Summary of Contents for Memorex MiKS2210 - Portable Karaoke System
Page 1
MiKS2210 User’s Guide Guía del usuario Portable iPod/CD/ CD+G Karaoke System Sistema Portátil de Karaoke iPod/CD/CD+G Before operating this product, please read these instructions completely. Antes de operar este producto, sírvase leer este instructivo en su totalidad.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. For future reference, record the serial number of the unit printed on the rear of the cabinet.
SAFETY INSTRUCTIONS Before using the unit, be sure to read all operating instructions 15. OVERLOADING carefully. Please note that these are general precautions and may not Do not overload wall outlets and extension cords as this can result in a pertain to your unit.
LOCATION OF CONTROLS FRONT CD OPEN/CLOSE Area (Top of Unit) Interchangeable Docks Display 17. CD Compartment Carrying Handle (Side of Unit) 18. Skip/Search (o) Button REPEAT Button 19. Skip/Search (n) Button PROGRAM Button 20. Play/Pause (®p) Button POWER Button 21. Stop (I) Button RANDOM Button 22.
POWER SOURCES Use the AC polarized line cord included with the unit for operation on AC power. Insert the small end of the AC cord into the AC jack on the rear of the unit. Insert the other end of the AC cord into any convenient 120V 60Hz household outlet.
OPTIONAL CONNECTIONS If you are using special CD+G (Graphics) discs in this portable Karaoke system, you must connect this unit to a television set in order to see the On-Screen Graphics that are recorded on CD+G Karaoke discs. The video cable has yellow RCA type plugs on each end. Please note that your TV set must have an RCA type Video Input Jack in order to view the CD+G lyrics on your TV screen.
OPTIONAL CONNECTIONS (CONTINUED) 3. You can connect the Audio Out jacks from this portable Karaoke system to the Aux In or Audio In jacks of your home stereo system to hear the sound through your home stereo speakers. Follow the instructions for your home stereo system to select the device connected to the external jacks as the audio source.
OPERATION CONNECTING THE MICROPHONE(S) This unit has two microphone jacks which will allow you to sing along with your favorite songs. Before connecting, make sure the MIC VOLUME control is set to minimum. AUTO VOICE CONTROL (AVC) ECHO CONTROL When the AVC feature is activated, the vocals on a multiplex Rotate the ECHO control clock- recording are muted as soon as the singer begins singing into wise to increase the echo or...
OPERATION (CONTINUED) INSERTING AN iPod Press in gently on the iPod compartment (A); the Insert the iPod (A) onto the connector. Gently iPod compartment will spring outward. push down so the connector on the iPod slides Locate the correct iPod dock to use as shown on onto the connector on this unit.
Page 10
OPERATION (CONTINUED) USING AN iPod WITH THIS UNIT With an iPod connected (see the If you are not already in iPod To play/pause the iPod: mode, rotate the FUNCTION previous page), turn this unit on by Press the Play/Pause (®p) control to select iPod mode.
Page 11
OPERATION (CONTINUED) PLAYING COMPACT DISCS NORMAL PLAYBACK (For karaoke playback, please refer to page 15) Set the MASTER VOLUME Turn this unit on by pressing the Press the CD OPEN/CLOSE area control to a low setting. to open the CD compartment POWER button 1;...
OPERATION (CONTINUED) CD PAUSE CONTROL During CD playback, if you wish Press the Play/Pause (® ) to pause the disc momentarily, button again to release pause and press the Play/Pause (® ) resume normal CD playback; the button. Playback stops but the PLAY indicator will remain on.
OPERATION (CONTINUED) REPEAT PLAYBACK To repeat a single track, while in To repeat all of the tracks on a To cancel Repeat Playback, the Stop mode, press the disc continuously, while in the press the REPEAT button until REPEAT button once; the RPT Stop mode, press the REPEAT the REPEAT indicator goes out.
Page 14
OPERATION (CONTINUED) Press the Skip/Search ( ) or Press either the Skip/Search ( Repeat step 5 until you have or ( ) button to select the programmed the desired track ) button to select the first numbers into the CD Program next track you wish to program.
Page 15
OPERATION (CONTINUED) RANDOM/REPEAT RANDOM PLAYBACK With a disc inserted and while in If desired, press the REPEAT the Stop mode, press the button twice to select Repeat Random playback (will randomly RANDOM button to select play all the tracks on the selected Random playback (will randomly disc continuously);...
Page 16
OPERATION (CONTINUED) PLAYING A CD+G (COMPACT DISC + GRAPHICS) KARAOKE DISC You can listen to a CD+G karaoke disc. CD+G discs combine the recorded music with an additional video track that displays the song lyrics on an external television screen if connected (see pages ).
Page 17
OPERATION (CONTINUED) iPod DOCKS Locate your iPod in the chart below and select the respective dock (the Dock No. is engraved at the back of the docks as shown on the next page) to match with your iPod. Insert the corresponding dock and your iPod into the unit as described on page 8.
Page 18
OPERATION (CONTINUED) NOTES: • The Third Generation iPod 10-15GB uses the same dock as the Fourth Generation iPod 20GB. Also, the Third Generation iPod 30-40GB uses the same dock as the Fourth Generation iPod 40GB. • For the iPod nano (Second Generation) and for the iPod video (Fifth Generation), please use the universal docks included with your iPod.
CARE AND MAINTENANCE Caring for Compact Discs • Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. • Do not attach adhesive tape, stickers, etc. to the compact disc label.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR TO MEMOREX. FOR CONSUMER REPLACEABLE PART(S), SEE PART NUMBER(S) ON PAGES 3, 16 AND 17 AND...
SPECIFICATIONS GENERAL: Power Source ....................120V, 60Hz AC Dimensions ................7.8" (W) x 8.1" (D) x 8" (H) Weight ........................4.75 Lbs Speaker ......................2 x 8 Ohms Output Power ......................2 x 1.2W CD SECTION: Disc Diameter ....................4.72” (120mm) 3.15” (80mm) Single CD Optical Source..................Semiconductor Laser Wavelength .......................780nm Conversion ........................1-bit Specifications are subject to change without notice.
Page 22
CONSERVE EL EMBALAJE AL MENOS 90 DÍAS EN CASO QUE NECESITE REGRESAR EL PRODUCTO AL LUGAR DE COMPRA O A MEMOREX. Para futura referencia, registre el número de serie de la unidad impresa en la parte trasera del gabinete.
MEDIDAS DE SEGURIDAD Antes de usar este aparato asegúrese de leer bien todos los puntos de este incendio o corta circuito. manual de operaciones. Una vez leído guárdelo a la mano para usarlo como 16. No permita la entrada de objetos o líquidos dentro de la unidad. referencia en el futuro.
UBICACIÓN DE LOS CONTROLES FRENTE Puerta del CD (OPEN/CLOSE) (Parte Superior 16. Compartimiento del iPod con Conector y de la Unidad) Bases Docks Intercambiables Pantalla 17. Compartimiento del CD o ) (Skip/Search) Manija (Lateral de la Unidad) 18. Botón de Salto/Búsqueda ( Botón REPETIR (REPEAT) n ) (Skip/Search) 19.
FUENTE DE ENERGÍA Corriente eléctrica: Use el cable de CA polarizado incluido con la unidad para operar con energía de CA. Enchufe en un tomacorriente de CA adecuadamente ubicado de 120V, 60Hz. NOTA: La clavija incluida con la unidad está polarizada para ayudar a minimizar la posibilidad de una descarga eléctrica.
CONEXIONES OPCIONALES Si usted utiliza discos especiales CD+G (Gráficos) en este sistema portátil de Karaoke, deberá conectar la unidad a un televisor para poder visualizar los Gráficos en Pantalla grabados en los discos de Karaoke CD+G. El cable de video posee conectores amarillos del tipo RCA en cada extremo. Tenga en cuenta que su televisor deberá tener una entrada de video RCA para poder visualizar la letra de las canciones del CD+G en la pantalla de su TV.
Page 27
CONEXIONES OPCIONALES (CONTINÚA) 3. Puede conectar la Salida a Audio de este sistema Karaoke portátil a la Entrada Aux o Audio del equipo estéreo para escuchar el sonido por medio de los altavoces del equipo. Siga estas instrucciones sobre su equipo estéreo para seleccionar el aparato conectado a los conectores externos como fuente de audio.
Page 28
FUNCIONAMIENTO CONEXIÓN DEL/LOS MICRÓFONO/S Esta unidad posee dos entradas para micrófono lo cual le permitirá cantar acompañando sus canciones favoritas. Antes de efectuar la conexión, asegúrese de que el control de VOLUMEN DEL MICRÓFONO (MIC VOLUME) está posicionado en mínimo. CONTROL AVC (AUTO VOZ) CONTROL DE ECO (ECHO) Cuando la función AVC (Auto Voz) está...
Page 29
FUNCIONAMIENTO (CONTINÚA) COLOCACIÓN DE iPod Oprima con cuidado el compartimiento del iPod Inserte el iPod (A) en el conector. Empuje (A). El compartimiento saldrá para afuera. cuidadosamente hacia abajo de manera tal que Ubique la base dock correcta de iPod según se el conector del iPod se deslice hasta el conector indica en la página 16.
Page 30
FUNCIONAMIENTO (CONTINÚA) UTILIZACIÓN DEL iPod CON ESTA UNIDAD Con el iPod conectado (vea la Si la unidad aún no se encuentra en modo Reproducir/pausar el iPod: iPod, gire el control de FUNCIÓN página anterior), encienda la Presione el botón Reproducir/ (FNTION) para seleccionar dicho modo.
Page 31
FUNCIONAMIENTO (CONTINÚA) REPRODUCIR DISCOS COMPACTOS REPRODUCCIÓN NORMAL (Para el karaoke, consulte la página 15.) Oprima la puerta del CD (CD OPEN/CLOSE) en la parte Posicione control Encienda la unidad presionando el superior de la unidad para abrir el VOLUMEN PRINCIPAL botón de ENCENDIDO/APAGADO compartimiento del CD.
Page 32
FUNCIONAMIENTO (CONTINÚA) CONTROL DE PAUSA DEL CD Durante la reproducción del CD, si Oprima nuevamente Reproducir/ desea pausar el disco temporalmente, Pausar ( ) (Play/Pause) para ®P presione el botón Reproducir/Pausar retomar la reproducción normal (®P) (Play/Pause). La reproducción se indicador detiene pero el disco continúa girando y REPRODUCIR...
FUNCIONAMIENTO (CONTINÚA) REPRODUCCIÓN REPETIDA Para repetir una pista mientras la Para repetir todas las pistas de Para cancelar la reproducción unidad se encuentra en modo un disco en forma continua repetida, oprima Repetir (Repeat) Detener (Stop), oprima REPETIR mientras se encuentra en el modo hasta que se apague el (REPEAT) una vez;...
Page 34
FUNCIONAMIENTO (CONTINÚA) Presione uno de los botones de Presione uno de los botones de Repita el paso 5 hasta que haya S a l t o / B ú s q u e d a Salto/búsqueda (Skip/search) programado las pistas deseadas ) 1 o ( (Skip/search) para...
Page 35
FUNCIONAMIENTO (CONTINÚA) ORDEN ALEATORIO/ REPRODUCCIÓN CON REPETICIÓN ALEATORIA Coloque un disco y, estando en Si así lo desea puede oprimir el modo Detener (Stop), oprima REPETIR (REPEAT) dos veces para seleccionar la reproducción RANDOM (ORDEN ALEATORIO) con Repetición Aleatoria (todas las para seleccionar la reproducción pistas reproducirán...
Page 36
FUNCIONAMIENTO (CONTINÚA) REPRODUCIR UN DISCO KARAOKE CD+G (DISCO COMPACTO + GRÁFICOS) Usted puede oír un disco karaoke CD+G. Los discos CD+G combinan la música grabada con una pista adicional de video que muestra las letras de las canciones en una pantalla de un televisor externo, si éste está conectado. Mientras escucha la canción, las palabras a cantar se resaltan con colores diferentes en la mayoría de los discos CD+Gs.
Page 37
FUNCIONAMIENTO (CONTINÚA) BASES DOCKS DE iPod Ubique su iPod en el siguiente cuadro y elija la base dock (el nº de Base Dock se encuentra grabado en la parte posterior de las bases según se indica en la siguiente página) que coincida con su iPod. Coloque la base dock correspondiente y su iPod en la unidad según se explica en la página 8.
Page 38
FUNCIONAMIENTO (CONTINÚA) NOTAS: • El iPod de Tercera Generación de 10-15GB utiliza la misma base dock que el iPod Cuarta Generación de 20GB. Asimismo, el iPod de Tercera Generación de 30-40GB utiliza la misma base dock que el iPod Cuarta Generación de 40GB. •...
CUIDADO Y MANTENIMIENTO Cuidado a los discos compactos • Trate el disco compacto con cuidado. Agarre el disco compacto sólo por sus orillas. Nunca permita que sus dedos toquen el lado brilloso y sin etiqueta del disco compacto. • No pegue cinta adhesiva, calcomanías, etc. sobre la etiqueta del disco compacto.
O COMUNÍQUESE CON EL SERVICIO DE ATENCIÓN AL CLIENTE AL (954) 660-7100. CONSERVE EL EMBALAJE AL MENOS 90 DÍAS EN CASO QUE NECESITE REGRESAR EL PRODUCTO AL LUGAR DE COMPRA O A MEMOREX. PARA OBTENER PIEZAS REEMPLAZABLES POR EL CONSUMIDOR, CONSULTE EL NÚMERO DE PIEZA EN LA PÁGINAS 3, 16 Y 17 Y LUEGO COMUNÍQUESE CON FOX INTERNATIONAL AL 1-800-...
ESPECIFICACIONES GENERAL: Fuente de Alimentación ................120V, 60Hz AC Tamaño ..................7.8" (W) x 8.1" (D) x 8" (H) Peso ........................4.75 Lbs Altavoz .......................2 x 8 Ohms Potencia de Salida ....................2 x 1.2W SECCIÓN DEL CD: Diámetro del Disco ..................4.72” (120mm) 3.15” (80mm) CD Único Fuente Óptica..................Semiconductor Láser Longitud de Onda......................780nm Conversión ........................1-bit...
Page 42
Memcorp, Inc. Weston, FL Printed in / Impreso en Hong Kong Visit our website at / Visite nuestro sitio web en www.memorexelectronics.com 172-0407iCDG20-0ME...
