Compaq 8000 - Elite Convertible Minitower PC Hardware Reference Manual page 39

3. Turn off the computer properly through the operating system, then turn off any external devices.
4. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION:
long as the system is plugged into an active AC outlet. You must disconnect the power cord to
avoid damage to the internal components of the computer.
5. Remove the computer access panel.
6. Install four 6-32 isolation mounting guide screws, two on each side of the drive.
Figure 2-26
NOTE:
installed on the hard drive bracket under the access panel. The HP-supplied isolation mounting
guide screws are silver and blue. Refer to
of the extra 6-32 isolation mounting guide screws location.
If you are replacing a drive, transfer the guides screws from the old drive to the new one.
7. Slide the hard drive down into the drive cage until it locks. The drivelock automatically secures the
drive in the bay.
Figure 2-27
CAUTION:
unnecessary force when installing any drive into the drive bay may result in damage to the drive.
ENWW
Regardless of the power-on state, voltage is always present on the system board as
Installing the Hard Drive Guide Screws
The hard drive uses 6-32 isolation mounting guide screws. Eight extra guide screws are
Installing a Hard Drive into the Hard Drive Bay
Make sure the guide screws line up with the guide slots in the drive cage. The use of
Installing Additional Drives on page 29 for an illustration
Installing Additional Drives 33
