YORKVILLE YSM1P - PARTS Datasheet

3a
5 & 6
7
8
*NOTE: Replacement grills & HF Driver supports are 'Special-Order' and are only available while the model is in production.
‡ Grilles & Support replacements are for CURRENT models only.
** Internal Lightbulb not shown
Parts-Serv-YSM1P-1v0.xls
1
2
3b
3c
4
ftp.yorkville.com
# Part# Description
Labeled Components
1 YSM1PTWTR 1" TWEETER WITH BUCKING MAGNET
2 YSM1PWFR 6.5 INCH WOOFER W/BUCKING MAGNET
3a 8255D Y LOGO YSM1/P BLUE SMALL DOMED
3b YSM1P LEFT ACTIVE LED LOGO DOMED
8256D
3c 8257D YSM1P RIGHT ACTIVE LED LOGO DOMED
4 DRESS GASKET FOR YSM1I AND YSM1P
YSM1IGAS
5 3425 DPDT PUSH SW PCMT MAKE B4 BREAK
6
8636 BUTTON KNOB FLAT BLACK
7
3396 4POSITION DIP SW KAP1104E
8 4497 _10K B LIN 9MM HORIZONTAL P29
9 3645 AC SOCKET RECEPTACLE WITH 0.250 TAB
10
3698 SPST ROKR SW QUIK 180" AC PWR BL/BL
11 3445 1/4"&XLR PCB MT HORZ COMBO
12
3428 8' 3/18 SJT AC LINE CORD REMOVABLE
15
16
17
18
19
20
21
22
9
10
11
12
Speaker Enclosure
