Haier HG-M150 User Manual

USER MANUAL
USER MANUAL
Safety Instructions
These instructions are intended for safe and effective use of your phone. Please
follow these guidelines. Failure to do so might cause the product to malfunction or
even a potential hazard to your health.
Do not use your mobile phone while driving. Park the car before making a call.
Turn off your phone when refueling.
Do not use your phone near a gas station, flammable, or chemical substances.
Warning! It may explode when exposed in fire.
Do not use your phone during a flight, it is dangerous.
Do not use your phone near medical equipments like pacemaker and hearing aids
without requesting permission from the physician or medical staff.
Radio signals may affect the performance of the phone.
Do not touch any exposed parts of the antenna during a call; otherwise it will
affect the call reception and waste battery power.
Do not attempt to disassemble or modify the phone by yourself. Only authorized
personnel should perform this service.
When you connect accessories to your phone, please read the safety guidelines
carefully.
Do not use unauthorized products.
Please use only the original accessories or products that are authorized by our
company.
Keep out of children's reach.
Phone Overview (Picture for reference only)
Left Soft key
Activates/selects the menu
function at the left bottom
side of the LCD screen.
Answer/Dial key
Dials and answers calls. In
standby mode, press to
view recently dialed calls.
Getting Started
Inserting SIM card and Battery
WARNING!
Keep SIM Card out of children's reach.
Any abrasions or bend might easily cause damage. Please take extra care.
Make sure the phone is power off when you remove the SIM Card.
Remove the battery cover by sliding downward.
Insert the SIM Card into the sim card slot with the contacts
facing down.
Place the battery into place. Make sure that the charge pins are in contact with the
battery terminals.
Slide the battery cover until it locks into place.
Taking out the battery
Remove the battery cover. Insert your fingernail at the bottom slot of the battery
compartment and then pull out the battery.
Charging the Battery
Insert the connector of the charger into the top-left side of the phone (Note: Ensure
that the charger connector is plugged in.
Plug the charger into the AC wall outlet.
When the power comes on, "Charging..." will be displayed on the LCD screen, and
the battery indicator will start to scroll. It will only stop after the battery comes to full
HG-M150
1
Navigation key
In standby mode, press;
Left-Date & time setting.
Right-Create message.
Down-Contact list.
Right Soft key
Activates/selects the menu
function at the right bottom
side of the LCD screen.
End/Power key
Ends or reject calls;
Power on/Power off;
In the menu programming,
press to return to standby
mode.
2
3
charge. If a battery is completely discharged, it may take a few minutes before the
charge indicator appears on the LCD screen.
After charging is completed, disconnect charger from phone and the socket of the
alternating current.
Notice:
When charging, please place the phone in an environment that has a normal room
temperature and good ventilation. It is recommended to charge the phone in an
environment with a temperature that ranges from 5
only the charger offered by the manufacturer. Using unauthorized charger may cause
danger and violate the authorization of the phone and the guarantee article.
When the phone automatically turns off or indicates the alarm information of power
shortage, please charge the battery in time.
The duration time of the standby and conversation of the phone offered by
manufacturer is based on ideal working environment. In may vary according to the
network condition, working environment, and application methods.
Warnings!
Do not take the battery out when it is being charged.
To ensure best performance, please use original accessories. Using any
unauthorized accessories may affect your mobile phone's performance.
Personal data and settings in your phone and SIM card might lose when you take out
the battery.
Security number
PIN
PIN (Personal Identity Number), usually provided to a SIM Card by the network
operator.
If you enter the wrong PIN three times in a row, it will be locked. You need to enter
your PUK (Personal Unblocking Key) number to unlock. Please contact your network
operator for more details.
PIN2
PIN2 is provided to some SIM. If you enter the wrong PIN three times in a row, it will
be locked. You need to enter your PUK2 to unlock. Please contact your network
operator for more information.
PUK
PUK (Personal Unblocking Key) is used to unblock the PIN. PUK is provided to a SIM
card. If you lose or forget the password, contact your network operator.
Phone code
Protects your phone against unauthorized use. You can turn on the Phone code for
your personal security use.The original code is "0000".
General Features
Turn on the phone
1.Press and hold key to turn on the phone. The LCD screen will turn on.
2.If SIM card is not properly installed, a warning prompt will appear on the screen.
Press and hold key to turn off, and re-install the SIM card properly.
3. If you have set a phone password, you will be asked to enter your password.
4.If your SIM card is protected by PIN, the phone will instruct you to enter the PIN
number.
5.You will be asked to enter the PUK number if SIM card is locked.
6.The phone will search for network automatically after turned on.
Warning!
If the phone has found an authorized network operator, the name of the network and
signal intensity will be displayed.
If not, you can only use the emergency calls and other non-communication service.
To make Domestic calls
In standby, enter a phone number (with region code and area code), Press
delete a wrong entry. Then press
connected, the call status will be displayed.
To reject a call
When you have incoming call, press
To answer a call
When a call comes in, phone will ring and/or vibrate. It will show the caller's name if
the network support it. The caller's name display depends on whether you have saved
it in your phonebook. Press key to answer, or press Option -> Accept.
To end a call conversation
When you have finished talking, press
key if you want to terminate a call after you dialed.
Emergency calls
You do not need to own a SIM card to make emergency calls.
Emergency calls may differ from different network operators, please contact your
network operator to get your local emergency call number.
To make an international call
To make a international call, press and hold 0 to switch until a + sign appear.
Then enter the country/region code, area code (without the first zero), and the phone
number:
After you have entered the + sign, enter the country code and the number you want to
dial. For example, 49 for Germany, 44 for UK, 46 for Sweden, 86 for China.
Ex.: dial +8613798297223, when making an international call to China.
As you dial a common international call, you don't have to enter the 0 of the city code.
To dial from contacts
Find the number you want to call in your phone book, press
dial the displayed contact.
To dial from the Call list
All the numbers that you have dialed are saved in the calls record. When the calls
memory turns full, the old numbers are automatically deleted. To scroll the call list:
1. In standby, press key. The call records will display starting from the most
recently called number. Press
~40 . Please ensure to use
4
5
key to dial the number. When the call gets
key to reject it.
key to end a call also, you can press
6
key to automatically
key to automatically dial the displayed record.
7
key to
