFF.
5.Press the SET key to change the scan direction.
6.If device is turn off then press DEVICE key (any), then indicator should flash and turn off to indicate that
the code is accepted.
Note: If no key on your remote is pressed for 30 seconds, the programming process will stop automatically,
and you will have to start over.
If the code is not match with your device, then repeat step 1-6.
POWER SCAN CONCEPTS
1.During the power scan mode, If you press and hold POWER, the power code data is transmitted continuously.
2.During the power scan mode, If you press and release SET, the power code data is transmitted one time in
reverse direction.
3.During the power scan mode, If you press and release DEVICE Key, the current code data is selected.
TEST THE SELECTED CODE
1.Press SET and Digit 1, LED will be flashing. The flashing time is stand for the 1st digit of the selected code.
E.g.: Code=547, LED will be flashing 5 times.
2.Press SET and Digit 2, LED will be flashing,. The flashing time is stand for the 2nd digit of the selected code.
E.g.: Code=547, LED will be flashing 4 times.
3.Press SET and Digit 3, LED will be flashing,. The flashing time is stand for the 3rd digit of the selected code.
E.g.: Code=547, LED will be flashing7 times.

Advertisement

Table of Contents
loading

Related Manuals for Insignia IS-HDPLTV42

Summary of Contents for Insignia IS-HDPLTV42

  • Page 1 Universal Remote Control User's Manual Application: Universal Remote Control for TV, VCR, SAT, Cable TV, Hi-Fi Audio System, DVD, STB etc Application Manual MANUAL SETTING 1.Look up the three-digit code for your brand and type of device in the Code Tables, then turn on the device. 2.Press and hold the SET key then press the DEVICE Key, then the indicator lights will turn on.
  • Page 2 Universal Remote Control User's Manual CODE Aiwa 054, 118, 135 Akai Atle Caabletime 000, 001, 002 Caravell Denon 022, 137, 039, 041 Dynatech Emerson Fisher 021, 121, 139, 140 Haitai Hitachi Inkei Inkel 078, 123, 143 Karcher Kenwood 025, 053, 124, 144, 145 Lenco 058, 059, 060, 061, 062, 063, 064, 065, 066, 067, 073, 024, 074 Luxman...
  • Page 3 Universal Remote Control User's Manual CODE Kenwood Magnavox Panasonic Philips Pioneer Sony Toshiba Zenith Brand of HIFI CODE Fisher Hitachi Kenwood 003, 007, 008, 009, 010 Lenco 068, 069, 070, 071, 072, 073, 074 Nordmende Onkyo 011, 012 Panasonic Pioneer Sanyo Sharp Sherwood...
  • Page 4 Universal Remote Control User's Manual Brand of DVD CODE Aiwa 087, 118, 041, 058, 153 Ames Apex 115, 122, 127 Atle Classic Daewoo 076, 107, 109 Denon 005, 135, 078 Elta 116, 121 Govideo Harman Kardon 073, 125 Hisense 145, 146 Hitachi 007, 075, 131, 1 03, 154 Integra...

  • Page 5: Table Of Contents

    Universal Remote Control User's Manual CODE Brand of VCR Admiral 089, 094, 212 Aiko 124, 258 Aiwa 073, 098, 104, 185 Akai 001, 002, 032, 033, 070, 071, 101, 107, 108, 109, 110, 165, 166, 167, 244, 164, 181, 236, 000 Alba 046, 010 American High...

  • Page 6: Govideo

    Universal Remote Control User's Manual Erres Ferguson Fidelity Finlandia 039, 054 Finlux 007, 073, 029, 002, 039, 020, 011, 054 First - line Fisher 009, 020, 039, 037, 095, 096, 097, 099, 140, 141, 142, 283, 197, 204, 229, 266 Formenti -Phoeix 011, 054 Fuji...
  • Page 7 Universal Remote Control User's Manual LXI(sears) 095, 097, 098, 104 M Electroinc Magnadyne Magnasonic Magnavox 087, 088, 090, 098, 103, 120, 121, 147, 162, 282, 172, 241, 190 Magnin Manest h Marantz 003, 007, 011, 036, 054, 087, 090, 114, 120, 121, 148, 186, 240 Mark Marta Matsui...
  • Page 8 Universal Remote Control User's Manual Portland 116, 118 Proline Proscan Pulsar 088, 162 Quarter Quartz Quasar 087, 120, 121, 173, 249, 195 Quelle 003, 006, 007, 015, 026, 081, 018, 011, 054 Radio 114, 120, 121, 125, 140, 141, 161, 080 Shack/Realistic Radioshack 197, 204, 212, 181, 229...
  • Page 9 Universal Remote Control User's Manual Tashiro Tatung 007, 073, 054, 165 TEAC 073, 165 Technics 087, 120 Teknika 073, 011, 087,098, 104,257, 208, 120, 121, 279, 284 Telefunken 001, 004, 021, 041, 042, 044, 049 Telemeister Tenosal Thomas Thomson 001, 004, 021, 043, 047 Thorm Thorn-Ferguson 001, 004, 030, 042, 049...
  • Page 10 Universal Remote Control User's Manual Brand of AUX CODE A mark 018, 023 Metz 039, 371 Mitsubishi 016, 017, 065, 370, 026 Akai 016, 019 Alleron Anam 016, 019, 026, 021 Nordmende Archer Oceanic(F) Audio Dynamics Omega Audiovox Orion Autovox Others 047, 028, 031, 032 Panasonic...

  • Page 11: Classic

    Universal Remote Control User's Manual Brand of TV CODE A mark 318,360 Aasic Line Abex Accuscan 105,331,336,339,362 Admiral 032,136,243,246,257,253,331,336,347,381,464,487 Aico Aiwa 225,424,471,222 005,045, 085,087,140,168 , 224,247,319,354,382 Akai Alba Albiral 001,009 Alleron 344,512 Amark Ambassador Amenicaction Amstrad 006,204,359,551 Atron Anam 105,240,321,339,360 Anam National 455,504,586,484,185 045,241,319,354,360,373,383,456,520,489,089,081...

  • Page 12: Dynatech

    Universal Remote Control User's Manual Daytron 204,334,449,081 Decca(UK) 002,004,026,028,031 Degraaf Denon Dimensia 315,380,560,096 Dorig Dual 041,221 Dual - Tec 004,011,019,029,033 Dumont 007,024,091,136,566,316 Dynatech 377,222 Edison 005,032,115,046,064 Elbe 001,009 Electroband 365,231,382,489,087 Electtohome 333,335,365,484,583,481,388 Elite Elman 019,029,033 Emerson 129,136,105,204,103,123,233,239,240,243,247,258,262,263,264,265,283,318,319,333,334, 337,338,339 ,343,344, 345,350,355,359,482,504,545,512,489,490,385,390,391,392,393,394, 395,396,397,449,451,452,505,507,555,510,511,561,426,398,399,401,400,523,524,530, 475,534,476,578, 222,070,062,185,186,188,229,217,211,203,200 ,485,486,554,551,491, Envision...
  • Page 13 Universal Remote Control User's Manual Interfunk 005,007,024,027,039,044,051,067,068,069,071,091,136 Irradio 008,007,024,038,042,059,091,134,226 007,024,031,063,091,127,154, ITT-Nokia 005,007,024,032,039,040,044,048,063,067,068,069,072,073,091,127,143,149,154,158 Janco 215,216 235,327 JC Penny 096,089,074,135,130,380,388,403,449,458,506,493,560,570,481,573,579,272,247,251 365,231,382,087 Jensen 070,109,127,159,167,168,270,271,346,234,445,385,404,405,493,527,477, Kaisui 007,024,091,144 Kamp 105,316,339 Karcher 007,024,026,091,140,144,156 Kawasho 355,382,087 Kendo Kennedy 025,075,076 Kenwood 045,354,583 Kloss 371,376 Kloss Novabeam 450,501,536,546 Konka 038, 141,173,509,514,525,531 Korting 036, 043,136,138,192...

  • Page 14: Sampo

    Universal Remote Control User's Manual Onwa 105,240,339 Optimus Optonica 347,362,487,171 Orion 005,006,016,028,031,032,046,056,064,085,099,103,105,115,167,168,169, 224,239,243,334,339,345,566 507,211 Osume Otto Versand 025,027,043,051,054,065 Pael 003, 007,008,,024,091 Palladium Panasonic 001,003,019,036,039,065,100,102,104,170,208,251,260,289,290,308,321,322, 327,358,478,493,484,569 Penny 232,233,236,319,325,327,328,329,334,341,342,353,354 Perdio 024,091,007,033,149 Philco 019,023,024,025,133,136,150,151,577,237,243,247,255,273,277,309,318,319, 327,341,354,371,235,546,536,474,484,583,385,074,070 Philips 003,026,027,071,136,070,172,173,174,074,228,209,024,091,007,149,141,005,032, 115,046,064,155,235,255,284,288,296,297,298,312,327,328,332,356,357,483,484, 583,385,536,472,387,516,425,460,515, 543,546,477,584,585,488 Philips/Magnavox 387,389,543,585,488 Phonola 149,156 Pice Club Pilot...
  • Page 15 Universal Remote Control User's Manual Sharp 022,038,043,053,065,109,114,178,201,171,204,233,565,576,582,487,498,499, 449,385,395,419,420 Shogun 250,319 Siarem 000,025,029,136 Sicatel 001,009,022,065 Siemens Siesta Signature 2000 904,903,912,318,319,320,329,334,336,344,347,381,408,578,902,253,257,098 Silver 141,208 Simpson 242,328,353,074 Singer 025,029, 131,136 Sinudyne 005,006,016,025,026,029,031,032,046,056,064,115,136,172,177,219, Sonic Sonoko Sony 028,109,005,117,118,119,120,163,179,224,123,231,245,330,364,365,369,539,382, 463,466,46 9,460,087 SounDesign 105, 334,339,344,353,239,240,512 Spectravision 587,360 Squareview 551,116 105,240,339 Starlite...
  • Page 16 Universal Remote Control User's Manual White Westinghouse 003,026,036,140,243,244,557,029,030 XR-1000 Yamaha 045,583 Yoko 004,033,140 Yorx Zanussi 005,026,032,046,064,075,076,115, Zenith 181,243,253,254,316,336,363,367,368,494,507,519,534,566,578,408,442,443,468 Zonda Zoppas 005,032,046,064,115 Brand of SAT CODE Alba 031,060 AlphsStar American High Amstrad 000,001,032,107,053 Ankaro Apollo Astra 001,033,107 Aura 053,106 Barcom Benjamin BEST Bush 060,026...
  • Page 17 Universal Remote Control User's Manual Lenco 046,049,100,101,102 Leng Luxor 056,019,026 Macom Magnavox 124,125,063,141,144,034 Marantz Maspro 016,021,026,109,001 Maxab Memorex 125,063 Metz Mina Minerva 011,104 Mitsubishi Morgans 044,018 Motorolat 045,098,112,062,051 Neckermann Next Level Nokia Norsat Obritech Olympus Pace 026,009,139,142 Palcom 022,042 Palladium Palsat Panasonic 116,054,123,766,063...
  • Page 18 Universal Remote Control User's Manual Brand of CABLE CODE 024,038,039,041,042,058,065,088,101,102 Adelphia Aeon Allegro 031,033,063 Americast Antronix Archer 036,045 Asiagiant 003,015 AT&T Bell&howell BEST Cabletenna Cableview Century Citizen Colour Voice 046,047 Comtronics Contec/Cony 066,043,089 Eastern 009,010,011,012 Emerson Everquest 027,028 Garrard Gemini 027,036,054,048 General Instrument 060,077,082,042...
