- Page 2 It was the top of the line amp for the time. In the spirit of all the great Fender amps of yesterday, we offer the Dual Professional of today. It is a hand-made, point-to-point wired, tube instrument amplifier. There are no solid-state (transistor) devices in the signal path of any kind.
- Page 3 DUAL PROFESSIONAL FRONT PANEL FUNCTIONS A. INPUTS - Input 1 is the main guitar input for the Dual Professional. Input 2 will work as a 6dB lower gain, low-Z input for hot, active pickups or as a passive output to link amplifiers in a multi- amp set up.
- Page 4 N. INTENSITY - Adjusts the intensity of the vibrato effect. O. PILOT JEWEL - When this lamp is illuminated, the Dual Professional is receiving power. Should this bulb burn out, unscrew the red jewel and replace the lamp with a type T47 light...
- Page 5 If the amplifier repeatedly blows fuses, it should be checked out by an authorized Fender service center. C. STANDBY SWITCH - This turns the amplifier ON and OFF. In the STANDBY position, the amplifier is off, although power is applied to the tube filaments to keep them warmed up and ready to play.
- Page 6 TOLEX COVERING CARE DO NOT have the amplifier plugged into a power outlet when cleaning. The exclusive Fender tolex covering on your cabinet may be cleaned periodically with a sponge and a light soapy solution. Be careful not to let liquid come in contact with operating surfaces.
- Page 7 DUAL PROFESSIONAL SPECIFICATIONS PART NUMBER: 081-1075-000 (100V) 081-1005-000 (120V) 081-1065-000 (230V) 081-1035-000 (240V) POWER OUTPUT: 100 W R.M.S. minimum into 4 or 8Ω OUTPUT IMPEDANCE: 4 or 8Ω INPUT IMPEDANCE: Input 1: 1MΩ Input 2: 20kΩ EFFECTS RETURN: 1MΩ POWER REQUIREMENTS:...
