HP 8000f Elite Illustrated Parts & Service Map

Illustrated Parts & Service Map
HP Compaq 8000f Elite Business PC
Ultra Slim Desktop
©
2010 Hewlett-Packard Development Company, L.P. The information con-
tained herein is subject to change without notice. HP shall not be liable for
technical or editorial errors or omissions contained herein. Intel, Pentium,
Intel Inside, and the Intel logo are trademarks or registered trademarks of the
Intel Corporation and its subsidiaries in the U. S. and other countries.
Document Number 605649-001.
Key Specifications
Processor Type Intel® Core2 Duo
RAM Type DDR3-SDRAM DIMMs, PC3-10600 (1333 MHz) non-ECC
Maximum RAM Supported 4 GB
Expansion Slots (1) PCI Express Mini Card
Chipset Intel Q45 Express supporting Core 2 processors with vPro
Graphics Adapter Integrated Intel Graphics Media Accelerator 4500
Drive Support •
•
I/O Interfaces Front: (4) USB, microphone, headphone
Rear: (6) USB, PS/2 keyboard and mouse, line in, line out,
VGA, DisplayPort, RJ-45
Operating Systems •
•

Spare Parts

System Unit
1 Access panel
2 Front bezel
3 AC adapter, 135W
* Stand
* Bezel blank, Jack Black
* Not shown
HP Compaq 8000f Elite, USDT Chassis
1st Edition February 2010.
Internal: (1) 2.5-inch
External: (1) Slimline optical
Windows 7 Professional 32
Windows 7 Home Premium 32
Cable and accessory
1 Optical drive cable/connector
* Cable cover
* Not shown
Keyboards (not illustrated)
USB, Basic
Brazilian Portuguese
French Canadian
Mass Storage Devices
1 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with
LightScribe. This kit also includes the drive bracket.
2 250 GB, 7200 RPM hard drive
2 160 GB, 7200 RPM hard drive
2 64 GB solid state drive (SSD)
587455-001
587457-001
587744-001
593231-001
593230-001
605649-001
590271-xxx
-201 LA Spanish
-121 U.S.
605163-001
588981-001
-161
-001
595115-001
608746-001
608745-001
581057-001
page 1
