RCA DRC6377 User Manual

User Manual
DRC6377
AVC Multimedia,
Markham, Ontario, L3R 1E3
http: //www.RCAav.com
Read these instructions before using your new product for the first time.
Safety Precautions
* SEE BOTTOM OF UNIT FOR GRAPHIC SYMBOLS *
The lightning flash with an arrowhead symbol, within the equilateral triangle, is intended to alert
the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that
may be of sufficient magnitude to cause an electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in this owner's manual.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE. DO NOT PLACE OBJECTS FILLED WITH LIQUIDS ON OR NEAR THIS UNIT.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE.
WARNING:
Should any trouble occur, disconnect the AC power adapter and refer servicing to a qualified technician.
This product contains a
low power laser device.
THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
On Placement
• Do not use the unit in places that are extremely hot, cold, dusty, or humid.
• Place the unit on a flat and even surface.
• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it with a
cloth, or by placing it on carpeting.
• To avoid magnetizing, do not place the unit near speakers or magnets.
• Do not use this unit in direct sunlight or leave the unit in a closed automobile (or yacht, etc) where it
would be exposed to high temperatures above 104°F (40°C).
• No naked flame sources such as lighted candles should be placed on the AC power adapter or the
main unit.
• The apparatus should not be exposed to splashing or dripping liquids, and no objects filled with
liquids, such as vases, should be placed on apparatus.
On Safety
• When connecting or disconnecting the AC power adapter, grip the plug and not the cord itself.
Pulling the cord may damage it and create a hazard.
• When you are not going to use the unit for a long period of time, disconnect the AC power adapter.
On Condensation
• When left in a heated room where it is warm and damp, water droplets or condensation may form
inside the unit. When there is condensation inside the unit, the unit may not function normally. Let
the unit stand for 1 to 2 hours before turning the power on, or gradually heat the room and allow
the unit to dry before use.
Ventilation Warning
• Do not block the ventilation openings or holes. If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to escape.
• Do not operate the unit in a confined space, such as a bookcase or built-in cabinet. Allow about 4
inches (10cm) of free space all around the unit for adequate ventilation.
Rating Plate Location
• The rating plate is located on the bottom of unit.
EN - 1
Safety Precautions
FCC Statements
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, or rent copyrighted
material without permission.
Apparatus Claims of U.S. Patent Nos. 6,836,549; 6,381,747; 7,050,698; 6,516,132 and 5,583,936 licensed for
limited viewing uses only.
This product incorporates copyright protection technology that is protected by U.S. patents and
other intellectual property rights. Use of this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized
by Macrovision. Reverse engineering or disassembly is prohibited.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block the ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods
of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Disc Formats
DVDs Audio CDs
The unit can playback
[8cm/12cm disc] [8cm/12cm disc] Compatible
Region Management Information
Region Management Information: This unit is designed and manufactured to respond to the Region
Management Information that is encoded on DVDs. If the region number printed on the DVD does not
correspond to the region number of this unit, it cannot play that disc.
The region number of this unit is 1.
Disc Function or Operation That is Not Available
When the symbol appears on the screen, it indicates the function or operation attempted is not
available at that time. This occurs because the DVD manufacturer determines the specific functions of
DVDs. Certain functions may not be available on some DVDs. Be sure to read the documentation provided
with the DVD.
Icons Used on DVDs
Language selections for audio
Sample lcons
Language selections for subtitles
Note:
Screen aspect ratio
When playing back a CD-G (Graphics) or CD EXTRA
disc, the audio portion will be played, but the
Multiple camera angles
graphic images will not be shown.
1 Region code indicator
Title, Chapter and Tracks
• DVDs are divided into "titles" and "chapters".
Title1 Title2
If the disc has more than one movie on it, each
movie would be a separate "title". "Chapters" Chapter1 Chapter2 Chapter3 Chapter1 Chapter2
are sections of titles.
• Audio CDs are divided into "tracks". A "track"
Track1 Track2 Track3 Track4 Track5
is usually one song on an Audio CD.
Note: Numbers identify each title, chapter, and track on a disc. Most discs have these numbers recorded
on them, but some do not.
Notes on Unauthorized Discs
You may not be able to play some DVDs on this unit, particularly if they were purchased from outside your
geographic area or made for business purposes.
EN - 2
Accessories
Please check and identify the supplied accessories.
Remote Control (with battery) ............................................................................................................................... x 1
AC Power Adapter....................................................................................................................................................... x 1
Car Power Adapter...................................................................................................................................................... x 1
Carrying Case ................................................................................................................................................................ x 1
Remote Control
Using the Remote Control
Remove the
• Point the remote control at the REMOTE SENSOR located
PLASTIC sheet
on the unit.
before USING the
• When using this unit in very bright light, the infrared
Remote Control.
REMOTE SENSOR may not work properly.
• The recommended effective distance for remote
Battery Replacement
operation is about 16 feet (5 meters).
When the batter y becomes weak ,
To Change Remote Battery
the operating distance of the remote
control will be greatly reduced and you
1. Open the battery door. 2. Insert one CR2025 (3V) size
will need to replace the battery.
battery.
Note: If the remote control is not going to be used for a long time, remove the battery.
WARNING: Do not dispose of the battery in a fire or it may leak and/or explode.
WARNING: Batteries should not be exposed to excessive heat such as sunshine, fire or the like.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type.
Control Reference Guide
Remote Control
7. Number (0 - 9) buttons
Use when creating programs or locating a
VIDEO
MODE MENU
9 title/chapter/track or specific time.
1
8. REPEAT A-B button
2 PREV SEARCH NEXT
10
Perform point-to-point repeat playback on a
3
DVD or CD.
GOTO STOP PAUSE
4
11 REPEAT DISC button
PLAY
5 Repeat a DVD chapter or title.
ENTER
12 Repeat a CD track or the whole disc.
MEMORY ANGLE DISPLAY
6
M SETUP button
13
AUDIO In Stop Mode, press to display the unit's
3 14
2
SETUP menu.
SUBTITLE/
RETURN
7 15 9. MENU button
4 5 6
Enter and exit the main DVD Menu.
7 8 9 0
10. NEXT button
SETUP
8 Skip to next title, chapter or track on a disc.
A-B DISC 11. STOP button
REPEAT
Stop playing a disc.
PLAY button
Start or resume playback of a disc.
PAUSE button
P r e s s o n c e t o p a u s e p l a y b a c k . P r e s s
1. VIDEO MODE button
subsequently to advance frame by frame on a
Adjust Brightness, Panel Display and Contrast
DVD.
of the LCD screen. 12. DISPLAY button
2. PREV button Show status information on the screen.
Move back through titles, chapters or tracks 13. ANGLE button
on a disc.
Switch between multiple camera angles if
3. / SEARCH buttons applicable to the DVD.
SEARCH: 14. AUDIO button
Fast reverse playback.
Select one of the audio sound tracks on a
SEARCH: DVD (if more than one is available) or select
Fast forward playback. the audio output mode on a CD.
4. GOTO button 15. SUBTITLE button
Skip directly to a location on
S e l e c t o n e o f t h e s u b t i t l e l a n g u a g e s
a CD/DVD. programmed on a DVD (if available).
5. Cursor ( , , , ) buttons RETURN button
Move between selections on a menu screen Return to normal operation after using the
and adjust certain settings.
SETUP menu of a DVD.
ENTER button
Confirm selections on a menu screen.
6. MEMORY button
Set titles/chapters in a favorite order.
EN - 3
Control Reference Guide
Unit
1) LCD screen 8) Disc door
2) DC IN 9V - 12V jack Close tray by pushing the disc door.
AUDIO / VIDEO OUT jacks
3) 9) Open knob
4) CHARGE / STANDBY(power off) / ON switch 10) Remote sensor
VOL control
5) Senses the remote control's signals.
Adjusts the volume. 11) Power ON indicator
6) Headphone jack 12) CHARGING indicator
7) PLAY button
Charge the rechargeable battery before using
Starts or resumes playback of a disc. it for the first time. The normal charging time
Confirms selections on a menu screen.
should be completed in approximately 4-5
STOP button hours. The charging light will go out when
Stops playing a disc.
the battery becomes fully charged.
PAUSE button
Pauses playback of a disc. Each time you
p r e s s t h e P A U S E b u t t o n t h e p i c t u r e
advances one frame on a DVD. Press the
PLAY button to resume playback.
SEARCH button
Performs fast reverse playback.
SEARCH button
Performs fast forward playback.
PREV button
Goes back to the previous chapters / tracks.
NEXT button
Advances chapters / tracks.
Power Supply
A. Using the AC Power Adapter
1
The supplied AC power
adapter operates on AC
To AC power outlet
120V.
AC power adapter
2
To DC IN 9V-12V Jack
Cautions:
• The AC power adapter included with this unit is for its use only. Do not use it with other equipment.
• When the unit is not going to be used for long time, disconnect the AC power adapter from the AC
power outlet.
• When the AC power adapter is plugged in, the apparatus is not completely disconnected from the
main power supply, even when the power is turned off.
Warning:
The AC/DC adapter is used as a disconnect device and it should remain readily operable during intended
use. In order to disconnect the apparatus from the mains completely, the AC/DC adapter should be
disconnected from the outlet completely.
B. Using the Car Power Adapter
The 12V car power adapter
allows the unit to be used
1
with vehicles that have
a 12V, n e g at i ve gro u n d
To cigarette
electrical system. lighter socket
2
Car power adapter To DC IN 9V-12V Jack
Warning:
Disconnect the car power
adapter when not in use.
Not for use in 24V vehicles.
Cautions:
• Use the provided 12V car power adapter only. Use with other car power adapters could damage the
unit.
• The 12V car power adapter included with this unit is for its use only. Do not use it with other
equipment.
• In the interest of traffic safety, do not operate this unit or view videos while driving a vehicle.
• Make sure the unit is securely fastened to prevent it from falling or flying through the air in the event
of an accident.
• When the inside of the cigarette lighter socket is dirty with ashes or dust, the plug section may
become hot due to poor contact. Be sure to clean the cigarette lighter socket before use.
• After use, disconnect the 12V car power adapter from both the unit and cigarette lighter socket.
EN - 4
Power Supply
C. Using the Built-in Battery
The unit has a built-in, non-replaceable, rechargeable battery. Charge the built-in battery before using it
for the first time. The normal charging time should be completed within 4-5 hours. The charging light will
go out when the built-in battery becomes fully charged.
To recharge the built-in battery
To AC power
1
outlet
AC power
adapter
To DC IN 9V-
2
12V jack
Recharging is completed
3 Slide the switch 5
Charging
4 w h e n c h a rg i n g l i g h t
to CHARGE
light ON
goes out
Warnings:
• The built-in battery can only be recharged when the unit is in CHARGE mode while using the AC
power adapter.
• The built-in battery cannot be recharged when the unit is in ON mode.
• Do NOT recharge the built-in battery in a vehicle using the car power adapter.
• Batteries should not be exposed to excessive heat such as sunshine, fire or the like.
Notes:
• When the built-in battery power is low, "Battery Low" will display on the screen and the unit will stop
playing.
• Recharge the built-in battery when you are ready to use it again.
• While using the built-in battery, the environmental temperature should be 41°F (5°C) to 95°F (35°C).
• To get the longest service life of the built-in battery, charge at indoor-temperature.
• The built-in battery in this device may present a risk of fire or chemical burn if mistreated. Do not
disassemble, heat above 212 o F (100 o C), or incinerate.
• The unit should not be exposed to excessive heat such as sunshine, fire or the like.
• When discarding the unit, environmental problems must be considered and local rules or laws
governing the disposal of such products must be strictly followed.
Turning on the Unit
1. Slide the CHARGE / STANDBY / ON switch on the left side of the unit to the
ON position.
2. The start-up picture will appear on the screen.
3. After use, slide the CHARGE / STANDBY / ON switch to the STANDBY (power
off ) position.
Connections
A. Connecting a TV
If your TV has audio/video inputs, you can connect the unit to your TV using a standard Audio/Video
cables.
TV
White Red Yellow
To AUDIO / VIDEO OUT jacks
Audio / Video cable
(not included)
Watching a DVD on your TV
1. Turn on the unit.
2. Turn on the TV and follow the instructions included with it to play the DVD.
B. Using Headphones/Earphones
• Turn down the volume before connecting, and
then adjust the level.
• When headphones/earphones are connected, no
sound will be emitted from the unit's speaker.
Caution:
Avoid listening to sound at levels which may be
harmful to your ears. Headphones/Earphones
(3.5mm diameter plug)
Sound System
Dolby Digital
Dolby Digital is a technology developed by Dolby Laboratories. Soundtracks encoded in Dolby Digital can
reproduce from one to 5.1 discrete channels of excellent quality audio.
The unit automatically recognizes the Dolby Digital bitstream and provides a downmix suitable for two-
channel listening. An additional Dolby Digital decoder is required for reproduction of the discrete multi-
channel soundtracks available on many DVDs.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
EN - 5
